Kaba Simplex LL1021M-26D-41 Pushbutton Cylindrical Lever Lock Combination Entry Function with Key Override 2-3/4 Backset 1/2 Throw Latch Medeco/Yale/ASSA/Abloy LFIC Prep Less Core Satin Chrome Finish Left Hand/Left Hand Reverse

Kaba Simplex

Write a Review
SKU:
LL1021M-26D-41
$621.41
Kaba Simplex LL1021M-26D-41 Pushbutton Cylindrical Lever Lock Combination Entry Function with Key Override 2-3/4 Backset 1/2 Throw Latch Medeco/Yale/ASSA/Abloy LFIC Prep Less Core Satin Chrome Finish Left Hand/Left Hand Reverse
UPC:
810007502434
$621.41

Descriptions

Simplex mechanical pushbutton locks offer a convenient way to control access between public and private areas. There are no keys or cards to manage, no computers to program, no batteries to replace, and combinations can be changed in seconds without removing the lock from the door.
TypeTitleURL
catalogSimplex Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/dormakaba/guides/KABA_catalog_simplex.pdf
price-book2024 Simplex Parts Price Book (effective 1.2024)https://dvwi9lnoau63q.cloudfront.net/dormakaba/pricebooks/DORMA_pricebook_simplex-parts_1-2024.pdf
2024 Simplex Price Book (effective 1.2024)https://dvwi9lnoau63q.cloudfront.net/dormakaba/pricebooks/DORMA_pricebook_simplex_1-2024.pdf
videoSimplex 1000 / L1000 - How to Reset Unknown Combination - New Style Chamberhttps://youtu.be/J4avWH1mlEc

Specifications

Brand:
Kaba Simplex
Base Material:
Brass or Bronze
Specifications Bullet 15:
3 Year Warranty
Minimum Stile (in):
5"
Commercial Residential:
Commercial
Certification:
BMHA Certified Grade 1, UL Listed
Latch Throw (in):
1/2"
Finish Description:
Satin Chrome
Country of Origin:
Mexico
ADA:
Yes
Finish:
626/US26D
Door Range (Thickness):
1-3/8" - 2-1/4"
Lever/Knob/Pull Design:
ADA
Latch Dimensions:
1-1/8" x 2-1/4"
Grade:
Grade 1
Specifications Bullet 2:
ADA Lever
Lever/Knob/Pull:
Lever
Keyway:
Less Core
Cylinder Type:
Medeco LFIC Housing
Specifications Bullet 14:
BMHA Certified Grade 1, UL Listed
Product Width (in):
3-1/8"
Series:
Simplex L1000 Series
Specifications Bullet 7:
Single Access Code
Electronic:
No
Minimum Door Thickness (in):
1-3/8"
Bore Hole Diameter (in):
2-1/8"
Specifications Bullet 4:
2-3/4" Backset
Specifications Bullet 3:
Medeco LFIC Housing Less Core
Latch Bore Diameter (in):
1"
Can Be Keyed:
Yes
Specifications Bullet 8:
5" Minimum Stile
Backset (in):
2-3/4"
Product Height (in):
7-3/8"
Rose/Escutcheon:
Escutcheon
Specifications Bullet 10:
3-1/8" x 8-7/8" Escutcheon Dimension
Projection (in):
3-13/16"
Product Warranty:
3 Year Warranty
Maximum Door Thickness (in):
2-1/4"
Specifications Bullet 13:
For Doors 1-3/8" - 2-1/4" Thick
Parent Manufacturer:
DormaKaba
Specifications Bullet 12:
1/2" Latch Throw
Latch Description:
Dead Latch
Door Handing:
Left Hand
Specifications Bullet 5:
1-1/4" x 4-7/8" ASA Strike
Function:
Entrance
Specifications Bullet 9:
3-13/16" Projection
Rose/Escutcheon Dimensions (in):
3-1/8" x 8-7/8"
Strike Description:
ASA Strike
Includes Cylinder(s)?:
No
Specifications Bullet 11:
1-1/8" x 2-1/4" Dead Latch
Specifications Bullet 1:
Grade 1 Cylindrical Single Access Code Pushbutton Lockset
Technology:
Single Access Code
Specifications Bullet 6:
Entrance Function
UOM:
1
Type:
Mechanical Pushbutton
UPC:
810007502434
User Codes:
1
Manufacturer:
Kaba Simplex
Strike Dimensions:
1-1/4" x 4-7/8"
Uid:
SIM100LL1021M26D41
Url Title:
ll1021m-26d-41
Title:
LL1021M-26D-41
Type:
Integrated and Pushbutton
Sub Type:
Cylindrical Locks with Keypad Trim
Manufacturer:
DormaKaba
Last Modified:
2023-02-28T07:02:32+00:00
Last Pricing:
2022-09-30T00:00:00+00:00
Msrp:
773
Avg Lead Time:
38
Finish Family:
Matte Silver
Popularity:
3
Pack Weight:
9
Limited Warranty:
3 Years
Fire Rated:
3 Hours {A}
Accessible:
Yes
Unit Of Measure:
Each
Vendor:
DormaKaba

Warranty Information

3 Year Warranty
