Corbin Russwin DL4111 626 LC Less Cylinder Satin Chrome

Corbin Russwin

Write a Review
SKU:
DL4111 626 LC
$185.84
Corbin Russwin DL4111 626 LC Less Cylinder Satin Chrome
$185.84

Descriptions

Mortise Deadbolt. Features Handing: Non-handed. Door Thickness: Standard- 1-3/4" (44mm). Optional door thicknesses available; see Quick Codes. Backset: 2-3/4" (70mm). Lockcase: Heavy wrought steel; zinc dichromate finish. Front: Brass, bronze, stainless steel. 4-5/8"(117mm) x 1-1/8" (29mm). Adjustable for flat or beveled doors (bevel adjustment 1/8"(3mm) in 2"(51mm). Deadbolt: Steel with hardened pin; 1" (25mm) throw. Strike: Standard: wrought brass or bronze, 3-1/2" (89mm) x 1-1/8" (29mm). Optional strikes available. Cylinder: 6-pin, L4 keyway, 0-bitted. Security cylinder optional; see Quick Codes. Keys: Two nickel silver standard. Keying Features Available: Master keying; Construction master keying; 7-pin (FC) conventional; Interchangeable core (IC); Security; Security (IC); Visual key control; Concealed key control; Pyramid (FC); Pyramid (IC) Warranty: One-year limited.
TypeTitleURL
catalogAlarm Lock Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/corbin/catalogs/ALA112U-Alarm-Lock-2019.pdf
Padlocks and Deadlocks Cataloghttps://dvwi9lnoau63q.cloudfront.net/corbin/catalogs/45012.pdf
installation-instructionsDL4100 Series Auxiliary Deadlock Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/corbin/installation-instructions/DL4100-instructions.pdf
DL4100 Series Ergonomic Thumbturn Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/corbin/installation-instructions/DL4100-ergo-install.pdf
price-book2023 Corbin Price Book (updated 10.2023)https://dvwi9lnoau63q.cloudfront.net/corbin/pricebooks/COR_pricebook_10-2023.pdf

Specifications

Brand:
Corbin Russwin
Application:
Operation by Key outside only
Series:
DL4100 Series Mortise Deadlocks
Parent Manufacturer:
Assa Abloy
Manufacturer:
Corbin Russwin
Backset (in):
2-3/4"
Base Material:
Brass or Bronze
Center Case Dimensions:
1-1/8" x 3-1/2"
Can Be Keyed:
Yes
Certification:
Underwriters UL Listed, A Label
Commercial/Residential:
Commercial
Door Handing:
Non-handed
Door Range (Thickness):
1-3/4" - 1-3/4"
Country of Origin:
Mexico
Deadbolt Throw (in):
1"
Cylinder Type:
Less Cylinder
Fire Rated:
3 Hours {A}
Electronic:
No
Finish Description:
Satin Chrome
Finish:
626/US26D
Function:
Cylinder Only
Latch Description:
Deadbolt
Interior/Exterior:
Interior/Exterior
Grade:
Not Graded
Includes Cylinder(s)?:
No
Keyway:
Not Applicable
Specifications Bullet 1:
Mortise Cylinder Only Function Deadbolt
Specifications Bullet 3:
2-3/4" Backset
Specifications Bullet 2:
Less Cylinder
Latch Dimensions:
1-1/8" x 4-5/8"
Specifications Bullet 4:
1-1/8" x 3-1/2" Square Corner Strike
Specifications Bullet 9:
1 Year Warranty
Specifications Bullet 6:
4-1/2" x 3-3/4" Pocket Dimension
Specifications Bullet 8:
Underwriters UL Listed, A Label
Specifications Bullet 7:
For Doors 1-3/4" Thick
Specifications Bullet 5:
1" Deadbolt Throw
Uid:
COR300DL4111626LC
Url Title:
dl4111-626-lc
Title:
DL4111 626 LC Corbin Russwin Deadlock
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Deadbolts
Last Modified:
2023-11-12T04:54:14+00:00
Last Pricing:
2023-04-17T00:00:00+00:00
Msrp:
283
Avg Lead Time:
5
Popularity:
9
Pack Weight:
1.6
Pack Length:
6
Pack Width:
4.25
Pack Height:
2.5
Pack Volume:
63.75
Limited Warranty:
1 Year
Unit Of Measure:
Each

Warranty Information

1 Year Warranty
