Kaba Simplex LL1021S-26D-41 Pushbutton Cylindrical Lever Lock Combination Entry Function with Key Override 2-3/4 Backset 1/2 Throw Latch Schlage FSIC Prep Less Core Satin Chrome Finish Left Hand/Left Hand Reverse

Kaba Simplex

Write a Review
SKU:
LL1021S-26D-41
$602.58
Kaba Simplex LL1021S-26D-41 Pushbutton Cylindrical Lever Lock Combination Entry Function with Key Override 2-3/4 Backset 1/2 Throw Latch Schlage FSIC Prep Less Core Satin Chrome Finish Left Hand/Left Hand Reverse
UPC:
810007502458
$602.58

Descriptions

Simplex mechanical pushbutton locks offer a convenient way to control access between public and private areas. There are no keys or cards to manage, no computers to program, no batteries to replace, and combinations can be changed in seconds without removing the lock from the door.
TypeTitleURL
catalogSimplex Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/dormakaba/guides/KABA_catalog_simplex.pdf
price-book2024 Simplex Parts Price Book (effective 1.2024)https://dvwi9lnoau63q.cloudfront.net/dormakaba/pricebooks/DORMA_pricebook_simplex-parts_1-2024.pdf
2024 Simplex Price Book (effective 1.2024)https://dvwi9lnoau63q.cloudfront.net/dormakaba/pricebooks/DORMA_pricebook_simplex_1-2024.pdf
videoSimplex 1000 / L1000 - How to Reset Unknown Combination - New Style Chamberhttps://youtu.be/J4avWH1mlEc

Specifications

Brand:
Kaba Simplex
Finish Description:
Satin Chrome
Specifications Bullet 8:
5" Minimum Stile
Finish:
626/US26D
Country of Origin:
Mexico
Minimum Door Thickness (in):
1-3/8"
Specifications Bullet 12:
1/2" Latch Throw
Lever/Knob/Pull:
Lever
Latch Dimensions:
1-1/8" x 2-1/4"
Cylinder Type:
Schlage LFIC Housing
Maximum Door Thickness (in):
2-1/4"
Rose/Escutcheon:
Escutcheon
Grade:
Grade 1
Commercial Residential:
Commercial
Specifications Bullet 4:
2-3/4" Backset
Specifications Bullet 1:
Grade 1 Cylindrical Single Access Code Pushbutton Lockset
Specifications Bullet 10:
3-1/8" x 8-7/8" Escutcheon Dimension
Latch Description:
Dead Latch
Specifications Bullet 14:
BMHA Certified Grade 1, UL Listed
Specifications Bullet 3:
Schlage LFIC Housing Less Core
Electronic:
No
Specifications Bullet 2:
ADA Lever
Door Range (Thickness):
1-3/8" - 2-1/4"
Specifications Bullet 13:
For Doors 1-3/8" - 2-1/4" Thick
Function:
Entrance
Projection (in):
3-13/16"
Specifications Bullet 9:
3-13/16" Projection
Lever/Knob/Pull Design:
ADA
Keyway:
Less Core
Specifications Bullet 15:
3 Year Warranty
Specifications Bullet 7:
Single Access Code
Product Warranty:
3 Year Warranty
Specifications Bullet 11:
1-1/8" x 2-1/4" Dead Latch
Latch Throw (in):
1/2"
Specifications Bullet 5:
1-1/4" x 4-7/8" ASA Strike
Includes Cylinder(s)?:
No
Specifications Bullet 6:
Entrance Function
Strike Description:
ASA Strike
Latch Bore Diameter (in):
1"
Type:
Integrated and Pushbutton
Strike Dimensions:
1-1/4" x 4-7/8"
Manufacturer:
DormaKaba
Minimum Stile (in):
5"
Backset (in):
2-3/4"
Can Be Keyed:
Yes
Product Width (in):
3-1/8"
Rose/Escutcheon Dimensions (in):
3-1/8" x 8-7/8"
Certification:
BMHA Certified Grade 1, UL Listed
Product Height (in):
7-3/8"
Series:
Simplex L1000 Series
Door Handing:
Left Hand
Technology:
Single Access Code
ADA:
Yes
UOM:
1
Parent Manufacturer:
DormaKaba
Base Material:
Brass Bronze
User Codes:
1
Bore Hole Diameter (in):
2-1/8"
UPC:
810007502458
Uid:
SIM100LL1021S26D41
Url Title:
ll1021s-26d-41
Title:
LL1021S-26D-41
Sub Type:
Cylindrical Locks with Keypad Trim
Last Modified:
2023-02-28T07:02:32+00:00
Last Pricing:
2022-09-30T00:00:00+00:00
Msrp:
773
Avg Lead Time:
43
Finish Family:
Matte Silver
Popularity:
3
Pack Weight:
9
Limited Warranty:
3 Years
Fire Rated:
3 Hours {A}
Accessible:
Yes
Unit Of Measure:
Each
Base Material:
Brass or Bronze
Vendor:
DormaKaba

Warranty Information

3 Year Warranty
