Dexter DB1000-SCT-626-KDC Grade 1 Single Cylinder Deadbolt 2-3/8 or 2-3/4 Adjustable Backset Conventional Cylinder Satin Chrome Finish Non-Handed

Dexter

Write a Review
SKU:
DB1000-SCT-626-KDC
$48.95
Dexter DB1000-SCT-626-KDC Grade 1 Single Cylinder Deadbolt 2-3/8 or 2-3/4 Adjustable Backset Conventional Cylinder Satin Chrome Finish Non-Handed
UPC:
840067637890
$48.95

Descriptions

Grade 1 Single Cylinder Deadbolt, 2-3/8" or 2-3/4" Adjustable Backset, Conventional Cylinder, Satin Chrome Finish, Non-Handed
TypeTitleURL
brochure/sales-materialDexter Finishes Charthttps://dvwi9lnoau63q.cloudfront.net/dexter/miscellaneous/DEXTER_finish-chart.pdf
catalogDexter Full Line Cataloghttps://dvwi9lnoau63q.cloudfront.net/dexter/catalogs/Dexter_Full_Line_Catalog_110998.pdf
installation-instructionsInstallation Instructions: Dexter DB1000 Deadbolt SFIC Instructionshttps://dvwi9lnoau63q.cloudfront.net/dexter/installationinstructions/Dexter_DB1000_Deadbolt_SFIC_Instructions_111075.pdf
Installation Instructions: Dexter DB1000 Deadbolt Standard Instructionshttps://dvwi9lnoau63q.cloudfront.net/dexter/installationinstructions/Dexter_DB1000_Deadbolt_Standard_Instructions_111076.pdf
price-books2023 Dexter Price Book (updated 10.16.2023)https://dvwi9lnoau63q.cloudfront.net/dexter/pricebook/DEX_pricebook_10-2023.pdf
2024 Dexter Price Book (effective 3.2024)https://dvwi9lnoau63q.cloudfront.net/dexter/pricebook/DEXTER_pricebook_3-2024.pdf

Specifications

Brand:
Dexter
Can Be Keyed:
Yes
Function:
Single Cylinder
Specifications Bullet 1:
Grade 1 Single Cylinder Deadbolt
Finish Description:
Satin Chrome
Cylinder Type:
Conventional
Specifications Bullet 2:
Conventional C Keyway
Door Range (Thickness):
1-3/8" - 1-7/8"
Parent Manufacturer:
Allegion
Electronic:
No
Specifications Bullet 9:
Certified Grade 1, UL Listed
Product Warranty:
5 Year Warranty
Includes Cylinder(s)?:
Yes
Strike Dimensions:
1-1/8" x 2-3/4"
Finish:
626/US26D
Specifications Bullet 4:
1-1/8" x 2-3/4" Rectangle Strike
Specifications Bullet 6:
1" Deadbolt Throw
Box Width (in):
3-3/4"
Box Height (in):
3-1/4"
Backset (in):
2-3/8 - 2-3/4"
Specifications Bullet 3:
2-3/8 - 2-3/4" Backset
Latch Bore Diameter (in):
1"
Specifications Bullet 5:
For Doors 1-3/8" - 1-7/8" Thick
Maximum Door Thickness (in):
1-7/8"
Latch Description:
Square Corner
Grade:
Grade 1
Specifications Bullet 8:
2-1/8" Bore Hole Diameter
UOM:
1
Number of Pins:
6
Certification:
Certified Grade 1, UL Listed
Commercial Residential:
Commercial
Minimum Door Thickness (in):
1-3/8"
Number of Keys:
2
Specifications Bullet 10:
5 Year Warranty
Series:
DB1000 Series Grade 1 Deadbolts
Specifications Bullet 7:
1-1/8" x 2-1/4" Latch Dimension
Bore Hole Diameter (in):
2-1/8"
UPC:
840067637890
Selling Quantity:
1
Door Handing:
Non-handed
Strike Description:
Rectangle Strike
Box Weight (lbs):
4 lbs
Strike Number:
30-253
Box Depth (in):
4"
Country Of Origin:
Mexico
Keyway:
C Keyway
Deadbolt Throw (in):
1"
Base Material:
Brass Bronze
Latch Number:
30-253
Latch Dimensions:
1-1/8" x 2-1/4"
Manufacturer:
Dexter
Interior/Exterior:
Interior/Exterior
Uid:
DEX100DB1000SCT626KDC
Url Title:
db1000-sct-626-kdc
Title:
DB1000-SCT-626-KDC Dexter Deadlock
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Deadbolts
Last Modified:
2023-02-28T05:41:48+00:00
Last Pricing:
2023-02-24T00:00:00+00:00
Msrp:
107
Avg Lead Time:
14
Finish Family:
Matte Silver
Popularity:
3
Ul Listing:
ANSI A156.2 Series 4000, Grade 1, UL Listed
Limited Warranty:
5 Years
Fire Rated:
3 Hours {A}
Unit Of Measure:
Each
Vendor:
Allegion

Warranty Information

5 Year Warranty
