Sargent 8255 LNJ 10B Grade 1 Office or Entry Mortise Lock J - Lever LN - Rose Field Reversible Conventional Cylinder ASA Strike Dark Oxidized Satin Bronze Oil Rubbed

Sargent

Write a Review
SKU:
8255 LNJ 10B
$871.67
Sargent 8255 LNJ 10B Grade 1 Office or Entry Mortise Lock J - Lever LN - Rose Field Reversible Conventional Cylinder ASA Strike Dark Oxidized Satin Bronze Oil Rubbed
$871.67

Descriptions

When it comes to strength and durability, SARGENT continues to set standards with the 8200 Mortise lock. The 8200 far surpasses ANSI/BHMA A156.13 Series 1000 Grade 1 standards, making it the strongest and most durable mortise lock in the industry. SARGENT Mortise Locks are designed and constructed with high quality components to provide maximum security, performance and durability
TypeTitleURL
catalogSargent 7800/8200 Series Mortise Locks Cataloghttps://dvwi9lnoau63q.cloudfront.net/sargent/catalog/SARGENT_Mortise_Lock_78008200_Series_Catalog.pdf
Sargent Healthcare Hardware Cataloghttps://dvwi9lnoau63q.cloudfront.net/sargent/catalog/SARGENT_Speciality_Hardware_Catalog.pdf
installation-instructions7800/8200 Series Mortise Lock w/Sectional Trim & V Series Indicators Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/7800-8200_Series_Mortise_Lock_w_Sectional_Trim__V_Series_Indicators.pdf
7800/8200 Series Mortise Lock w/VN1 Escutcheon Trim & V Series Indicators Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/7800-8200_Series_Mortise_Lock_w_VN1_Escutcheon_Trim__V_Series_Indicators_Installatio_Instructions.pdf
7800/8200 Series Mortise Locks Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/7800Knob8200LeverMortiseLockEscutcheonRoseTrim.pdf
7900/8200 Series Mortise Locks Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/8200installationA8202A.pdf
Video: 8200 Series Mortise Lock Installationhttps://youtu.be/DWRY72iLKN4
literatureSargent 8200 Series Environmental Product Declaration (EPD)https://dvwi9lnoau63q.cloudfront.net/sargent/literature/133.1_ASSA_ABLOY_mrEPD_Sargent8200SeriesMortiseElectrified.pdf
sell-sheetSargent 8200 Series Mortise Locks Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/sargent/sell-sheet/8200sellsheetv7.pdf

Specifications

Brand:
Sargent
Specifications Bullet 9:
3/4" Dead Latch
Keyway:
LA Keyway
Specifications Bullet 14:
10 Year Warranty
Grade:
Grade 1
Deadbolt Throw (in):
Not Applicable
Maximum Door Thickness (in):
1-3/4"
Specifications Bullet 8:
2-1/8" Rose Dimension
Specifications Bullet 2:
J Lever
Door Range (Thickness):
1-3/4" - 1-3/4"
Specifications Bullet 1:
Grade 1 Office Function Mortise Lockset
Base Material:
Bronze
Pocket Depth (in):
6-5/8" x 4-1/2"
Country Of Origin:
USA
Finish Description:
Dark Oxidized Satin Bronze Oil Rubbed
Specifications Bullet 7:
2-13/16" Projection
Door Handing:
Non-handed
Interior/Exterior:
Interior/Exterior
Backset (in):
2-3/4"
Can Be Keyed:
Yes
Lever/Knob/Pull Design:
J
Specifications Bullet 12:
For Doors 1-3/4" Thick
Includes Cylinder(s)?:
Yes
Lever/Knob/Pull:
Lever
Finish:
613/US10B
Rose/Escutcheon Design:
LN
Specifications Bullet 11:
6-5/8" x 4-1/2" Pocket Dimension
Specifications Bullet 13:
ANSI A156.13, Series 1000, Grade 1, A117.1, UL Listed
Specifications Bullet 5:
2-3/4" Backset
Latch Description:
Dead Latch
Product Warranty:
10 Year Warranty
Cylinder Type:
Mortise Conventional
Selling Quantity:
1
Minimum Door Thickness (in):
1-3/4"
Certification:
ANSI A156.13, Series 1000, Grade 1, A117.1, UL Listed
Electronic:
No
Projection (in):
2-13/16"
Commercial/Residential:
Commercial
Latch Dimensions:
1-1/4" x 8"
Function:
Office
Rose/Escutcheon Dimensions (in):
2-1/8"
Strike Description:
ASA Strike
Pocket Dimensions:
6-5/8" x 4-1/2"
Armor Front Dimensions:
1-1/4" x 8"
Strike Dimensions:
1-1/4" x 4-7/8"
Rose/Escutcheon:
Rose
Parent Manufacturer:
Assa Abloy
Strike Number:
82-0110
UOM:
1
Specifications Bullet 6:
1-1/4" x 4-7/8" ASA Strike
Manufacturer:
Sargent
Specifications Bullet 3:
Mortise Conventional LA Keyway
Latch Throw (in):
3/4"
Series:
8200 Series
Fire Rated:
Yes
Specifications Bullet 4:
LN Rose
ADA:
Yes
Specifications Bullet 10:
1-1/8" x 8" Faceplate Dimension
Uid:
SAR1008255LNJ10B
Url Title:
8255-lnj-10b
Title:
8255 LNJ 10B Sargent Manufacturing Mortise Lock
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Mortise Lock
Series:
8200 Line Lever Mortise Locks
Last Modified:
2023-02-28T05:12:34+00:00
Last Pricing:
2022-09-16T00:00:00+00:00
Msrp:
1227
Popularity:
9
Pack Weight:
6.1
Pack Length:
9.25
Pack Width:
5.625
Pack Height:
4.375
Pack Volume:
227.6367188
Baa Qualified:
Yes
Limited Warranty:
10 Years
Fire Rated:
2 Hours {B}
Unit Of Measure:
Each
Assembly Item:
1

Warranty Information

10 Year Warranty
