Kaba Simplex L8146R-26D-41 Mortise Combination Lever Lock Key Override Passage Lockout Sargent LFIC Prep Less Core Satin Chrome

Kaba Simplex

Write a Review
SKU:
L8146R-26D-41
$733.47
$733.47

Descriptions

Simplex mechanical pushbutton locks offer a convenient way to control access between public and private areas. There are no keys or cards to manage, no computers to program, no batteries to replace, and combinations can be changed in seconds without removing the lock from the door.
TypeTitleURL
catalogSimplex Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/dormakaba/guides/KABA_catalog_simplex.pdf
price-book2024 Simplex Parts Price Book (effective 1.2024)https://dvwi9lnoau63q.cloudfront.net/dormakaba/pricebooks/DORMA_pricebook_simplex-parts_1-2024.pdf
2024 Simplex Price Book (effective 1.2024)https://dvwi9lnoau63q.cloudfront.net/dormakaba/pricebooks/DORMA_pricebook_simplex_1-2024.pdf

Specifications

Brand:
Kaba Simplex
Manufacturer:
DormaKaba
Can Be Keyed:
Yes
Series:
Simplex 8100 Series
Parent Manufacturer:
DormaKaba
Door Handing:
Left Hand
Type:
Integrated and Pushbutton
ADA:
Yes
Base Material:
Brass or Bronze
Certification:
BHMA Grade 1, UL Listed, A Label
Finish:
626/US26D
Function:
Entrance, Passage
Keyway:
Less Core
Specifications Bullet 3:
Sargent LFIC Housing Less Core
Box Width (in):
10-1/2"
Audit Trails:
Not Applicable
Cylinder Type:
Sargent LFIC Housing
Maximum Door Thickness (in):
2-1/4"
Box Height (in):
8"
Product Width (in):
3-1/8"
Specifications Bullet 9:
BHMA Grade 1, UL Listed, A Label
Armor Front Dimensions:
1-1/4" x 8"
Commercial/Residential:
Commercial
Specifications Bullet 7:
3-1/8" x 7-3/8" Escutcheon Dimension
Specifications Bullet 4:
Single Access Code
Specifications Bullet 8:
For Doors 1-3/4" - 2-1/4" Thick
Latch Description:
Dead Latch
Electronic:
No
Pocket Dimensions:
6-5/8" x 4-1/2"
Product Height (in):
7-3/8"
Specifications Bullet 5:
Entrance, Passage Function
Box Weight (lbs):
12.5 lbs
Strike Description:
ASA Strike
Latch Throw (in):
3/4"
Interior/Exterior:
Interior/Exterior
Lever/Knob/Pull:
Lever
Specifications Bullet 1:
Grade 1 Mortise PIN Access Pushbutton Lockset
Door Range (Thickness):
1-3/4" - 2-1/4"
Includes Cylinder(s)?:
No
User Codes:
1
Country of Origin:
Mexico
Specifications Bullet 10:
3 Year Warranty
UPC:
840067622513
Finish Description:
Satin Chrome
Trademark Term:
Simplex
Grade:
Grade 1
Backset (in):
2-3/4"
Box Depth (in):
11"
Specifications Bullet 2:
ADA Lever
Product Warranty:
3 Year Warranty
Projection (in):
3-13/16"
Strike Dimensions:
1-1/4" x 4-7/8"
Lever/Knob/Pull Design:
ADA
Technology:
PIN Access
Rose/Escutcheon Dimensions (in):
3-1/8" x 7-3/8"
Minimum Door Thickness (in):
1-3/4"
UOM:
1
Specifications Bullet 6:
3-13/16" Projection
Selling Quantity:
1
Rose/Escutcheon:
Escutcheon
Uid:
SIM100L8146R26D41
Url Title:
l8146r-26d-41
Title:
L8146R-26D-41
Sub Type:
Mortise Locks with Keypad Trim
Last Modified:
2023-02-28T05:42:16+00:00
Last Pricing:
2022-09-30T00:00:00+00:00
Msrp:
905
Avg Lead Time:
27
Popularity:
3
Unit Of Measure:
Each

Warranty Information

3 Year Warranty
