Schlage B252P6 605 Grade 2 Double Cylinder Deadlatch Conventional 6-Pin Cylinder 2-3/8 Backset Bright Brass Finish

Schlage

Write a Review
SKU:
B252P6 605
$289.74
Schlage B252P6 605 Grade 2 Double Cylinder Deadlatch Conventional 6-Pin Cylinder 2-3/8 Backset Bright Brass Finish
UPC:
840067634912
$289.74

Descriptions

The B250 Series is a range of deadlatches designed for commercial applications. The B250 Series is ideally suited for storage cupboards and non-fire rated service ducts. The B250 is suitable for fire rated duct doors when fitted with a B160 Rose & Turn.
TypeTitleURL
brochure/sales-materialSchlage Finishes Charthttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/ALLEGION_finish-chart.pdf
catalogB250 Series Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/schlage_b250.pdf
installation-instructionsB-Series Single Cylinder Lock Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/B-Series_Single_Cylinder_Lock_Installation_Instructions.PDF
price-book2024 Schlage Commercial Price Book (effective 3.2024)https://dvwi9lnoau63q.cloudfront.net/schlage/pricebooks/SCH_pricebook_3-2024.pdf
service-manualSchlage B Series Service Manualhttps://dvwi9lnoau63q.cloudfront.net/schlage/manuals/Schlage_B_Series_Service_Manual.pdf
templateB250, B252 Series Door Templatehttps://dvwi9lnoau63q.cloudfront.net/schlage/templates/B250__B252_Series_Door_Template.pdf

Specifications

Brand:
Schlage
Box Width (in):
3"
Number of Pins:
5
Bore Hole Diameter (in):
1-1/2"
Minimum Door Thickness (in):
1-1/2"
Deadbolt Throw (in):
1/2"
Keyway:
C Keyway
Door Range (Thickness):
1-1/2" - 1-3/4"
Latch Number:
12-100
Certification:
ANSI A156.36-2010, Grade 2 Auxiliary Lock
Specifications Bullet 10:
3 Year Warranty
Specifications Bullet 8:
1-1/2" Bore Hole Diameter
Box Height (in):
4-3/8"
Product Warranty:
3 Year Warranty
Includes Cylinder(s)?:
Yes
Specifications Bullet 6:
1/2" Deadlatch Throw
Box Weight (lbs):
1.4 lbs
Series:
B250 Series Deadbolts
Box Depth (in):
5-7/8"
Interior/Exterior:
Interior/Exterior
Finish Description:
Bright Brass
Electronic:
No
Function:
Double Cylinder Deadlatch
Specifications Bullet 3:
2-3/8" Backset
Commercial Residential:
Commercial
Can Be Keyed:
Yes
Latch Dimensions:
1-1/8" x 2-1/4"
Latch Bore Diameter (in):
1"
UOM:
1
Specifications Bullet 9:
ANSI A156.36-2010, Grade 2 Auxiliary Lock
Specifications Bullet 4:
1-1/8" x 2-3/4" Rectangle Strike
Door Handing:
Non-handed
Backset (in):
2-3/8"
UPC:
840067634912
Specifications Bullet 1:
Grade 2 Double Cylinder Deadlatch
Specifications Bullet 2:
Conventional C Keyway
Specifications Bullet 5:
For Doors 1-1/2" - 1-3/4" Thick
Latch Description:
Dead Latch
Selling Quantity:
1
Strike Dimensions:
1-1/8" x 2-3/4"
Cylinder Type:
Conventional
Number of Keys:
2
Strike Number:
10-001
Country of Origin:
United States
Manufacturer:
Schlage
Strike Description:
Rectangle Strike
Base Material:
Brass
Parent Manufacturer:
Allegion
Maximum Door Thickness (in):
1-3/4"
Latch Throw (in):
9/16"
Specifications Bullet 7:
1-1/8" x 2-1/4" Latch Dimension
Finish:
605
Grade:
Grade 2

Warranty Information

3 Year Warranty
