Schlage L9010 07A 630 Grade 1 Passage Latch Mortise Lock 07 Lever A Rose Satin Stainless Steel Finish Field Reversible

Schlage

Write a Review
SKU:
L9010 07A 630
$671.42
UPC:
840067640227
$671.42

Descriptions

Schlage L-Series Extra Heavy Duty Mortise Locks are built to withstand the rigors of daily use without fail. Our L9000 Series locks are ideal for use in schools, hospitals and factories, where the finest hardware must also deliver consistent, dependable operation and stand up to constant use and abuse. We pay attention to these details so you can focus on creating a functional and aesthetically pleasing environment for your clients. In fact, every one of our L-Series locks meets ANSI Grade 1 standards for safety. A multitude of functions, finishes and trim designs are available to meet virtually every security and aesthetic requirement.
TypeTitleURL
brochure/sales-materialSchlage Finishes Charthttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/ALLEGION_finish-chart.pdf
catalogL Series Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/Schlage_L_Series_Catalog_102899.pdf
data-sheetSchlage L Indicator Data Sheethttps://dvwi9lnoau63q.cloudfront.net/schlage/datasheets/Schlage_L_Series_Mechanical_Indicator_Data_Sheet_110453.pdf
installation-instructionsL Series Mounting Plate Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108302.pdf
L400 Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108267.pdf
L9000 Indicator Handing Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/111375.pdf
L9000 Indicator Lever w/ Escutcheon Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/110669.pdf
L9000 Indicator Lever w/ Sectional Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/110670.pdf
L9000 Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108367.pdf
L9000 Knob Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108380.pdf
Video: L9050 Mortise Lock Installationhttps://youtu.be/U6fUoLLH7Kw
parts-listSchlage L Series Parts Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/miscellaneous/SCH_parts-diagram_L-series.pdf
price-book2024 Schlage Commercial Price Book (effective 3.2024)https://dvwi9lnoau63q.cloudfront.net/schlage/pricebooks/SCH_pricebook_3-2024.pdf
service-manualSchlage L Series Service Manualhttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/106500.pdf

Specifications

Brand:
Schlage
Interior/Exterior:
Interior/Exterior
Fire Rated:
3 Hours {A}
Door Handing:
Non-handed
Lever/Knob/Pull Design:
7
Deadbolt Throw (in):
Not Applicable
Certification:
ANSI A156.13-2012, Series 1000, Grade 1, UL Listed
Specifications Bullet 10:
6-5/8" X 4-1/2" Pocket Dimension
Specifications Bullet 9:
1-1/8" x 8" Faceplate Dimension
ADA:
Yes
Specifications Bullet 4:
2-3/4" Backset
Base Material:
Stainless Steel
Specifications Bullet 7:
2-1/8" Rose Dimension
Cylinder Type:
Keyless
Specifications Bullet 3:
A Rose
Commercial Residential:
Commercial
Latch Throw (in):
3/4"
Function:
Passage
Maximum Door Thickness (in):
1-3/4"
Electronic:
No
Specifications Bullet 1:
Grade 1 Passage Function Mortise Lockset
Minimum Door Thickness (in):
1-3/4"
Specifications Bullet 11:
For Doors 1-3/4" Thick
Manufacturer:
Schlage
Lever/Knob/Pull:
Lever
Specifications Bullet 8:
3/4" Spring Latch
Includes Cylinder(s)?:
No
Specifications Bullet 5:
1-1/4" x 4-7/8" ASA Strike
Parent Manufacturer:
Allegion
Latch Description:
Spring Latch
Keyway:
Not Applicable
Product Warranty:
10 Year Warranty
Specifications Bullet 13:
10 Year Warranty
Backset (in):
2-3/4"
Can Be Keyed:
No
Finish Description:
Satin Stainless Steel
Grade:
Grade 1
Specifications Bullet 6:
2-7/8" Projection
Country Of Origin:
Mexico
Rose/Escutcheon:
Rose
Specifications Bullet 12:
ANSI A156.13-2012, Series 1000, Grade 1, UL Listed
Armor Front Dimensions:
1-1/4" x 8"
Finish:
630/US32D
Pocket Dimensions:
6-5/8" X 4-1/2"
Rose/Escutcheon Dimensions (in):
2-1/8"
Rose/Escutcheon Design:
A
Door Range (Thickness):
1-3/4" - 1-3/4"
Selling Quantity:
1
Specifications Bullet 2:
07 Lever
Latch Dimensions:
1-1/4" x 8"
Projection (in):
2-7/8"
Strike Description:
ASA Strike
Strike Dimensions:
1-1/4" x 4-7/8"
UPC:
840067640227
Series:
L Series
Strike Number:
10-072
UOM:
1
Uid:
SCH100L901007A630
Url Title:
l9010-07a-630
Title:
L9010 07A 630 Schlage Mortise Lock
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Mortise Lock
Series:
L9000 Series Mortise Lock
Last Modified:
2023-02-28T05:31:31+00:00
Last Pricing:
2023-02-24T00:00:00+00:00
Msrp:
977
Avg Lead Time:
53
Finish Family:
Matte Silver
Popularity:
5
Pack Weight:
6.3
Pack Length:
10.375
Pack Width:
5.375
Pack Height:
5.625
Pack Volume:
313.6816406
Ul Listing:
UL Listed
Ansi Code:
A156.13-2017 Series 1000, Grade 1
Baa Qualified:
Yes
Limited Warranty:
3 Years
Unit Of Measure:
Each
Unit Of Measure 2:
CASE
Unit Of Measure 2 Qty:
6
Vendor:
Allegion
Assembly Item:
1

Warranty Information

10 Year Warranty
