HES 9400-630 Fail Safe/Fail Secure Complete 12/24VDC Electric Strike Surface Mounted 1/2 Thickness Satin Stainless Steel

HES

Write a Review
SKU:
9400-630
$375.14
HES 9400-630 Fail Safe/Fail Secure Complete 12/24VDC Electric Strike Surface Mounted 1/2 Thickness Satin Stainless Steel
$375.14

Descriptions

The 9400 series is a slim-line, surface mounted electric strike designed to accommodate rim exit devices with a 1/2" Pullman latch. All components are completely encased within its 1/2" thick stainless steel housing, so no cutting on the frame is required for installation. Simply place the electric strike on the surface of the frame, align it with the exit latchbolt, and install.
TypeTitleURL
brochure/sales-materialAA ESH Electric Strike Overviewhttps://dvwi9lnoau63q.cloudfront.net/hes/literature/ESH_Electric_Strike_Overview_Brochure.pdf
catalog2021 HES/Securitron Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/hes/catalog/ASSA_ABLOY_ESH_Catalog.pdf
compatibility-chartHES Compatibility Charthttps://dvwi9lnoau63q.cloudfront.net/hes/compatibility-chart/HESCompatibilityChart2015.pdf
cross-reference-sheetHES Lock Cross Reference Charthttps://dvwi9lnoau63q.cloudfront.net/hes/cross-reference-sheet/HESLockCrossReference2015.pdf
dimensional-drawingHES 9400 Series Dimensional Drawingshttps://dvwi9lnoau63q.cloudfront.net/hes/dimensional-drawing/HES9400DimensionalDrawings.pdf
installation-guideHES 9400 Series Installation Guidehttps://dvwi9lnoau63q.cloudfront.net/hes/installation-guide/9400_9500_9600InstallationInstructions.pdf
HES 9400 Series Installation Templatehttps://dvwi9lnoau63q.cloudfront.net/hes/installation-guide/940095009600InstallationTemplate.pdf
HES 9400/9500/9600 Electric Strike Installation Guidehttps://dvwi9lnoau63q.cloudfront.net/hes/installation-guide/AADSS1053638_1.pdf
installation-instructionsVideo: 9400 Series Electric Strikes Installationhttps://youtu.be/NcgKlnMjNmY
price-book2023 HES Price Book (effective 4.17.2023)https://dvwi9lnoau63q.cloudfront.net/hes/pricebooks/HES_pricebook_11-2023.pdf
product-guideElectric Strike Selector Guidehttps://dvwi9lnoau63q.cloudfront.net/hes/product-guide/Electric_Strike_Selector_Guide.pdf
HES 9400 Series Overviewhttps://dvwi9lnoau63q.cloudfront.net/hes/product-guide/HES9400SeriesOverview2015.pdf
HES 9400, 9500, 9600 Surface Mounted Electric Strikes Videohttps://youtu.be/8VjpbNdYvUE
HES Electric Strikes for Every Lockset Applicationhttps://dvwi9lnoau63q.cloudfront.net/hes/product-guide/HES_guide_slectric-strikes.pdf
HES Electric Strikes How to Order Guidehttps://dvwi9lnoau63q.cloudfront.net/hes/product-guide/HESESHowtoOrder2015.pdf
sell-sheetHES 9400 Series Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/hes/sell-sheet/HES_9400_Sell-Sheet.pdf

Specifications

Brand:
HES
Parent Manufacturer:
Assa Abloy
Specifications Bullet 1:
12/24 VDC Voltage Electric Strike
Box Depth (in):
1/2"
Interior/Exterior:
Interior/Exterior
Electronic:
No
Latch Throw (in):
1/2"
Finish Description:
Satin Stainless Steel
Specifications Bullet 3:
1500 lbs Static Holding Strength
Current:
240mA @ 12 VDC, 120mA @ 24 VDC Current
Country Of Origin:
USA
UOM:
1
Dimensions:
1-3/4" x 9"
Dynamic Impact Strength:
70 foot-pounds
Certification:
ANSI A156.31, Grade 1, UL 1034, UL 10C
Frame Material:
Metal/Wood
Series:
9400 Series Electric Strikes
Fire Rated:
No
Box Width (in):
1-3/4"
Product Warranty:
5 Year Warranty
Specifications Bullet 8:
ANSI A156.31, Grade 1, UL 1034, UL 10C
Specifications Bullet 4:
240mA @ 12 VDC, 120mA @ 24 VDC Current
Box Height (in):
9"
FS/FSE Mode:
Fail Safe / Fail Secure
Grade:
Grade 1
Finish:
630/US32D
Door Range (Thickness):
-
Specifications Bullet 6:
1-3/4" x 9" Unit Dimension
Specifications Bullet 5:
Fail Safe / Fail Secure
Specifications Bullet 7:
Accepts 1/2" Latch Throw
Specifications Bullet 9:
5 Year Warranty
Selling Quantity:
1
Door Handing:
Non-handed
Voltage:
12/24 VDC Voltage
Base Material:
Stainless Steel
Application:
For RIM Exit Devices having 1/2" Throw
Armor Front Dimensions:
1-3/4" x 9"
Specifications Bullet 2:
For RIM Exit Devices having 1/2" Throw
Static Holding Strength (lbs):
1500
Commercial Residential:
Commercial
Manufacturer:
HES
Uid:
HAN1009400630
Url Title:
9400-630
Title:
9400-630 HES Electric Strike
Type:
Electric Strikes, Bolts, Magnets
Sub Type:
Electric Strikes
Last Modified:
2024-02-03T05:28:27+00:00
Last Pricing:
2023-04-17T00:00:00+00:00
Msrp:
575
Avg Lead Time:
18
Finish Family:
Matte Silver
Popularity:
2
Pack Weight:
2
Pack Length:
10.5
Pack Width:
3.375
Pack Height:
2.25
Pack Volume:
79.734375
Baa Qualified:
Yes
Limited Warranty:
5 Years
Unit Of Measure:
Each
Vendor:
Assa Abloy

Warranty Information

5 Year Warranty
