ML20906 NSM 626 SEC M92 Corbin Russwin Electric Mortise Lock

Corbin Russwin

Write a Review
SKU:
ML20906 NSM 626 SEC M92
$1,305.11
ML20906 NSM 626 SEC M92 Corbin Russwin Electric Mortise Lock
$1,305.11

Descriptions

Utilizing the ML2000 Series Grade 1 Mortise Lock with the patented quick reversible latchbolt, the ML20900 Series provides actuator operated remote locking and unlocking. The self contained integral continuous duty aqctuator allows installation in standard mortise prep with slight modification. The ML20900 ECL is ideal for use where increased security is necessary at all times, such as tenant space, pharmacies, computer rooms and high security areas. THe ML20900 Series features Ecoflex Technology, reducing energy consumption up to 96% as certified by GreenCircle. It is field configurable to fail safe or fail secure and operates off 12-24VDC.
TypeTitleURL
brochure/sales-materialCorbin Strikes/Kits Brochurehttps://dvwi9lnoau63q.cloudfront.net/corbin/brochures/Corbin_Strikes-Kits_Brochure.pdf
catalogML2000 and ML20900 Series Cataloghttps://dvwi9lnoau63q.cloudfront.net/corbin/catalogs/Corbin_Russwin_ML2000_Series_Mortise_Lock_Catalog.pdf
installation-instructionsML20900 Electrified Mortise Lock Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/corbin/installation-instructions/FM357-ML209002802-1429optimizedmobile.pdf
ML20900 Electrified Series ElectroLynx Connector System Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/corbin/installation-instructions/FM2122801-1429.pdf
Video: HPSK Push/Pull Trim Installationhttps://youtu.be/htk2fZmiXdo
literatureML20900 ECL Electromechanical Mortise Lock - Environmental Product Declaration (EPD)https://dvwi9lnoau63q.cloudfront.net/corbin/literature/141.1_ASSA_ABLOY_mrEPD_CorbinRusswinML20900_ECL_Mortise_Lock.pdf
price-book2023 Corbin Price Book (updated 10.2023)https://dvwi9lnoau63q.cloudfront.net/corbin/pricebooks/COR_pricebook_10-2023.pdf
wiring-diagrams-and-instructionsML20900 Series Wiring Diagramshttps://dvwi9lnoau63q.cloudfront.net/corbin/wiring-diagrams-instructions/120870.pdf
ML20900 x M91 x M92 Wiring Informationhttps://dvwi9lnoau63q.cloudfront.net/corbin/keywaydiagrams/120870.pdf

Specifications

Brand:
Corbin Russwin
Maximum Door Thickness (in):
1-3/4"
Cylinder Type:
Mortise Conventional
Specifications Bullet 2:
Newport Lever
Finish:
626/US26D
Keyway:
L4 Keyway
Door Handing:
Non-handed
FS/FSE Mode:
Fail Secure
Specifications Bullet 10:
2-5/8" Projection
Latch Throw (in):
3/4"
Certification:
ANSI A156.13-2012, Series 1000, Grade 1, UL Listed
Backset (in):
2-3/4"
Specifications Bullet 9:
3/4" Dead Latch
Voltage:
12/24VDC
Specifications Bullet 11:
2-1/4" x 7-1/2" Escutcheon Dimension
Specifications Bullet 4:
Fail Secure Request to Exit
Lever/Knob/Pull Design:
Newport
Lever/Knob/Pull:
Lever
Latch Description:
Dead Latch
Specifications Bullet 6:
SM Escutcheon
Grade:
Grade 1
Specifications Bullet 5:
12/24 VDC Voltage
Specifications Bullet 13:
ANSI A156.13-2012, Series 1000, Grade 1, UL Listed
Specifications Bullet 14:
2 Year Warranty
Function:
Electronic Unlocking Storeroom
Parent Manufacturer:
Assa Abloy
Specifications Bullet 7:
2-3/4" Backset
Finish Description:
Satin Chrome
Rose/Escutcheon:
Escutcheon
Specifications Bullet 3:
Mortise Conventional L4 Keyway
Series:
ML20900 Series Electrified Mortise Locks
Specifications Bullet 1:
Grade 1 Electronic Unlocking Storeroom Function Mortise Lockset
Option 1:
Request to Exit
Door Range (Thickness):
1-3/4" - 1-3/4"
Can Be Keyed:
Yes
Includes Cylinder(s)?:
Yes
Projection (in):
2-5/8"
Rose/Escutcheon Design:
SM
Product Warranty:
2 Year Warranty
Minimum Door Thickness (in):
1-3/4"
Specifications Bullet 12:
For Doors 1-3/4" Thick
Specifications Bullet 8:
1-1/4" x 4-7/8" ASA Strike
Strike Dimensions:
1-1/4" x 4-7/8"
Rose/Escutcheon Dimensions (in):
2-1/4" x 7-1/2"
Strike Description:
ASA Strike
Strike Number:
236L72
Manufacturer:
Corbin Russwin
ADA:
Yes
Base Material:
Brass or Bronze
Uid:
COR300ML20906NSM626SECM92
Url Title:
ml20906-nsm-626-sec-m92
Title:
ML20906 NSM 626 SEC M92 Corbin Russwin Electric Mortise Lock
Type:
Electric Locks
Sub Type:
Electric Mortise Lock
Last Modified:
2023-02-16T05:36:00+00:00
Last Pricing:
2022-09-16T00:00:00+00:00
Commercial Residential:
Commercial
Msrp:
1817
Finish Family:
Matte Silver
Popularity:
3
Pack Weight:
4
Pack Length:
10
Pack Width:
7.5
Pack Height:
4.5
Country Of Origin:
USA
Baa Qualified:
Yes
Limited Warranty:
2 Years
Fire Rated:
3 Hours {A}
Accessible:
Yes
Unit Of Measure:
Each
Unit Of Measure 2:
Case
Unit Of Measure 2 Qty:
6
Vendor:
Assa Abloy

Warranty Information

2 Year Warranty
