Schlage L9010 07A 605 Grade 1 Passage Latch Mortise Lock 07 Lever A Rose Bright Brass Finish Field Reversible

Schlage

Write a Review
SKU:
L9010 07A 605
$659.52
UPC:
840067640173
$659.52

Descriptions

Schlage L-Series Extra Heavy Duty Mortise Locks are built to withstand the rigors of daily use without fail. Our L9000 Series locks are ideal for use in schools, hospitals and factories, where the finest hardware must also deliver consistent, dependable operation and stand up to constant use and abuse. We pay attention to these details so you can focus on creating a functional and aesthetically pleasing environment for your clients. In fact, every one of our L-Series locks meets ANSI Grade 1 standards for safety. A multitude of functions, finishes and trim designs are available to meet virtually every security and aesthetic requirement.
TypeTitleURL
brochure/sales-materialSchlage Finishes Charthttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/ALLEGION_finish-chart.pdf
catalogL Series Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/Schlage_L_Series_Catalog_102899.pdf
data-sheetSchlage L Indicator Data Sheethttps://dvwi9lnoau63q.cloudfront.net/schlage/datasheets/Schlage_L_Series_Mechanical_Indicator_Data_Sheet_110453.pdf
installation-instructionsL Series Mounting Plate Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108302.pdf
L400 Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108267.pdf
L9000 Indicator Handing Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/111375.pdf
L9000 Indicator Lever w/ Escutcheon Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/110669.pdf
L9000 Indicator Lever w/ Sectional Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/110670.pdf
L9000 Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108367.pdf
L9000 Knob Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108380.pdf
Video: L9050 Mortise Lock Installationhttps://youtu.be/U6fUoLLH7Kw
parts-listSchlage L Series Parts Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/miscellaneous/SCH_parts-diagram_L-series.pdf
price-book2024 Schlage Commercial Price Book (effective 3.2024)https://dvwi9lnoau63q.cloudfront.net/schlage/pricebooks/SCH_pricebook_3-2024.pdf
service-manualSchlage L Series Service Manualhttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/106500.pdf

Specifications

Brand:
Schlage
Parent Manufacturer:
Allegion
Manufacturer:
Schlage
Base Material:
Brass
ADA:
Yes
Armor Front Dimensions:
1-1/4" x 8"
Can Be Keyed:
No
Series:
L9000 Series Mortise Lock
Backset (in):
2-3/4"
Certification:
ANSI A156.13-2012, Series 1000, Grade 1, UL Listed
Commercial Residential:
Commercial
Deadbolt Throw (in):
Not Applicable
Country Of Origin:
Mexico
Door Range (Thickness):
1-3/4" - 1-3/4"
Electronic:
No
Function:
Passage
Cylinder Type:
Keyless
Fire Rated:
3 Hours {A}
Finish:
605/US3
Finish Description:
Bright Brass
Door Handing:
Non-handed
Lever/Knob/Pull Design:
7
Latch Throw (in):
3/4"
Interior/Exterior:
Interior/Exterior
Specifications Bullet 1:
Grade 1 Passage Function Mortise Lockset
Grade:
Grade 1
Includes Cylinder(s)?:
No
Keyway:
Not Applicable
Latch Description:
Spring Latch
Lever/Knob/Pull:
Lever
Latch Dimensions:
1-1/4" x 8"
Specifications Bullet 4:
2-3/4" Backset
Specifications Bullet 6:
2-7/8" Projection
Specifications Bullet 10:
6-5/8" X 4-1/2" Pocket Dimension
Specifications Bullet 7:
2-1/8" Rose Dimension
Specifications Bullet 8:
3/4" Spring Latch
Specifications Bullet 11:
For Doors 1-3/4" Thick
Specifications Bullet 9:
1-1/8" x 8" Faceplate Dimension
Specifications Bullet 5:
1-1/4" x 4-7/8" ASA Strike
Specifications Bullet 3:
A Rose
Specifications Bullet 2:
07 Lever
Maximum Door Thickness (in):
1-3/4"
Projection (in):
2-7/8"
Rose/Escutcheon:
Rose
Rose/Escutcheon Design:
A
Specifications Bullet 12:
ANSI A156.13-2012, Series 1000, Grade 1, UL Listed
Minimum Door Thickness (in):
1-3/4"
Pocket Dimensions:
6-5/8" X 4-1/2"
Rose/Escutcheon Dimensions (in):
2-1/8"
Specifications Bullet 13:
10 Year Warranty
Product Warranty:
10 Year Warranty
UOM:
1
UPC:
840067640173
Selling Quantity:
1
Strike Description:
ASA Strike
Strike Dimensions:
1-1/4" x 4-7/8"
Strike Number:
10-072
Uid:
SCH100L901007A605
Url Title:
l9010-07a-605
Title:
L9010 07A 605 Schlage Mortise Lock
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Mortise Lock
Last Modified:
2023-02-28T05:31:31+00:00
Last Pricing:
2023-02-24T00:00:00+00:00
Msrp:
959
Avg Lead Time:
24
Finish Family:
Polished Brass
Popularity:
9
Pack Weight:
6.3
Pack Length:
10.375
Pack Width:
5.375
Pack Height:
5.625
Pack Volume:
313.6816406
Ul Listing:
UL Listed
Ansi Code:
A156.13-2017 Series 1000, Grade 1
Baa Qualified:
Yes
Limited Warranty:
3 Years
Unit Of Measure:
Each
Unit Of Measure 2:
CASE
Unit Of Measure 2 Qty:
6
Vendor:
Allegion
Assembly Item:
1

Warranty Information

10 Year Warranty
