Arrow BM17 HSL 26D IC7 Classroom Mortise Lock HS Lever L Rose SFIC Prep Less Core Satin Chrome

Arrow

Write a Review
SKU:
BM17 HSL 26D IC7
$474.81
Arrow BM17 HSL 26D IC7 Classroom Mortise Lock HS Lever L Rose SFIC Prep Less Core Satin Chrome
$474.81

Descriptions

Arrow mortise locks are offered in a complete range of functions designed for commercial, institutional and industrial applications. They are engineered for strength and performance, and precisely manufactured to exacting standards. Arrow mortise locks are intended for heavy duty use in schools, hospitals and commercial buildings where security, durability and low maintenance are required. The lock case is made from heavy gauge steel, with zinc dichromate finish for corrosion resistance and it can be re-handed without disassembling the lock case. A wide selection of trim designs and functions are offered which meet or exceed the performance requirements of ANSI Grade 1.
TypeTitleURL
catalogAM/BM Series Mortise Lock Cataloghttps://dvwi9lnoau63q.cloudfront.net/arrow/catalog/ARR_catalog_am-bm-series.pdf
cut-sheetAM Series / BM Series Cut Sheethttps://dvwi9lnoau63q.cloudfront.net/arrow/cut-sheet/MortiseLocks.pdf

Specifications

Brand:
Arrow
Parent Manufacturer:
Assa Abloy
Manufacturer:
Arrow
Armor Front Dimensions:
1-1/4" x 8"
ADA:
Yes
Series:
BM Series Mortise Locks
Commercial/Residential:
Commercial
Certification:
ANSI A156.13, Series 1000, Grade 1, UL Listed
Can Be Keyed:
Yes
Backset (in):
2-3/4"
Base Material:
Brass or Bronze
Deadbolt Throw (in):
Not Applicable
Country of Origin:
United States
Cylinder Type:
Mortise SFIC Housing
Door Handing:
Non-handed
Door Range (Thickness):
1-3/4" - 1-3/4"
Finish:
626/US26D
Fire Rated:
3 Hours {A}
Electronic:
No
Finish Description:
Satin Chrome
Function:
Classroom
Keyway:
Less Core
Grade:
Grade 1
Latch Description:
Dead Latch
Interior/Exterior:
Interior/Exterior
Includes Cylinder(s)?:
No
Latch Throw (in):
3/4"
Lever/Knob/Pull Design:
HS
Specifications Bullet 2:
HS Lever
Specifications Bullet 1:
Grade 1 Classroom Function Mortise Lockset
Lever/Knob/Pull:
Lever
Specifications Bullet 4:
L Rose
Specifications Bullet 5:
2-3/4" Backset
Specifications Bullet 6:
1-1/4" x 4-7/8" ASA Strike
Specifications Bullet 7:
2-15/16" Projection
Specifications Bullet 3:
Mortise SFIC Housing Less Core
Specifications Bullet 8:
2-1/4" Rose Dimension
Specifications Bullet 10:
1-1/8" x 8" Faceplate Dimension
Specifications Bullet 9:
3/4" Dead Latch
Specifications Bullet 12:
For Doors 1-3/4" Thick
Specifications Bullet 11:
6-5/8" X 4-1/2" Pocket Dimension
Minimum Door Thickness (in):
1-3/4"
Maximum Door Thickness (in):
1-3/4"
Pocket Dimensions:
6-5/8" X 4-1/2"
Specifications Bullet 13:
ANSI A156.13, Series 1000, Grade 1, UL Listed
Specifications Bullet 14:
5 Year Warranty
Projection (in):
2-15/16"
Product Warranty:
5 Year Warranty
Rose/Escutcheon:
Rose
Rose/Escutcheon Design:
L
Rose/Escutcheon Dimensions (in):
2-1/4"
Strike Number:
460
Selling Quantity:
1
Strike Description:
ASA Strike
Strike Dimensions:
1-1/4" x 4-7/8"
UOM:
1
Uid:
ARR100BM17HSL26DIC7
Url Title:
bm17-hsl-26d-ic7
Title:
BM17 HSL 26D IC7 Arrow Mortise Lock
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Mortise Lock
Last Modified:
2022-10-18T05:15:00+00:00
Last Pricing:
2022-09-16T00:00:00+00:00
Msrp:
688
Popularity:
8
Pack Weight:
6
Pack Length:
9.25
Pack Width:
5.75
Pack Height:
4.5
Pack Volume:
239.34375
Limited Warranty:
5 Years
Unit Of Measure:
Each

Warranty Information

5 Year Warranty
