  • Falcon MA101 DN 626 Grade 1 Passage Mortise Lock Dane Lever Napa Escutcheon Satin Chrome Finish

Falcon MA101 DN 626 Grade 1 Passage Mortise Lock Dane Lever Napa Escutcheon Satin Chrome Finish

Falcon

Write a Review
SKU:
MA101 DN 626
$270.70
Falcon MA101 DN 626 Grade 1 Passage Mortise Lock Dane Lever Napa Escutcheon Satin Chrome Finish
$270.70

Descriptions

The Falcon MA Series lock delivers high performance at an affordable cost for your office, hospital, education, or other commercial projects. One of Falcon's toughest and most dependable locks, the MA Series, provides security and is built to stand up to constant use without fail. The MA Series also makes retrofit easy with an interchangeable core that can be removed for quick, easy re-keying and is compatible with SFIC products from other manufacturers. Plus they're backed by one of the best names in the business - Allegion.
TypeTitleURL
brochure/sales-materialFalcon Finishes Charthttps://dvwi9lnoau63q.cloudfront.net/falcon/miscellaneous/ALLEGION_finish-chart.pdf
catalogFalcon Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/falcon/catalog/Falcon_Locks_Catalog_110449.pdf
installation-instructionsMA-Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/falcon/installation_instructions/108476.pdf
Video: Falcon MA Mortise Lock Installationhttps://youtu.be/GYxFyOeYDlo
price-book2024 Falcon Price Book (effective 3.2024)https://dvwi9lnoau63q.cloudfront.net/falcon/pricebooks/FAL_pricebook_3-2024.pdf
sell-sheetMA-Series Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/falcon/literature/106198.pdf
service-manualMA-Series Service Manualhttps://dvwi9lnoau63q.cloudfront.net/falcon/manuals/106694.pdf

Specifications

Brand:
Falcon
Specifications Bullet 13:
7 Year Warranty
Backset (in):
2-3/4"
Projection (in):
2-1/2"
Cylinder Type:
Keyless
Finish:
626/US26D
Fire Rated:
Yes
Armor Front Dimensions:
1-1/4" x 8"
Rose/Escutcheon Design:
Napa
Specifications Bullet 3:
Napa Escutcheon
Keyway:
Not Applicable
Deadbolt Throw (in):
Not Applicable
Door Handing:
Non-handed
Interior/Exterior:
Interior/Exterior
Specifications Bullet 6:
2-1/2" Projection
Includes Cylinder(s)?:
No
Specifications Bullet 1:
Grade 1 Passage Function Mortise Lockset
Specifications Bullet 7:
4-1/2" x 8-1/8" Escutcheon Dimension
Specifications Bullet 9:
1-1/8" x 8" Faceplate Dimension
Lever/Knob/Pull Design:
Dane
Specifications Bullet 4:
2-3/4" Backset
Electronic:
No
Certification:
ANSI A 156.13, Series 1000, Grade 1
Latch Throw (in):
3/4"
Specifications Bullet 8:
3/4" Spring Latch
Specifications Bullet 10:
6-5/8" X 4-1/2" Pocket Dimension
Can Be Keyed:
No
Commercial Residential:
Commercial
Specifications Bullet 12:
ANSI A 156.13, Series 1000, Grade 1
Base Material:
Brass or Bronze
Minimum Door Thickness (in):
1-3/4"
ADA:
Yes
Finish Description:
Satin Chrome
Specifications Bullet 5:
1-1/4" x 4-7/8" ASA Strike
Series:
MA Series Grade 1 Mortise Locks
Maximum Door Thickness (in):
1-7/8"
Specifications Bullet 2:
Dane Lever
Latch Description:
Spring Latch
Product Warranty:
7 Year Warranty
Specifications Bullet 11:
For Doors 1-3/4" - 1-7/8" Thick
Strike Dimensions:
1-1/4" x 4-7/8"
Selling Quantity:
1
Strike Description:
ASA Strike
Strike Number:
A8737-1
Door Range (Thickness):
1-3/4" - 1-7/8"
Parent Manufacturer:
Allegion
Lever/Knob/Pull:
Lever
Grade:
Grade 1
Manufacturer:
Falcon
Pocket Dimensions:
6-5/8" X 4-1/2"
Rose/Escutcheon:
Escutcheon
Rose/Escutcheon Dimensions (in):
4-1/2" x 8-1/8"
UOM:
1
Function:
Passage
Uid:
FAL100MA101DN626
Url Title:
ma101-dn-626
Title:
MA101 DN 626 Falcon Mortise Lock
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Mortise Lock
Last Modified:
2023-02-26T06:45:57+00:00
Last Pricing:
2023-02-24T00:00:00+00:00
Msrp:
617
Avg Lead Time:
22
Popularity:
8
Pack Weight:
7
Pack Length:
10.25
Pack Width:
9
Pack Height:
5
Unit Of Measure:
EACH
Vendor:
Allegion
Assembly Item:
1

Warranty Information

7 Year Warranty
