Arrow MK02-DD-26D Grade 2 Privacy Cylindrical Lock Darrin Knob Non-Keyed Satin Chrome Finish Non-handed

Arrow

Write a Review
SKU:
MK02-DD-26D
$73.10
Arrow MK02-DD-26D Grade 2 Privacy Cylindrical Lock Darrin Knob Non-Keyed Satin Chrome Finish Non-handed
$73.10

Descriptions

Arrow MK Series offer the designer, architect and contractor simple solutions to accessibility requirements. Their clean designs, architectural finishes and available functions make them ideal for commercial applications where heavy duty grade one hardware may not be necessary.
TypeTitleURL
cut-sheetMK Series Cut Sheethttps://dvwi9lnoau63q.cloudfront.net/arrow/cut-sheet/MKSeries.pdf
templateMK Series Dummy Knob Templatehttps://dvwi9lnoau63q.cloudfront.net/arrow/template/MK_Template_Dummy_1.pdf
MK Series Templatehttps://dvwi9lnoau63q.cloudfront.net/arrow/template/MK_Series_Template_1.pdf

Specifications

Brand:
Arrow
ADA:
No
Manufacturer:
Arrow
Electronic:
No
Specifications Bullet 1:
Grade 2 Privacy Function Cylindrical Lockset
Bore Hole Diameter (in):
2-1/8"
Specifications Bullet 11:
1 Year Warranty
Country Of Origin:
Mexico
Certification:
ANSI A156.2, Series 4000, Grade 2, UL Listed
Specifications Bullet 9:
2-1/8" Bore Hole Diameter
Specifications Bullet 4:
1-1/8" x 2-1/4" Spring Latch
Specifications Bullet 5:
1-1/8" x 2-3/4" T-Strike
Specifications Bullet 6:
2-3/8" Projection
Latch Dimensions:
1-1/8" x 2-1/4"
Backset (in):
2-3/4"
Door Handing:
Non-handed
Finish:
626/US26D
Specifications Bullet 8:
For Doors 1-3/8" - 1-3/4" Thick
Door Range (Thickness):
1-3/8" - 1-3/4"
Keyway:
Not Applicable
Maximum Door Thickness (in):
1-3/4"
Commercial Residential:
Commercial
Grade:
Grade 2
Specifications Bullet 10:
ANSI A156.2, Series 4000, Grade 2, UL Listed
Latch Bore Diameter (in):
1"
Cylinder Type:
Keyless
Finish Description:
Satin Chrome
Lever/Knob/Pull:
Knob
Can Be Keyed:
No
Latch Number:
104
Specifications Bullet 3:
2-3/4" Backset
Latch Description:
Spring Latch
Rose/Escutcheon:
Rose
Specifications Bullet 2:
Darrin Knob
Base Material:
Brass, Bronze
Includes Cylinder(s)?:
No
Lever/Knob/Pull Design:
Darrin
Product Warranty:
1 Year Warranty
Specifications Bullet 7:
2-9/16" Rose
Latch Throw (in):
1/2"
Parent Manufacturer:
Assa Abloy
Projection (in):
2-3/8"
Rose/Escutcheon Design:
Not Applicable
Minimum Door Thickness (in):
1-3/8"
Fire Rated:
3 Hours {A}
Function:
Privacy
Rose/Escutcheon Dimensions (in):
2-9/16"
Strike Description:
T-Strike
Strike Dimensions:
1-1/8" x 2-3/4"
Selling Quantity:
1
Strike Number:
300
Series:
MK Series
UOM:
1
Uid:
ARR100MK02DD26D
Url Title:
mk02dd-26d
Title:
Arrow MK02-DD-26D Cylindrical Lock
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Cylindrical Lock
Series:
MK Series Grade 2 Cylindrical Knob Locks
Last Modified:
2022-12-15T05:29:41+00:00
Last Pricing:
2022-09-16T00:00:00+00:00
Msrp:
104
Avg Lead Time:
51
Finish Family:
Matte Silver
Popularity:
8
Pack Weight:
1.5
Pack Length:
7.5
Pack Width:
3.5
Pack Height:
2.625
Pack Volume:
68.90625
Ul Listing:
BHMA A156.2, Series 4000, Grade 2, UL Listed
Ansi Code:
F76
Limited Warranty:
1 Year Warranty
Unit Of Measure:
Each
Vendor:
Assa Abloy

Warranty Information

1 Year Warranty
