Securitron M38 Maglock 600lbs Holding Force Bracket Mount 12/24VDC Satin Aluminum Clear Anodized

Securitron

Write a Review
SKU:
M38
$412.07
Securitron M38 Maglock 600lbs Holding Force Bracket Mount 12/24VDC Satin Aluminum Clear Anodized
UPC:
784607030959
$412.07

Descriptions

The M38 electromagnetic lock is ideal for traffic control in high-use areas within secured or monitored perimeters. Offerings include solutions for interior rooms, closets and hallways where reliability, high durability and low maintenance are required. Bracket mounting and wiring chamber provide quick, accurate installation. Automatic dual-voltage, no field adjustment required. Instant release circuit with no residual magnetism. Efficient, low power usage. All ferrous metal surfaces plated for durability and rust resistance. Holding Force: 600 lbs [272kg]. Dimensions: Magnalock: 10-1/2"L x 1-11/16"D x 2-1/2"H, Strike: 6-1/4"L x 1/2"D x 1-5/8"H. Electrical: 350 mA at 12 VDC, 170 mA at 24 VDC. Operating Temperature: +32 to +110F [0 to +43C] Indoor use only
TypeTitleURL
catalog2021 Securitron Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/securitron/catalog/ASSA_ABLOY_ESH_Catalog.pdf
installation-instructionsVideo: M370/M380 Installationhttps://youtu.be/zusSwEzGxrg
Video: M670/M680 Installationhttps://youtu.be/V2eCDTgu3kk
literatureM32 Magnalock Environment Product Declaration (EPD)https://dvwi9lnoau63q.cloudfront.net/securitron/literature/138.1_ASSA_ABLOY_mrEPD_SecuritronMagnetsM32.pdf
M62 Magnalock - Environmental Product Declaration (EPD)https://dvwi9lnoau63q.cloudfront.net/securitron/literature/139.1_ASSA_ABLOY_mrEPD_SecuritronMagnetsM62.pdf
price-book2023 Securitron Price Book (effective 4.17.2023)https://dvwi9lnoau63q.cloudfront.net/securitron/pricebooks/SEC_pricebook_4-2023.pdf

Specifications

Brand:
Securitron
Door Handing:
Non-handed
Door Range (Thickness):
-
Specifications Bullet 4:
320/170mA @ 12/24 VDC Current
Certification:
UL Listed, UL 294
Series:
Securitron Smart Magnalocks
Commercial Residential:
Commercial
Country Of Origin:
USA
Specifications Bullet 1:
Single Door Electromagnetic Lock
Dimensions:
10-1/2" x 1-23/32" x 2-1/2"
Specifications Bullet 6:
10-1/2" x 1-23/32" x 2-1/2" Unit Dimension
Parent Manufacturer:
Assa Abloy
UPC:
784607030959
Specifications Bullet 7:
Includes Machine Screws
Finish:
628/US28
Manufacturer:
Securitron
Includes:
Mounting Bracket
Product Warranty:
Limited Warranty
Voltage:
12/24 VDC Voltage
FS/FSE Mode:
Not Applicable
Finish Description:
Satin Aluminum Clear Anodized
Interior/Exterior:
Interior/Exterior
Grade:
Not Graded
Holding Force (lbs):
600
Specifications Bullet 2:
600 lbs Holding Force
Function:
Single Door
Current Draw:
320/170mA @ 12/24 VDC Current
Electronic:
Yes
Specifications Bullet 5:
Includes Mounting Bracket
Specifications Bullet 9:
Limited Warranty
Specifications Bullet 3:
12/24 VDC Voltage
User Codes:
0
Selling Quantity:
1
Fire Rated:
3 Hours {A}
Screw Pack:
Machine Screws
Specifications Bullet 8:
UL Listed, UL 294
UOM:
1
Uid:
SEC100M38
Url Title:
m38
Title:
M38 Securitron Maglock
Type:
Electric Strikes, Bolts, Magnets
Sub Type:
Maglocks
Last Modified:
2024-02-03T06:00:00+00:00
Last Pricing:
2023-04-14T00:00:00+00:00
Msrp:
575
Avg Lead Time:
17
Finish Family:
Matte Silver
Popularity:
3
Pack Weight:
8
Ul Listing:
10C
Ansi Code:
294
Restrictions:
None
Baa Qualified:
Yes
Limited Warranty:
Lifetime
Unit Of Measure:
Each
Base Material:
Aluminum
Vendor:
Assa Abloy

Warranty Information

Limited Warranty
