SDC MD-31DB Passive Infrared Egress Sensor Black

SDC

Write a Review
SKU:
MD-31DB
$204.86
SDC MD-31DB Passive Infrared Egress Sensor Black
UPC:
840067662663
$204.86

Descriptions

The SDC MD31D passive infrared detector is specifically designed for request-to-exit applications. It has an adjustable 1-60 second time delay. The coverage field is internally pointable. When angled 14¼ down, coverage may be 5 x 6 feet at 7 feet high to 10 x 12 feet at 15 feet high. The MD31D projects a wrap around U pattern down and away from the door to inhibit tampering. The MD31D may be mounted to the frame header, wall or ceiling. Complies with NFPA applications.
TypeTitleURL
catalog2020 SDC Cataloghttps://dvwi9lnoau63q.cloudfront.net/sdc/catalogs/CondensedHardwareBrochure.pdf

Specifications

Brand:
SDC
UPC:
840067662663
Specifications Bullet 1:
Passive Infrared Infrared Request to Exit Motion Sensor
Door Range (Thickness):
-
Finish:
Black
Dimensions:
7" x 2" x 2"
Specifications Bullet 10:
14 to 122 Degrees F Operating Temperature
Specifications Bullet 9:
1A @ 30 VDC Contact Rating Contact Rating
Contacts:
(2) SPDT, Dry Contacts
Function:
Infrared Request to Exit
Specifications Bullet 5:
7" x 2" x 2" Unit Dimension
Current:
26mA @ 12 or 24 VDC/AC Current
Country of Origin:
United States
Voltage:
12-24 VAC/DC Voltage
Finish Description:
Black Lexan
Specifications Bullet 11:
UL 294 Listed
Mount:
7' to 15' Mounting Height
UOM:
1
Specifications Bullet 3:
7' to 15' Mounting Height
Specifications Bullet 2:
For use in "Request to Exit" Applications
User Codes:
0
Selling Quantity:
1
Specifications Bullet 6:
12-24 VAC/DC Voltage Voltage
Door Handing:
Non-handed
Range:
6' to 12' Coverage
Grade:
Grade 1
Operating Temperature:
14 to 122 Degrees F
Type:
Sensors, Switches, Relays, Timers
Product Warranty:
5 Year Warranty
Application:
For use in "Request to Exit" applications
Manufacturer:
SDC
Commercial Residential:
Commercial
Contact Rating:
1A @ 30 VDC Contact Rating
Specifications Bullet 8:
(2) SPDT, Dry Contacts
Base Material:
Varies
Specifications Bullet 4:
6' to 12' Coverage Range
Interior/Exterior:
Interior/Exterior
Specifications Bullet 12:
5 Year Warranty
Series:
SDC Exit Switches & Sensors
Specifications Bullet 7:
26mA @ 12 or 24 VDC/AC Current
Certification:
UL 294 Listed
Uid:
SDCMD31DB
Url Title:
sdcmd-31db
Title:
MD-31DB SDC Motion Sensors
Sub Type:
Motion Sensors
Last Modified:
2024-08-16T12:12:51+00:00
Last Pricing:
2023-08-28T00:00:00+00:00
Msrp:
268
Avg Lead Time:
55
Popularity:
9
Vendor:
Security Door Controls

Warranty Information

5 Year Warranty
