  • Corbin Russwin CL3352 NZD 626 Grade 1 Classroom Intruder Cylindrical Lock Newport Lever Conventional Cylinder Satin Chrome Finish Non-handed

Corbin Russwin CL3352 NZD 626 Grade 1 Classroom Intruder Cylindrical Lock Newport Lever Conventional Cylinder Satin Chrome Finish Non-handed

Corbin Russwin

Write a Review
SKU:
CL3352 NZD 626
$639.69
Corbin Russwin CL3352 NZD 626 Grade 1 Classroom Intruder Cylindrical Lock Newport Lever Conventional Cylinder Satin Chrome Finish Non-handed
UPC:
840067630648
$639.69

Descriptions

The CL3300 series is a Grade 1 cylindrical lockset manufactured with the highest quality materials to ensure strength, durability and quiet operation. Available in all standard architectural finishes and four lever designs, the CL3300 series subtly complements any high-use commercial, industrial and institutional application.
TypeTitleURL
catalogCL3300 Series Cylindrical Lock Cataloghttps://dvwi9lnoau63q.cloudfront.net/corbin/catalogs/Corbin_Russwin_CL3300_Series_Cylindrical_Lock_Catalog.pdf
installation-instructionsCL3300 and CL3600 Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/corbin/installation-instructions/FM123.pdf
CL3300 and CL3600 Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/corbin/installation-instructions/FM123.pdf
CL3300 Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/corbin/installation-instructions/FM53307-12.pdf
CL3300 Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/corbin/installation-instructions/FM53307-12.pdf
literatureCL3300 Series Cylindrical Lock - Environmental Product Declaration (EPD)https://dvwi9lnoau63q.cloudfront.net/corbin/literature/124.1_ASSA_ABLOY_mrEPD_Corbin_Russwin_CL3300_Series_Lock.pdf
price-book2023 Corbin Price Book (updated 10.2023)https://dvwi9lnoau63q.cloudfront.net/corbin/pricebooks/COR_pricebook_10-2023.pdf

Specifications

Brand:
Corbin Russwin
Can Be Keyed:
Yes
Finish Description:
Satin Chrome
Grade:
Grade 1
Door Handing:
Non-handed
Finish:
626/US26D
Minimum Door Thickness (in):
1-3/4"
Backset (in):
2-3/4"
Latch Description:
Dead Latch
Certification:
ANSI A156.2, Series 4000, Grade 1, A117.1, UL Listed
Box Weight (lbs):
4.8 lbs
Selling Quantity:
1
Base Material:
Brass, Bronze
Includes Cylinder(s)?:
Yes
Specifications Bullet 12:
7 Year Limited Warranty
Specifications Bullet 11:
ANSI A156.2, Series 4000, Grade 1, A117.1, UL Listed
Latch Number:
586F17
Specifications Bullet 7:
2-13/16" Projection
UPC:
840067630648
Country Of Origin:
United States
Specifications Bullet 1:
Grade 1 Classroom Intruder Function Cylindrical Lockset
Commercial Residential:
Commercial
Specifications Bullet 3:
Conventional L4 Keyway
Keyway:
L4 Keyway
Cylinder Type:
Conventional
Latch Throw (in):
1/2"
Specifications Bullet 10:
2-1/8" Bore Hole Diameter
Specifications Bullet 5:
1-1/8" x 2-1/4" Dead Latch
Specifications Bullet 6:
1-1/4" x 4-7/8" ASA Strike
Specifications Bullet 4:
2-3/4" Backset
Lever/Knob/Pull Design:
Newport
Lever/Knob/Pull:
Lever
Latch Bore Diameter (in):
1"
UOM:
1
Latch Dimensions:
1-1/8" x 2-1/4"
Box Width (in):
7-1/2"
Electronic:
No
Rose/Escutcheon Design:
D
Box Height (in):
4-1/2"
Specifications Bullet 2:
Newport Lever
Function:
Classroom Intruder
Fire Rated:
3 Hours {A}
Series:
CL3300 Series Grade 1 Cylindrical Lever Locks
Rose/Escutcheon:
Rose
Projection (in):
2-13/16"
Box Depth (in):
10"
Bore Hole Diameter (in):
2-1/8"
Strike Description:
ASA Strike
Manufacturer:
Corbin Russwin
Door Range (Thickness):
1-3/4" - 2"
Maximum Door Thickness (in):
2"
Specifications Bullet 9:
For Doors 1-3/4" - 2" Thick
Product Warranty:
7 Year Limited Warranty
ADA:
Yes
Rose/Escutcheon Dimensions (in):
3-1/2"
Strike Dimensions:
1-1/4" x 4-7/8"
Strike Number:
217L13
Specifications Bullet 8:
3-1/2" D Rose
Parent Manufacturer:
Assa Abloy
Uid:
COR300CL3352NZD626
Url Title:
cl3352-nzd-626
Title:
Corbin Russwin CL3352 NZD 626 Cylindrical Lock
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Cylindrical Lock
Last Modified:
2023-02-13T12:03:57+00:00
Last Pricing:
2022-09-16T00:00:00+00:00
Msrp:
946
Avg Lead Time:
12
Finish Family:
Matte Silver
Popularity:
3
Pack Weight:
7
Pack Length:
10
Pack Width:
8
Pack Height:
4.5
Pack Volume:
360
Ul Listing:
ANSI A156.2, Series 4000, Grade 1, UL Listed
Ansi Code:
F110
Limited Warranty:
7 Year Warranty
Unit Of Measure:
Each
Unit Of Measure 2:
Case
Unit Of Measure 2 Qty:
6
Vendor:
ASSA ABLOY
Assembly Item:
1

Warranty Information

7 Year Limited Warranty
