Sargent LC-8238 LNE 26D Grade 1 Classroom Security Intruder Latchbolt Mortise Lock E - Lever LN - Rose Field Reversible Less Cylinder ASA Strike Satin Chrome

Sargent

Write a Review
SKU:
LC-8238 LNE 26D
$842.59
Sargent LC-8238 LNE 26D Grade 1 Classroom Security Intruder Latchbolt Mortise Lock E - Lever LN - Rose Field Reversible Less Cylinder ASA Strike Satin Chrome
$842.59

Descriptions

When it comes to strength and durability, SARGENT continues to set standards with the 8200 Mortise lock. The 8200 far surpasses ANSI/BHMA A156.13 Series 1000 Grade 1 standards, making it the strongest and most durable mortise lock in the industry. SARGENT Mortise Locks are designed and constructed with high quality components to provide maximum security, performance and durability
TypeTitleURL
catalogSargent 7800/8200 Series Mortise Locks Cataloghttps://dvwi9lnoau63q.cloudfront.net/sargent/catalog/SARGENT_Mortise_Lock_78008200_Series_Catalog.pdf
Sargent Healthcare Hardware Cataloghttps://dvwi9lnoau63q.cloudfront.net/sargent/catalog/SARGENT_Speciality_Hardware_Catalog.pdf
installation-instructions7800/8200 Series Mortise Lock w/Sectional Trim & V Series Indicators Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/7800-8200_Series_Mortise_Lock_w_Sectional_Trim__V_Series_Indicators.pdf
7800/8200 Series Mortise Lock w/VN1 Escutcheon Trim & V Series Indicators Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/7800-8200_Series_Mortise_Lock_w_VN1_Escutcheon_Trim__V_Series_Indicators_Installatio_Instructions.pdf
7800/8200 Series Mortise Locks Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/7800Knob8200LeverMortiseLockEscutcheonRoseTrim.pdf
7900/8200 Series Mortise Locks Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/sargent/instruction-sheets/8200installationA8202A.pdf
Video: 8200 Series Mortise Lock Installationhttps://youtu.be/DWRY72iLKN4
literatureSargent 8200 Series Environmental Product Declaration (EPD)https://dvwi9lnoau63q.cloudfront.net/sargent/literature/133.1_ASSA_ABLOY_mrEPD_Sargent8200SeriesMortiseElectrified.pdf
sell-sheetSargent 8200 Series Mortise Locks Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/sargent/sell-sheet/8200sellsheetv7.pdf

Specifications

Brand:
Sargent
ADA:
Yes
Series:
8200 Line Lever Mortise Locks
Manufacturer:
Sargent
Armor Front Dimensions:
1-1/4" x 8"
Parent Manufacturer:
Assa Abloy
Base Material:
Brass Bronze
Can Be Keyed:
Yes
Backset (in):
2-3/4"
Commercial/Residential:
Commercial
Certification:
ANSI A156.13, Series 1000, Grade 1, A117.1, UL Listed
Door Range (Thickness):
1-3/4" - 1-3/4"
Country Of Origin:
USA
Door Handing:
Non-handed
Cylinder Type:
Less Cylinder
Deadbolt Throw (in):
Not Applicable
Finish Description:
Satin Chrome
Electronic:
No
Fire Rated:
2 Hours {B}
Finish:
626/US26D
Function:
Classroom Security Intruder
Interior/Exterior:
Interior/Exterior
Latch Description:
Dead Latch
Keyway:
Not Applicable
Grade:
Grade 1
Includes Cylinder(s)?:
No
Latch Dimensions:
1-1/4" x 8"
Lever/Knob/Pull:
Lever
Lever/Knob/Pull Design:
E
Specifications Bullet 1:
Grade 1 Classroom Security Intruder Function Mortise Lockset
Latch Throw (in):
3/4"
Specifications Bullet 3:
Less Cylinder
Specifications Bullet 5:
2-3/4" Backset
Specifications Bullet 4:
LN Rose
Specifications Bullet 2:
E Lever
Specifications Bullet 6:
1-1/4" x 4-7/8" ASA Strike
Uid:
SAR100LC8238LNE26D
Url Title:
lc-8238-lne-26d
Last Modified:
2023-11-08T11:09:58+00:00
Last Pricing:
2023-04-17T00:00:00+00:00
Msrp:
1268
Title:
LC-8238 LNE 26D Sargent Manufacturing Mortise Lock
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Mortise Lock
Last Modified:
2023-02-13T12:05:58+00:00
Last Pricing:
2022-09-16T00:00:00+00:00
Msrp:
1185
Popularity:
8
Pack Weight:
6.1
Pack Length:
9.25
Pack Width:
5.625
Pack Height:
4.375
Pack Volume:
227.6367188
Baa Qualified:
Yes
Limited Warranty:
10 Years
Unit Of Measure:
Each
Assembly Item:
1

Warranty Information

10 Year Warranty
