Sargent 8265 LNF 26D Grade 1 Privacy Bath/Bedroom Mortise Lock F - Lever LN - Rose Field Reversible ASA Strike Satin Chrome

Sargent

Write a Review
SKU:
8265 LNF 26D
$801.50
Sargent 8265 LNF 26D Grade 1 Privacy Bath/Bedroom Mortise Lock F - Lever LN - Rose Field Reversible ASA Strike Satin Chrome
$801.50

Descriptions

TypeTitleURL
catalogSargent 7800/8200 Series Mortise Locks Cataloghttps://dvwi9lnoau63q.cloudfront.net/sargent/catalog/SARGENT_Mortise_Lock_78008200_Series_Catalog.pdf
Sargent Healthcare Hardware Cataloghttps://dvwi9lnoau63q.cloudfront.net/sargent/catalog/SARGENT_Speciality_Hardware_Catalog.pdf
installation-instructions7800/8200 Series Mortise Lock w/Sectional Trim & V Series Indicators Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/7800-8200_Series_Mortise_Lock_w_Sectional_Trim__V_Series_Indicators.pdf
7800/8200 Series Mortise Lock w/VN1 Escutcheon Trim & V Series Indicators Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/7800-8200_Series_Mortise_Lock_w_VN1_Escutcheon_Trim__V_Series_Indicators_Installatio_Instructions.pdf
7800/8200 Series Mortise Locks Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/7800Knob8200LeverMortiseLockEscutcheonRoseTrim.pdf
7900/8200 Series Mortise Locks Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/8200installationA8202A.pdf
Video: 8200 Series Mortise Lock Installationhttps://youtu.be/DWRY72iLKN4
literatureSargent 8200 Series Environmental Product Declaration (EPD)https://dvwi9lnoau63q.cloudfront.net/sargent/literature/133.1_ASSA_ABLOY_mrEPD_Sargent8200SeriesMortiseElectrified.pdf
sell-sheetSargent 8200 Series Mortise Locks Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/sargent/sell-sheet/8200sellsheetv7.pdf

Specifications

Brand:
Sargent
Series:
8200 Line Lever Mortise Locks
Manufacturer:
Sargent
Parent Manufacturer:
Assa Abloy
Armor Front Dimensions:
1-1/4" x 8"
ADA:
Yes
Base Material:
Brass Bronze
Backset (in):
2-3/4"
Certification:
ANSI A156.13, Series 1000, Grade 1, A117.1, UL Listed
Can Be Keyed:
No
Commercial/Residential:
Commercial
Cylinder Type:
Keyless
Deadbolt Throw (in):
Not Applicable
Country Of Origin:
USA
Door Handing:
Non-handed
Door Range (Thickness):
1-3/4" - 1-3/4"
Fire Rated:
2 Hours {B}
Electronic:
No
Function:
Privacy
Finish:
626/US26D
Finish Description:
Satin Chrome
Includes Cylinder(s)?:
No
Keyway:
Not Applicable
Grade:
Grade 1
Latch Description:
Spring Latch
Interior/Exterior:
Interior/Exterior
Specifications Bullet 1:
Grade 1 Privacy Function Mortise Lockset
Latch Dimensions:
1-1/4" x 8"
Lever/Knob/Pull:
Lever
Lever/Knob/Pull Design:
F
Latch Throw (in):
3/4"
Specifications Bullet 2:
F Lever
Specifications Bullet 3:
LN Rose
Specifications Bullet 5:
1-1/4" x 4-7/8" ASA Strike
Specifications Bullet 6:
2-3/4" Projection
Specifications Bullet 4:
2-3/4" Backset
Specifications Bullet 7:
2-1/8" Rose Dimension
Specifications Bullet 10:
6-5/8" x 4-1/2" Pocket Dimension
Specifications Bullet 8:
3/4" Spring Latch
Specifications Bullet 9:
1-1/8" x 8" Faceplate Dimension
Specifications Bullet 11:
For Doors 1-3/4" Thick
Specifications Bullet 12:
ANSI A156.13, Series 1000, Grade 1, A117.1, UL Listed
Specifications Bullet 13:
10 Year Warranty
Minimum Door Thickness (in):
1-3/4"
Maximum Door Thickness (in):
1-3/4"
Pocket Depth (in):
6-5/8" x 4-1/2"
Product Warranty:
10 Year Warranty
Rose/Escutcheon Design:
LN
Rose/Escutcheon:
Rose
Projection (in):
2-3/4"
Pocket Dimensions:
6-5/8" x 4-1/2"
Strike Number:
82-0110
Strike Description:
ASA Strike
Rose/Escutcheon Dimensions (in):
2-1/8"
Selling Quantity:
1
Strike Dimensions:
1-1/4" x 4-7/8"
UOM:
1
Uid:
SAR1008265LNF26D
Url Title:
8265-lnf-26d
Title:
8265 LNF 26D Sargent Manufacturing Mortise Lock
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Mortise Lock
Last Modified:
2023-02-13T10:04:13+00:00
Last Pricing:
2022-09-16T00:00:00+00:00
Msrp:
1129
Popularity:
8
Pack Weight:
6.1
Pack Length:
9.25
Pack Width:
5.625
Pack Height:
4.375
Pack Volume:
227.6367188
Baa Qualified:
Yes
Limited Warranty:
10 Years
Unit Of Measure:
Each
Assembly Item:
1

Warranty Information

10 Year Warranty
