Name: Schlage Residential B62 609 KA4 Grade 1 Double Cylinder Deadbolt Lock Conventional Cylinder 5 Pins Keyed Alike Group of 4 Dual Option Latch Satin Brass Blackened Satin Relieved Clear Coated Finish
Brand: Schlage Residential
SKU: B62 609 KA4
Price: 73.09 USD
Availability: InStock

Descriptions

With premium metal construction and plated keyways, Schlage mechanical deadbolts are made with durability in mind. Combine our wide range of unique finish and style options with our easy one-tool installation and you can give your door a stylish makeover in minutes.

Type	Title	URL
brochure/sales-material	Schlage Residential Finishes Chart	https://dvwi9lnoau63q.cloudfront.net/schlageres/brochures/ALLEGION_finish-chart.pdf
installation-manuals	B60/B62 - Deadbolt Installation Instructions	https://dvwi9lnoau63q.cloudfront.net/schlageres/manuals_instructions/P515-788.pdf
	B81/B81F - Installation Manual & Template	https://dvwi9lnoau63q.cloudfront.net/schlageres/manuals_installation/P515-790.pdf
	BE365, FE575, FE595 - Keypad Locks Programming Guide	https://dvwi9lnoau63q.cloudfront.net/schlageres/manuals_instructions/237800341.pdf
	BE375 Schlage Touch Deadbolt Installation Instructions	https://dvwi9lnoau63q.cloudfront.net/schlageres/manuals_instructions/P516-865.pdf
	BE468/BE469 - Schlage Connect™ Z-Wave Association and Configuration Parameters	https://dvwi9lnoau63q.cloudfront.net/schlageres/manuals_instructions/24352403.pdf
	Schlage Control Smart Locks User Guide	https://dvwi9lnoau63q.cloudfront.net/schlageres/manuals_instructions/schlage-control-smart-locks-user-guide.pdf
price-book	2024 Schlage Residential Price Book (effective 3.2024)	https://dvwi9lnoau63q.cloudfront.net/schlageres/pricebook/SCR_pricebook_3-2024.pdf
sell-sheet	Schlage Residential B-Series Deadbolts Sell Sheet	https://dvwi9lnoau63q.cloudfront.net/schlageres/sell-sheets/MR-0027.pdf
video	How to Install Schlage BE467 Control Smart Deadbolt	https://youtu.be/yG8I_Immdiw
	How To: Keypad Deadbolt Cam Positioning	https://youtu.be/JWvFXVjoNPM
	Installing Your BE365 Keypad Deadbolt	https://youtu.be/bU5MaaT8gX4

Specifications

Brand:

Schlage Residential

Specifications Bullet 4:

1-1/8" x 2-3/4" Rectangle Strike

Deadbolt Throw (in):

Series:

B Series Residential Deadbolts

Box Weight (lbs):

1.6 lbs

Base Material:

Brass

Latch Bore Diameter (in):

Can Be Keyed:

Yes

Cylinder Type:

Conventional

Box Depth (in):

Country Of Origin:

Mexico

Finish Description:

Satin Brass Blackened Satin Relieved Clear Coated

Electronic:

Door Handing:

Non-handed

Commercial Residential:

Residential

Selling Quantity:

Minimum Door Thickness (in):

1-3/8"

Specifications Bullet 8:

1-1/2" Bore Hole Diameter

Certification:

ANSI A156.40-2015, Residential Grade AAA

Latch Dimensions:

1" x 2-1/4"

Includes Cylinder(s)?:

Yes

Keyway:

C Keyway

Door Range (Thickness):

1-3/8" - 1-3/4"

Finish:

609/US5

Strike Description:

Rectangle Strike

Box Width (in):

4-3/8"

Specifications Bullet 7:

1" x 2-1/4" Latch Dimension

Specifications Bullet 10:

1 Year Warranty

Specifications Bullet 5:

For Doors 1-3/8" - 1-3/4" Thick

Parent Manufacturer:

Allegion

Number of Keys:

UPC:

840067626818

Latch Number:

12-321

Interior/Exterior:

Interior/Exterior

UOM:

Grade:

Grade 1

Maximum Door Thickness (in):

1-3/4"

Manufacturer:

Schlage Residential

Specifications Bullet 3:

2-3/8 - 2-3/4" Backset

Specifications Bullet 9:

ANSI A156.40-2015, Residential Grade AAA

Product Warranty:

1 Year Warranty

Strike Number:

10-116

Specifications Bullet 2:

Conventional C Keyway

Function:

Double Cylinder

Box Height (in):

Backset (in):

2-3/8 - 2-3/4"

Number of Pins:

Latch Description:

Square Corner

Bore Hole Diameter (in):

1-1/2"

Specifications Bullet 1:

Grade AAA Double Cylinder Deadbolt

Strike Dimensions:

1-1/8" x 2-3/4"

Specifications Bullet 6:

1" Deadbolt Throw

Uid:

SCR100B62N609

Url Title:

b62n-609

Title:

B62N 609

Type:

Locks, Cylinders, Cores, Keyblanks

Sub Type:

Deadbolts

Last Modified:

2023-02-26T06:10:12+00:00

Last Pricing:

2023-02-24T00:00:00+00:00

Msrp:

111

Avg Lead Time:

Finish Family:

Matte Brass

Popularity:

Pack Weight:

1.6

Pack Length:

5.66

Pack Width:

4.38

Pack Height:

2.86

Pack Volume:

70.901688

Ansi Code:

ANSI/BHMA A156.36-2016 Commercial Grade 1

Limited Warranty:

Lifetime

Unit Of Measure:

Each

Unit Of Measure 2:

Case

Unit Of Measure 2 Qty:

Vendor:

Allegion

Warranty Information

1 Year Warranty

Schlage Residential B62 609 KA4 Grade 1 Double Cylinder Deadbolt Lock Conventional Cylinder 5 Pins Keyed Alike Group of 4 Dual Option Latch Satin Brass Blackened Satin Relieved Clear Coated Finish
