Sargent 8271-24V LNL 26D Fail Secure 24V Electrified Mortise Lock LN Rose L Lever Satin Chrome

Sargent

Write a Review
SKU:
8271-24V LNL 26D
$1,085.20
Sargent 8271-24V LNL 26D Fail Secure 24V Electrified Mortise Lock LN Rose L Lever Satin Chrome
$1,085.20

Descriptions

Featuring Ecoflex Technology, Sargent 8200 Electromechanical Mortise Locks are field changeable between fail safe and fail secure functions and operate off 12v through 24v power. They are designed to handle single opening, stand alone applications. They can also be readily integrated into sophisticated access control systems. They meet ANSI/BHMA A 156.13 Grade 1 requirements, are UL listed on fire doos and sitisfy industry standards for operating temperature, shock and fire hazard.
TypeTitleURL
catalogSargent 7800/8200 Series Mortise Locks Cataloghttps://dvwi9lnoau63q.cloudfront.net/sargent/catalog/SARGENT_Mortise_Lock_78008200_Series_Catalog.pdf
sell-sheetEcoflex Promotional Sheethttps://dvwi9lnoau63q.cloudfront.net/sargent/sell-sheet/90799A_Sargent_Ecoflex_Sell_Sheet_3.3.14_high_res.pdf

Specifications

Brand:
Sargent
ADA:
Yes
Manufacturer:
Sargent
Backset (in):
2-3/4"
Series:
8270 Series Electrified Lever Mortise Locks
Parent Manufacturer:
Assa Abloy
Door Handing:
Non-handed
Can Be Keyed:
Yes
Certification:
ANSI A156.13-2012, Series 1000, Grade 1, UL Listed
Cylinder Type:
Mortise Conventional
Country Of Origin:
USA
Grade:
Grade 1
Door Range (Thickness):
1-3/4" - 1-3/4"
Finish:
626/US26D
FS/FSE Mode:
Fail Secure
Function:
Electronic Unlocking Storeroom
Keyway:
LA Keyway
Latch Description:
Dead Latch
Latch Throw (in):
3/4"
Includes Cylinder(s)?:
Yes
Lever/Knob/Pull:
Lever
Specifications Bullet 1:
Grade 1 Electronic Unlocking Storeroom Function Mortise Lockset
Lever/Knob/Pull Design:
L
Specifications Bullet 4:
24 VDC Voltage Fail Secure
Specifications Bullet 2:
L Lever
Specifications Bullet 3:
Mortise Conventional LA Keyway
Specifications Bullet 6:
2-3/4" Backset
Specifications Bullet 9:
2-3/8" Projection
Specifications Bullet 8:
3/4" Dead Latch
Specifications Bullet 5:
LN Rose
Specifications Bullet 7:
1-1/4" x 4-7/8" ASA Strike
Specifications Bullet 13:
2 Year Warranty
Maximum Door Thickness (in):
1-3/4"
Specifications Bullet 12:
ANSI A156.13-2012, Series 1000, Grade 1, UL Listed
Specifications Bullet 10:
2-1/8" Rose
Specifications Bullet 11:
For Doors 1-3/4" Thick
Projection (in):
2-3/8"
Rose/Escutcheon Design:
LN
Minimum Door Thickness (in):
1-3/4"
Rose/Escutcheon:
Rose
Product Warranty:
2 Year Warranty
Strike Description:
ASA Strike
Rose/Escutcheon Dimensions (in):
2-1/8"
Strike Dimensions:
1-1/4" x 4-7/8"
Strike Number:
82-0110
Voltage:
24 VDC Voltage
Uid:
SAR100827124VLNL26D
Url Title:
8271-24v-lnl-26d
Title:
8271-24V LNL 26D Sargent Electric Mortise Lock
Type:
Electric Locks
Sub Type:
Electric Mortise Lock
Last Modified:
2023-02-16T05:13:38+00:00
Last Pricing:
2022-09-16T00:00:00+00:00
Msrp:
1517
Finish Description:
Satin Chrome
Popularity:
3
Pack Weight:
6.1
Pack Length:
9.25
Pack Width:
5.625
Pack Height:
4.375
Pack Volume:
227.6367188
Baa Qualified:
Yes
Limited Warranty:
2 Years
Fire Rated:
2 Hours {B}
Unit Of Measure:
Each
Base Material:
Brass or Bronze
Assembly Item:
1

Warranty Information

2 Year Warranty
