Schlage L9010 03A 626 Grade 1 Passage Latch Mortise Lock 03 Lever A Rose Satin Chrome Finish Field Reversible

Schlage

Write a Review
SKU:
L9010 03A 626
$578.81
UPC:
810007502113
$578.81

Descriptions

Schlage L-Series Extra Heavy Duty Mortise Locks are built to withstand the rigors of daily use without fail. Our L9000 Series locks are ideal for use in schools, hospitals and factories, where the finest hardware must also deliver consistent, dependable operation and stand up to constant use and abuse. We pay attention to these details so you can focus on creating a functional and aesthetically pleasing environment for your clients. In fact, every one of our L-Series locks meets ANSI Grade 1 standards for safety. A multitude of functions, finishes and trim designs are available to meet virtually every security and aesthetic requirement.
TypeTitleURL
brochure/sales-materialSchlage Finishes Charthttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/ALLEGION_finish-chart.pdf
catalogL Series Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/Schlage_L_Series_Catalog_102899.pdf
data-sheetSchlage L Indicator Data Sheethttps://dvwi9lnoau63q.cloudfront.net/schlage/datasheets/Schlage_L_Series_Mechanical_Indicator_Data_Sheet_110453.pdf
installation-instructionsL Series Mounting Plate Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108302.pdf
L400 Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108267.pdf
L9000 Indicator Handing Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/111375.pdf
L9000 Indicator Lever w/ Escutcheon Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/110669.pdf
L9000 Indicator Lever w/ Sectional Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/110670.pdf
L9000 Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108367.pdf
L9000 Knob Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108380.pdf
Video: L9050 Mortise Lock Installationhttps://youtu.be/U6fUoLLH7Kw
parts-listSchlage L Series Parts Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/miscellaneous/SCH_parts-diagram_L-series.pdf
price-book2024 Schlage Commercial Price Book (effective 3.2024)https://dvwi9lnoau63q.cloudfront.net/schlage/pricebooks/SCH_pricebook_3-2024.pdf
service-manualSchlage L Series Service Manualhttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/106500.pdf

Specifications

Brand:
Schlage
Commercial Residential:
Commercial
Can Be Keyed:
No
Base Material:
Brass Bronze
ADA:
Yes
Cylinder Type:
Keyless
Specifications Bullet 3:
A Rose
Specifications Bullet 5:
1-1/4" x 4-7/8" ASA Strike
Specifications Bullet 4:
2-3/4" Backset
Product Warranty:
10 Year Warranty
Includes Cylinder(s)?:
No
Latch Dimensions:
1-1/4" x 8"
Deadbolt Throw (in):
Not Applicable
Specifications Bullet 13:
10 Year Warranty
Manufacturer:
Schlage
Minimum Door Thickness (in):
1-3/4"
Parent Manufacturer:
Allegion
Armor Front Dimensions:
1-1/4" x 8"
Maximum Door Thickness (in):
1-3/4"
Pocket Dimensions:
6-5/8" X 4-1/2"
Specifications Bullet 8:
3/4" Spring Latch
Specifications Bullet 12:
ANSI A156.13-2012, Series 1000, Grade 1, UL Listed
Backset (in):
2-3/4"
Country Of Origin:
Mexico
Finish:
626/US26D
Specifications Bullet 7:
2-1/8" Rose Dimension
Door Range (Thickness):
1-3/4" - 1-3/4"
UOM:
1
Electronic:
No
Fire Rated:
3 Hours {A}
Specifications Bullet 11:
For Doors 1-3/4" Thick
Strike Number:
10-072
Series:
L9000 Series Mortise Lock
Grade:
Grade 1
Certification:
ANSI A156.13-2012, Series 1000, Grade 1, UL Listed
Specifications Bullet 6:
2-13/16" Projection
Latch Throw (in):
3/4"
Specifications Bullet 1:
Grade 1 Passage Function Mortise Lockset
Keyway:
Not Applicable
Function:
Passage
Projection (in):
2-13/16"
Door Handing:
Non-handed
Rose/Escutcheon Design:
A
Strike Dimensions:
1-1/4" x 4-7/8"
Rose/Escutcheon Dimensions (in):
2-1/8"
Latch Description:
Spring Latch
Rose/Escutcheon:
Rose
UPC:
810007502113
Specifications Bullet 2:
03 Lever
Interior/Exterior:
Interior/Exterior
Finish Description:
Satin Chrome
Strike Description:
ASA Strike
Specifications Bullet 10:
6-5/8" X 4-1/2" Pocket Dimension
Lever/Knob/Pull Design:
3
Specifications Bullet 9:
1-1/8" x 8" Faceplate Dimension
Selling Quantity:
1
Lever/Knob/Pull:
Lever
Uid:
SCH100L901003A626
Url Title:
l9010-03a-626
Title:
L9010 03A 626 Schlage Mortise Lock
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Mortise Lock
Last Modified:
2023-02-28T05:31:26+00:00
Last Pricing:
2023-02-24T00:00:00+00:00
Msrp:
837
Avg Lead Time:
35
Finish Family:
Matte Silver
Popularity:
5
Pack Weight:
6.3
Pack Length:
10.375
Pack Width:
5.375
Pack Height:
5.625
Pack Volume:
313.6816406
Ul Listing:
UL Listed
Ansi Code:
A156.13-2017 Series 1000, Grade 1
Baa Qualified:
Yes
Limited Warranty:
3 Years
Unit Of Measure:
Each
Unit Of Measure 2:
CASE
Unit Of Measure 2 Qty:
6
Vendor:
Allegion
Assembly Item:
1

Warranty Information

10 Year Warranty
