Falcon MA581P DG 626 Grade 1 Storeroom Mortise Lock Dane Lever Gala Rose Satin Chrome Finish

Falcon

Write a Review
SKU:
MA581P DG 626
$0.00
Falcon MA581P DG 626 Grade 1 Storeroom Mortise Lock Dane Lever Gala Rose Satin Chrome Finish
$0.00

Descriptions

The Falcon MA Series lock delivers high performance at an affordable cost for your office, hospital, education, or other commercial projects. One of Falcon's toughest and most dependable locks, the MA Series, provides security and is built to stand up to constant use without fail. The MA Series also makes retrofit easy with an interchangeable core that can be removed for quick, easy re-keying and is compatible with SFIC products from other manufacturers. Plus they're backed by one of the best names in the business - Allegion.
TypeTitleURL
brochure/sales-materialFalcon Finishes Charthttps://dvwi9lnoau63q.cloudfront.net/falcon/miscellaneous/ALLEGION_finish-chart.pdf
catalogFalcon Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/falcon/catalog/Falcon_Locks_Catalog_110449.pdf
installation-instructionsMA-Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/falcon/installation_instructions/108476.pdf
Video: Falcon MA Mortise Lock Installationhttps://youtu.be/GYxFyOeYDlo
price-book2024 Falcon Price Book (effective 3.2024)https://dvwi9lnoau63q.cloudfront.net/falcon/pricebooks/FAL_pricebook_3-2024.pdf
sell-sheetMA-Series Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/falcon/literature/106198.pdf
service-manualMA-Series Service Manualhttps://dvwi9lnoau63q.cloudfront.net/falcon/manuals/106694.pdf

Specifications

Brand:
Falcon
Armor Front Dimensions:
1-1/4" x 8"
Parent Manufacturer:
Allegion
ADA:
Yes
Series:
MA Series Grade 1 Mortise Locks
Manufacturer:
Falcon
Backset (in):
2-3/4"
Can Be Keyed:
Yes
Certification:
ANSI A 156.13, Series 1000, Grade 1
Commercial Residential:
Commercial
Base Material:
Brass or Bronze
Deadbolt Throw (in):
Not Applicable
Electronic:
No
Cylinder Type:
Conventional
Door Handing:
Non-handed
Door Range (Thickness):
1-3/4" - 1-7/8"
Fire Rated:
Yes
Finish:
626/US26D
Finish Description:
Satin Chrome
Grade:
Grade 1
Function:
Storeroom
Latch Description:
Dead Latch
Keyway:
G Keyway
Includes Cylinder(s)?:
Yes
Latch Throw (in):
3/4"
Interior/Exterior:
Interior/Exterior
Specifications Bullet 1:
Grade 1 Storeroom Function Mortise Lockset
Specifications Bullet 3:
Conventional G Keyway
Lever/Knob/Pull:
Lever
Specifications Bullet 2:
Dane Lever
Lever/Knob/Pull Design:
Dane
Specifications Bullet 4:
Gala Rose
Specifications Bullet 6:
1-1/4" x 4-7/8" ASA Strike
Specifications Bullet 5:
2-3/4" Backset
Specifications Bullet 7:
2-1/2" Projection
Specifications Bullet 8:
2-9/16" Rose Dimension
Specifications Bullet 9:
3/4" Dead Latch
Specifications Bullet 13:
ANSI A 156.13, Series 1000, Grade 1
Specifications Bullet 12:
For Doors 1-3/4" - 1-7/8" Thick
Specifications Bullet 10:
1-1/8" x 8" Faceplate Dimension
Specifications Bullet 11:
6-5/8" X 4-1/2" Pocket Dimension
Pocket Dimensions:
6-5/8" X 4-1/2"
Product Warranty:
7 Year Warranty
Minimum Door Thickness (in):
1-3/4"
Maximum Door Thickness (in):
1-7/8"
Specifications Bullet 14:
7 Year Warranty
Rose/Escutcheon Design:
Gala
Projection (in):
2-1/2"
Rose/Escutcheon:
Rose
Rose/Escutcheon Dimensions (in):
2-9/16"
Selling Quantity:
1
Strike Description:
ASA Strike
Strike Dimensions:
1-1/4" x 4-7/8"
Strike Number:
A8737-1
UOM:
1
Uid:
FAL100MA581PDG626
Url Title:
ma581p-dg-626
Title:
MA581P DG 626 Falcon Mortise Lock
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Mortise Lock
Last Modified:
2023-02-26T06:56:23+00:00
Last Pricing:
2023-02-24T00:00:00+00:00
Msrp:
753
Avg Lead Time:
25
Popularity:
3
Pack Weight:
7
Pack Length:
10.25
Pack Width:
9
Pack Height:
5
Unit Of Measure:
EACH
Vendor:
Allegion
Assembly Item:
1

Warranty Information

7 Year Warranty
