Arrow BM11 HSH 26D Apartment Front Door Mortise Lock HS Lever H Escutcheon Satin Chrome

Arrow

Write a Review
SKU:
BM11 HSH 26D
$523.38
Arrow BM11 HSH 26D Apartment Front Door Mortise Lock HS Lever H Escutcheon Satin Chrome
$523.38

Descriptions

Arrow mortise locks are offered in a complete range of functions designed for commercial, institutional and industrial applications. They are engineered for strength and performance, and precisely manufactured to exacting standards. Arrow mortise locks are intended for heavy duty use in schools, hospitals and commercial buildings where security, durability and low maintenance are required. The lock case is made from heavy gauge steel, with zinc dichromate finish for corrosion resistance and it can be re-handed without disassembling the lock case. A wide selection of trim designs and functions are offered which meet or exceed the performance requirements of ANSI Grade 1.
TypeTitleURL
catalogAM/BM Series Mortise Lock Cataloghttps://dvwi9lnoau63q.cloudfront.net/arrow/catalog/ARR_catalog_am-bm-series.pdf
cut-sheetAM Series / BM Series Cut Sheethttps://dvwi9lnoau63q.cloudfront.net/arrow/cut-sheet/MortiseLocks.pdf

Specifications

Brand:
Arrow
Lever/Knob/Pull:
Lever
Cylinder Type:
Mortise Conventional
Deadbolt Throw (in):
1"
Country of Origin:
United States
Finish Description:
Satin Chrome
ADA:
Yes
Series:
BM Series Mortise Locks
Specifications Bullet 10:
3/4" Dead Latch
Specifications Bullet 4:
H Rose
Keyway:
A Keyway
Lever/Knob/Pull Design:
HS
Grade:
Grade 1
Maximum Door Thickness (in):
1-3/4"
Specifications Bullet 1:
Grade 1 Entrance Function Mortise Lockset
Certification:
ANSI A156.13, Series 1000, Grade 1, UL Listed
Manufacturer:
Arrow
Latch Description:
Dead Latch
Finish:
626/US26D
Specifications Bullet 2:
HS Lever
Fire Rated:
3 Hours {A}
Specifications Bullet 5:
2-3/4" Backset
Electronic:
No
Function:
Entrance
Specifications Bullet 12:
6-5/8" X 4-1/2" Pocket Dimension
Specifications Bullet 6:
1-1/4" x 4-7/8" ASA Strike
Commercial/Residential:
Commercial
Minimum Door Thickness (in):
1-3/4"
Specifications Bullet 14:
ANSI A156.13, Series 1000, Grade 1, UL Listed
Door Handing:
Non-handed
Specifications Bullet 3:
Mortise Conventional A Keyway
Pocket Dimensions:
6-5/8" X 4-1/2"
Specifications Bullet 7:
2-15/16" Projection
Backset (in):
2-3/4"
Latch Throw (in):
3/4"
Projection (in):
2-15/16"
Door Range (Thickness):
1-3/4" - 1-3/4"
Specifications Bullet 11:
1-1/8" x 8" Faceplate Dimension
UOM:
1
Base Material:
Brass or Bronze
Specifications Bullet 8:
2-1/4" Rose Dimension
Specifications Bullet 13:
For Doors 1-3/4" Thick
Specifications Bullet 15:
5 Year Warranty
Strike Number:
460
Strike Description:
ASA Strike
Rose/Escutcheon Design:
H
Strike Dimensions:
1-1/4" x 4-7/8"
Armor Front Dimensions:
1-1/4" x 8"
Can Be Keyed:
Yes
Parent Manufacturer:
Assa Abloy
Product Warranty:
5 Year Warranty
Specifications Bullet 9:
1" Deadbolt Throw
Uid:
ARR100BM11HSH26D
Url Title:
bm11-hsh-26d
Title:
BM11 HSH 26D Arrow Mortise Lock
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Mortise Lock
Last Modified:
2023-02-26T05:49:55+00:00
Last Pricing:
2022-09-16T00:00:00+00:00
Msrp:
755
Avg Lead Time:
54
Popularity:
3
Pack Weight:
6
Pack Length:
9.25
Pack Width:
5.75
Pack Height:
4.5
Pack Volume:
239.34375
Limited Warranty:
5 Years
Unit Of Measure:
Each

Warranty Information

5 Year Warranty
