Kaba Simplex LR1031-03-41 Pushbutton Cylindrical Lever Lock Combination Entry/Passage Functions 2-3/4 Backset 1/2 Throw Latch Bright Brass Finish Right Hand/Right Hand Reverse

Kaba Simplex

Write a Review
SKU:
LR1031-03-41
$625.06
Kaba Simplex LR1031-03-41 Pushbutton Cylindrical Lever Lock Combination Entry/Passage Functions 2-3/4 Backset 1/2 Throw Latch Bright Brass Finish Right Hand/Right Hand Reverse
UPC:
840067622988
$625.06

Descriptions

Simplex mechanical pushbutton locks offer a convenient way to control access between public and private areas. There are no keys or cards to manage, no computers to program, no batteries to replace, and combinations can be changed in seconds without removing the lock from the door.
TypeTitleURL
catalogSimplex Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/dormakaba/guides/KABA_catalog_simplex.pdf
price-book2024 Simplex Parts Price Book (effective 1.2024)https://dvwi9lnoau63q.cloudfront.net/dormakaba/pricebooks/DORMA_pricebook_simplex-parts_1-2024.pdf
2024 Simplex Price Book (effective 1.2024)https://dvwi9lnoau63q.cloudfront.net/dormakaba/pricebooks/DORMA_pricebook_simplex_1-2024.pdf
videoSimplex 1000 / L1000 - How to Reset Unknown Combination - New Style Chamberhttps://youtu.be/J4avWH1mlEc

Specifications

Brand:
Kaba Simplex
Specifications Bullet 3:
2-3/4" Backset
ADA:
Yes
Specifications Bullet 7:
5" Minimum Stile
Backset (in):
2-3/4"
Product Width (in):
3-1/8"
Latch Dimensions:
1-1/8" x 2-1/4"
Certification:
BMHA Certified Grade 1, UL Listed
Base Material:
Brass
Latch Description:
Dead Latch
Door Range (Thickness):
1-3/8" - 2-1/4"
Lever/Knob/Pull:
Lever
Bore Hole Diameter (in):
2-1/8"
Specifications Bullet 9:
3-1/8" x 8-7/8" Escutcheon Dimension
Box Weight (lbs):
10.5 lbs
Grade:
Grade 1
Box Depth (in):
11"
Parent Manufacturer:
DormaKaba
Latch Bore Diameter (in):
1"
Specifications Bullet 4:
1-1/4" x 4-7/8" ASA Strike
Country of Origin:
Mexico
Specifications Bullet 6:
Single Access Code
Can Be Keyed:
No
Specifications Bullet 8:
3-13/16" Projection
Electronic:
No
Box Width (in):
10-1/2"
Specifications Bullet 13:
BMHA Certified Grade 1, UL Listed
Latch Throw (in):
1/2"
Finish Description:
Bright Brass
Keyway:
Not Applicable
Includes Cylinder(s)?:
No
Box Height (in):
8"
Cylinder Type:
Keyless
Finish:
605/US3
Specifications Bullet 11:
1/2" Latch Throw
Specifications Bullet 1:
Grade 1 Cylindrical Single Access Code Pushbutton Lockset
Commercial Residential:
Commercial
Lever/Knob/Pull Design:
ADA
Maximum Door Thickness (in):
2-1/4"
Projection (in):
3-13/16"
User Codes:
1
Specifications Bullet 14:
3 Year Warranty
Minimum Stile (in):
5"
Minimum Door Thickness (in):
1-3/8"
Strike Description:
ASA Strike
Rose/Escutcheon:
Escutcheon
Product Warranty:
3 Year Warranty
Selling Quantity:
1
Type:
Integrated and Pushbutton
Product Height (in):
7-3/8"
Function:
Entrance, Passage
Door Handing:
Right Hand
Specifications Bullet 5:
Entrance, Passage Function
Specifications Bullet 10:
1-1/8" x 2-1/4" Dead Latch
Specifications Bullet 12:
For Doors 1-3/8" - 2-1/4" Thick
Specifications Bullet 2:
ADA Lever
Rose/Escutcheon Dimensions (in):
3-1/8" x 8-7/8"
Strike Dimensions:
1-1/4" x 4-7/8"
Manufacturer:
Kaba Simplex
UPC:
840067622988
Series:
1000 Series
UOM:
1
Technology:
Single Access Code
Uid:
SIM100LR10310341
Url Title:
lr1031-03-41
Title:
LR1031-03-41
Sub Type:
Cylindrical Locks with Keypad Trim
Manufacturer:
DormaKaba
Series:
Simplex L1000 Series
Last Modified:
2023-02-28T07:02:34+00:00
Last Pricing:
2022-09-30T00:00:00+00:00
Msrp:
778
Avg Lead Time:
258
Finish Family:
Polished Brass
Popularity:
9
Pack Weight:
9.3
Limited Warranty:
3 Years
Fire Rated:
3 Hours {A}
Accessible:
Yes
Unit Of Measure:
Each
Vendor:
DormaKaba

Warranty Information

3 Year Warranty
