Sargent 8237 OL 26D Grade 1 Classroom Mortise Lock L - Lever O - Rose Field Reversible Conventional Cylinder ASA Strike Satin Chrome

Sargent

Write a Review
SKU:
8237 OL 26D
$884.31
Sargent 8237 OL 26D Grade 1 Classroom Mortise Lock L - Lever O - Rose Field Reversible Conventional Cylinder ASA Strike Satin Chrome
$884.31

Descriptions

When it comes to strength and durability, SARGENT continues to set standards with the 8200 Mortise lock. The 8200 far surpasses ANSI/BHMA A156.13 Series 1000 Grade 1 standards, making it the strongest and most durable mortise lock in the industry. SARGENT Mortise Locks are designed and constructed with high quality components to provide maximum security, performance and durability
TypeTitleURL
catalogSargent 7800/8200 Series Mortise Locks Cataloghttps://dvwi9lnoau63q.cloudfront.net/sargent/catalog/SARGENT_Mortise_Lock_78008200_Series_Catalog.pdf
Sargent Healthcare Hardware Cataloghttps://dvwi9lnoau63q.cloudfront.net/sargent/catalog/SARGENT_Speciality_Hardware_Catalog.pdf
installation-instructions7800/8200 Series Mortise Lock w/Sectional Trim & V Series Indicators Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/7800-8200_Series_Mortise_Lock_w_Sectional_Trim__V_Series_Indicators.pdf
7800/8200 Series Mortise Lock w/VN1 Escutcheon Trim & V Series Indicators Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/7800-8200_Series_Mortise_Lock_w_VN1_Escutcheon_Trim__V_Series_Indicators_Installatio_Instructions.pdf
7800/8200 Series Mortise Locks Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/7800Knob8200LeverMortiseLockEscutcheonRoseTrim.pdf
7900/8200 Series Mortise Locks Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/8200installationA8202A.pdf
Video: 8200 Series Mortise Lock Installationhttps://youtu.be/DWRY72iLKN4
literatureSargent 8200 Series Environmental Product Declaration (EPD)https://dvwi9lnoau63q.cloudfront.net/sargent/literature/133.1_ASSA_ABLOY_mrEPD_Sargent8200SeriesMortiseElectrified.pdf
sell-sheetSargent 8200 Series Mortise Locks Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/sargent/sell-sheet/8200sellsheetv7.pdf

Specifications

Brand:
Sargent
Keyway:
LA Keyway
Parent Manufacturer:
Assa Abloy
Cylinder Type:
Mortise Conventional
Specifications Bullet 4:
O Rose
Armor Front Dimensions:
1-1/4" x 8"
Electronic:
No
Function:
Classroom
Latch Throw (in):
3/4"
Finish Description:
Satin Chrome
Backset (in):
2-3/4"
Product Warranty:
10 Year Warranty
Specifications Bullet 9:
3/4" Dead Latch
Country Of Origin:
USA
Base Material:
Brass Bronze
ADA:
Yes
Latch Description:
Dead Latch
Door Handing:
Non-handed
Certification:
ANSI A156.13, Series 1000, Grade 1, A117.1, UL Listed
Series:
8200 Line Lever Mortise Locks
Grade:
Grade 1
Specifications Bullet 14:
10 Year Warranty
Latch Dimensions:
1-1/4" x 8"
Strike Description:
ASA Strike
Finish:
626/US26D
Strike Dimensions:
1-1/4" x 4-7/8"
Door Range (Thickness):
1-3/4" - 1-3/4"
Specifications Bullet 3:
Mortise Conventional LA Keyway
Commercial/Residential:
Commercial
Includes Cylinder(s)?:
Yes
Specifications Bullet 5:
2-3/4" Backset
Specifications Bullet 8:
2-3/4" Rose Dimension
Specifications Bullet 7:
2-3/8" Projection
Lever/Knob/Pull:
Lever
Lever/Knob/Pull Design:
L
Rose/Escutcheon Design:
O
Specifications Bullet 10:
1-1/8" x 8" Faceplate Dimension
Pocket Depth (in):
6-5/8" x 4-1/2"
Deadbolt Throw (in):
Not Applicable
Can Be Keyed:
Yes
Maximum Door Thickness (in):
1-3/4"
Specifications Bullet 12:
For Doors 1-3/4" Thick
Selling Quantity:
1
Interior/Exterior:
Interior/Exterior
Specifications Bullet 1:
Grade 1 Classroom Function Mortise Lockset
Specifications Bullet 6:
1-1/4" x 4-7/8" ASA Strike
Specifications Bullet 2:
L Lever
Specifications Bullet 13:
ANSI A156.13, Series 1000, Grade 1, A117.1, UL Listed
Pocket Dimensions:
6-5/8" x 4-1/2"
Fire Rated:
2 Hours {B}
Minimum Door Thickness (in):
1-3/4"
Projection (in):
2-3/8"
Strike Number:
82-0110
Rose/Escutcheon:
Rose
UOM:
1
Rose/Escutcheon Dimensions (in):
2-3/4"
Specifications Bullet 11:
6-5/8" x 4-1/2" Pocket Dimension
Manufacturer:
Sargent

Warranty Information

10 Year Warranty
