Schlage B580 619 Grade 2 Door Bolt No Trim Outside/Thumbturn Inside 12-288 Latch 10-094 Strike 1-3/8 - 1-7/8 Door Thickness Satin Nickel Finish

Schlage

Write a Review
SKU:
B580 619
$65.49
UPC:
840067635803
$65.49

Descriptions

The B500 Series deadbolt from Schlage offers some of the toughest, most versatile Grade 2 deadbolts in the business. Designed by locksmiths for locksmiths, B500 Series can accept every Schlage cylinder format and fit virtually every door you service. It features enhanced lock strength on the jamb side of the door and is offered in most functions with optional single- or dual-sided lock status indicator trim options. Large window size and Schlage’s patented 180-degree visibility will change forever the way you look at deadbolts.
TypeTitleURL
brochure/sales-materialSchlage Finishes Charthttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/ALLEGION_finish-chart.pdf
data-sheetsB500 Series Data Sheethttps://dvwi9lnoau63q.cloudfront.net/schlage/datasheets/B500_Series_Data_Sheet.pdf
installation-instructionsB500 Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/B500_Series_Installation_Instructions.pdf
price-book2024 Schlage Commercial Price Book (effective 3.2024)https://dvwi9lnoau63q.cloudfront.net/schlage/pricebooks/SCH_pricebook_3-2024.pdf
Schlage B Series Indicator Pricing Addendumhttps://dvwi9lnoau63q.cloudfront.net/schlage/pricebooks/B_Series_Indicator_Trim_Price_Book_Addendum_030124.pdf
service-manualSchlage B Series Service Manualhttps://dvwi9lnoau63q.cloudfront.net/schlage/manuals/Schlage_B_Series_Service_Manual.pdf
templateB560, 61, 62, 63 Templatehttps://dvwi9lnoau63q.cloudfront.net/schlage/templates/B560_-_61-62-63_Template.pdf
B571 Templatehttps://dvwi9lnoau63q.cloudfront.net/schlage/templates/B571_Template.pdf

Specifications

Brand:
Schlage
Box Height (in):
9-1/2"
Box Weight (lbs):
5 lbs
Backset (in):
2-3/8 - 2-3/4"
Series:
B500 Series Deadbolts
Box Width (in):
4-3/4"
Box Depth (in):
8-1/4"
Manufacturer:
Schlage
Parent Manufacturer:
Allegion
Bore Hole Diameter (in):
2-1/8"
Base Material:
Brass Bronze
Deadbolt Throw (in):
1"
Cylinder Type:
Keyless
Can Be Keyed:
No
Door Handing:
Non-handed
Door Range (Thickness):
1-3/8" - 1-7/8"
Electronic:
No
Commercial Residential:
Commercial
Certification:
ANSI A156.36-2010, Grade 2, UL Listed
Finish:
619/US15
Country Of Origin:
USA
Latch Description:
Square Corner
Latch Dimensions:
1" x 2-1/4"
Includes Cylinder(s)?:
No
Function:
Door Bolt
Latch Number:
12-288
Finish Description:
Satin Nickel
Grade:
Grade 2
Keyway:
Not Appicable
Latch Bore Diameter (in):
1"
Interior/Exterior:
Interior/Exterior
Specifications Bullet 2:
2-3/8 - 2-3/4" Backset
Latch Throw (in):
1"
Specifications Bullet 1:
Grade 2 Door Bolt Deadbolt
Specifications Bullet 5:
1" Deadbolt Throw
Specifications Bullet 4:
For Doors 1-3/8" - 1-7/8" Thick
Specifications Bullet 3:
1-1/8" x 2-3/4" Rectangle Strike
Specifications Bullet 7:
2-1/8" Bore Hole Diameter
Specifications Bullet 8:
ANSI A156.36-2010, Grade 2, UL Listed
Specifications Bullet 9:
3 Year Warranty
Specifications Bullet 6:
1" x 2-1/4" Latch Dimension
Number of Keys:
0
UPC:
840067635803
Product Warranty:
3 Year Warranty
UOM:
1
Strike Description:
Rectangle Strike
Maximum Door Thickness (in):
1-7/8"
Strike Dimensions:
1-1/8" x 2-3/4"
Selling Quantity:
1
Minimum Door Thickness (in):
1-3/8"
Strike Number:
10-094
Uid:
SCH100B580619
Url Title:
b580-619
Title:
B580 619 Schlage Lock Deadlock
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Deadbolts
Last Modified:
2023-02-26T05:58:06+00:00
Last Pricing:
2023-02-24T00:00:00+00:00
Msrp:
95
Avg Lead Time:
34
Popularity:
3
Pack Weight:
2
Pack Length:
5.75
Pack Width:
4.5
Pack Height:
3
Unit Of Measure:
Each
Vendor:
Allegion

Warranty Information

3 Year Warranty
