  • Corbin Russwin CL3132 PZD 626 M08 Grade 1 Institutional/Utility Cylindrical Lock Princeton Lever D Rose SFIC Less Core Satin Chrome Finish Non-handed

Corbin Russwin CL3132 PZD 626 M08 Grade 1 Institutional/Utility Cylindrical Lock Princeton Lever D Rose SFIC Less Core Satin Chrome Finish Non-handed

Corbin Russwin

Write a Review
SKU:
CL3132 PZD 626 M08
$1,083.32
Corbin Russwin CL3132 PZD 626 M08 Grade 1 Institutional/Utility Cylindrical Lock Princeton Lever D Rose SFIC Less Core Satin Chrome Finish Non-handed
UPC:
840067629192
$1,083.32

Descriptions

The CL3100 series is a Grade 1 lever lockset manufactured with the highest quality materials to ensure strength, durability and quiet operation. Available in all standard architectural finishes, the CL3100 series subtly complements any high-use commercial, industrial and institutional application.
TypeTitleURL
catalogCL3100 Series Cylindrical Lock Cataloghttps://dvwi9lnoau63q.cloudfront.net/corbin/catalogs/Corbin_Russwin_CL3100_Series_Cylindrical_Lock_Catalog.pdf
installation-instructionsCL3100 Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/corbin/installation-instructions/Corbin_Russwin_CL3100_Series_Installation_Instructions.pdf
Video: CL3100 Series Cylindrical Lock Installationhttps://youtu.be/mrbX3uF49GM
literatureCL3100 Series Vandal Resistant Lock - Environmental Product Declaration (EPD)https://dvwi9lnoau63q.cloudfront.net/corbin/literature/123.1_ASSA_ABLOY_EPD_Corbin_Russwin_CL_3100_Lock.pdf
parts-manualCL3100 Series Lever Lockset Parts Manualhttps://dvwi9lnoau63q.cloudfront.net/corbin/partsmanual/Corbin_Russwin_CL3100_Series_Lever_Lockset_Parts_Manual.pdf
price-book2023 Corbin Price Book (updated 10.2023)https://dvwi9lnoau63q.cloudfront.net/corbin/pricebooks/COR_pricebook_10-2023.pdf

Specifications

Brand:
Corbin Russwin
Specifications Bullet 3:
SFIC Housing Less Core
Latch Description:
Dead Latch
Parent Manufacturer:
Assa Abloy
Finish:
626/US26D
Specifications Bullet 10:
2-1/8" Bore Hole Diameter
Cylinder Type:
SFIC Housing
Latch Number:
780F82
Rose/Escutcheon:
Rose
Certification:
ANSI A156.2, Series 4000, Grade 1, A117.1, UL Listed
Specifications Bullet 11:
ANSI A156.2, Series 4000, Grade 1, A117.1, UL Listed
Grade:
Grade 1
Box Weight (lbs):
4.3 lbs
Commercial Residential:
Commercial
Door Range (Thickness):
1-3/4" - 2"
Includes Cylinder(s)?:
No
Keyway:
Less Core
Lever/Knob/Pull:
Lever
Specifications Bullet 6:
1-1/4" x 4-7/8" ASA Strike
Door Handing:
Non-handed
Specifications Bullet 1:
Grade 1 Institutional Function Cylindrical Lockset
Electronic:
No
Base Material:
Brass, Bronze
Box Depth (in):
10"
Latch Dimensions:
1-1/8" x 2-1/4"
Lever/Knob/Pull Design:
Princeton
Backset (in):
2-3/4"
Specifications Bullet 4:
2-3/4" Backset
Specifications Bullet 7:
2-7/8" Projection
Product Warranty:
10 Year Limited Warranty
Minimum Door Thickness (in):
1-3/4"
Specifications Bullet 5:
1-1/8" x 2-1/4" Dead Latch
Country Of Origin:
United States
ADA:
Yes
Box Height (in):
4-1/2"
Maximum Door Thickness (in):
2"
UPC:
840067629192
Box Width (in):
7-1/2"
Fire Rated:
3 Hours {A}
Rose/Escutcheon Design:
D
Latch Bore Diameter (in):
1"
Specifications Bullet 9:
For Doors 1-3/4" - 2" Thick
Can Be Keyed:
Yes
Projection (in):
2-7/8"
Bore Hole Diameter (in):
2-1/8"
Series:
CL3100 Series Grade 1 Cylindrical Lever Locks
Function:
Institutional
Strike Description:
ASA Strike
Specifications Bullet 8:
3-1/2" D Rose
Selling Quantity:
1
Finish Description:
Satin Chrome
Specifications Bullet 2:
Princeton Lever
Manufacturer:
Corbin Russwin
Strike Number:
217L13
Rose/Escutcheon Dimensions (in):
3-1/2"
Strike Dimensions:
1-1/4" x 4-7/8"
Latch Throw (in):
1/2"
Specifications Bullet 12:
10 Year Limited Warranty
UOM:
1

Warranty Information

10 Year Limited Warranty
