Kaba Simplex LR1021S-026-41 Pushbutton Cylindrical Lever Lock Combination Entry Function with Key Override 2-3/4 Backset 1/2 Throw Latch Schlage FSIC Prep Less Core Bright Chrome Finish Right Hand/Right Hand Reverse

Kaba Simplex

Write a Review
SKU:
LR1021S-026-41
$646.07
Kaba Simplex LR1021S-026-41 Pushbutton Cylindrical Lever Lock Combination Entry Function with Key Override 2-3/4 Backset 1/2 Throw Latch Schlage FSIC Prep Less Core Bright Chrome Finish Right Hand/Right Hand Reverse
UPC:
840067622957
$646.07

Descriptions

Simplex mechanical pushbutton locks offer a convenient way to control access between public and private areas. There are no keys or cards to manage, no computers to program, no batteries to replace, and combinations can be changed in seconds without removing the lock from the door.
TypeTitleURL
catalogSimplex Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/dormakaba/guides/KABA_catalog_simplex.pdf
price-book2024 Simplex Parts Price Book (effective 1.2024)https://dvwi9lnoau63q.cloudfront.net/dormakaba/pricebooks/DORMA_pricebook_simplex-parts_1-2024.pdf
2024 Simplex Price Book (effective 1.2024)https://dvwi9lnoau63q.cloudfront.net/dormakaba/pricebooks/DORMA_pricebook_simplex_1-2024.pdf
videoSimplex 1000 / L1000 - How to Reset Unknown Combination - New Style Chamberhttps://youtu.be/J4avWH1mlEc

Specifications

Brand:
Kaba Simplex
Country of Origin:
Mexico
Certification:
BMHA Certified Grade 1, UL Listed
ADA:
Yes
Specifications Bullet 1:
Grade 1 Cylindrical Single Access Code Pushbutton Lockset
Box Depth (in):
11"
Finish:
625/US26
Rose/Escutcheon Dimensions (in):
3-1/8" x 8-7/8"
UPC:
840067622957
Specifications Bullet 6:
Entrance Function
Box Width (in):
10-1/2"
Lever/Knob/Pull:
Lever
Manufacturer:
DormaKaba
Parent Manufacturer:
DormaKaba
Box Height (in):
8"
Electronic:
No
Specifications Bullet 10:
3-1/8" x 8-7/8" Escutcheon Dimension
Specifications Bullet 13:
For Doors 1-3/8" - 2-1/4" Thick
Specifications Bullet 2:
ADA Lever
Backset (in):
2-3/4"
Commercial Residential:
Commercial
Latch Throw (in):
1/2"
Minimum Door Thickness (in):
1-3/8"
Latch Bore Diameter (in):
1"
Specifications Bullet 14:
BMHA Certified Grade 1, UL Listed
Function:
Entrance
Product Warranty:
3 Year Warranty
Includes Cylinder(s)?:
No
Specifications Bullet 11:
1-1/8" x 2-1/4" Dead Latch
Specifications Bullet 7:
Single Access Code
Can Be Keyed:
Yes
Specifications Bullet 3:
Schlage LFIC Housing Less Core
Base Material:
Brass or Bronze
Specifications Bullet 15:
3 Year Warranty
Rose/Escutcheon:
Escutcheon
Specifications Bullet 12:
1/2" Latch Throw
Specifications Bullet 8:
5" Minimum Stile
Latch Dimensions:
1-1/8" x 2-1/4"
Bore Hole Diameter (in):
2-1/8"
Specifications Bullet 5:
1-1/4" x 4-7/8" ASA Strike
Selling Quantity:
1
Door Range (Thickness):
1-3/8" - 2-1/4"
Door Handing:
Right Hand
Product Width (in):
3-1/8"
Specifications Bullet 9:
3-13/16" Projection
Cylinder Type:
Schlage LFIC Housing
Technology:
Single Access Code
Box Weight (lbs):
10.5 lbs
Latch Description:
Dead Latch
User Codes:
1
Product Height (in):
7-3/8"
Type:
Mechanical Pushbutton
Grade:
Grade 1
Keyway:
Less Core
Finish Description:
Bright Chrome
Minimum Stile (in):
5"
Series:
1000 Series
Specifications Bullet 4:
2-3/4" Backset
Lever/Knob/Pull Design:
ADA
Projection (in):
3-13/16"
Strike Description:
ASA Strike
UOM:
1
Maximum Door Thickness (in):
2-1/4"
Strike Dimensions:
1-1/4" x 4-7/8"

Warranty Information

3 Year Warranty
