Schlage ND53JD TLR 626 Grade 1 Entrance Lock Tubular Lever Schlage FSIC Prep Less Core Satin Chrome Finish Non-Handed

Schlage

Write a Review
SKU:
ND53JD TLR 626
$525.89
$525.89

Descriptions

Walter Schlage invented the cylindrical lock in 1920. Since then, the Schlage Lock Company has consistently delivered innovation and continuous improvement. In that tradition, The ND Series Cylindrical Lockset is a proven, easy to install product with extensive function, keying, trim and finish capabilities that work in nearly any application. The Schlage ND Series Locksets are commonly used in Healthcare, Education, Government, Office, Retail, and other commercial applications. The ND Series has been certified Grade 1; exceeding 3-million operating cycles without failure. This provides confidence that the lock will last within any type of facility. Finally, Schlage has incorporated wire-wireless capabilities that meet the access control and security needs of every facility owner.
TypeTitleURL
brochure/sales-materialSchlage Finishes Charthttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/ALLEGION_finish-chart.pdf
catalogND Series Locks & Latches Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/Allegion_2014_Commercial_Product_Catalogue_ND_Series_0114.pdf
ND Series Mechanical Grade 1 Cylindrical Locks Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/Schlage_ND_Series_Catalog_106501.pdf
ND Series Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/106501.pdf
installation-guideSchlage ND-Series Standard Installation Instructions (locks manufactured after 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/NDSeriesStandInstallInstructionslocksmanafter8-15-2012.pdf
Schlage ND-Series Standard Installation Instructions (locks manufactured before 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/NDStandInstallInstructionslocksmanubefore8-15-2012.pdf
installation-instructionsND Series Electrified Functions Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108353.PDF
ND Series Electrified Functions Installation Instructions (solenoid, mfg before 3-14-2016)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/111248.pdf
ND Series Hollow Metal Door Spacer Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/107544.pdf
ND170 Installation Instructions (locks manufactured after 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/108996.pdf
ND170 Installation Instructions (locks manufactured before 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/106121.pdf
ND25 Installation Instructions (locks manufactured after 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/108995.pdf
ND25 Installation Instructions (locks manufactured before 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/106122.pdf
Video: ND Series Lock Installationhttps://youtu.be/U6fUoLLH7Kw
keyway-diagramEverest 29 S Keyway Family Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/keywaydiagram/S-Family_Open_Keyway_Diagram.pdf
Everest Keyways Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/keywaydiagram/Everest_Keyways.pdf
Observe Keyways for Classic Conventional Cylinders Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/keywaydiagram/Convetional_Observe_Keyways.pdf
Observe Keyways for Classic Primus XP Cylinders Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/keywaydiagram/Primus_Observe_Keyways.pdf
miscellaneousND Series Locks & Latches Warrantyhttps://dvwi9lnoau63q.cloudfront.net/schlage/miscellaneous/Schlage_ND_Series_Commercial_Warranty_December_2013.pdf
price-book2024 Schlage Commercial Price Book (effective 3.2024)https://dvwi9lnoau63q.cloudfront.net/schlage/pricebooks/SCH_pricebook_3-2024.pdf
sell-sheetSchlage ND Series Electrified Cylindrical Locks Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/Schlage_ND_Series_Data_Sheet_110875.pdf
Schlage ND Series Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/106486NDsellsheet.pdf
service-manualSchlage ND Series Service Manualhttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/2021_Schlage_ND_Series_Service_Manual.pdf
templateND Series Templatehttps://dvwi9lnoau63q.cloudfront.net/schlage/templates/Schlage_ND_Series_Template.pdf

Specifications

Brand:
Schlage
Certification:
ANSI A156.2-2011, Series 4000, Grade 1, UL Listed
Cylinder Type:
LFIC Housing
Specifications Bullet 11:
ANSI A156.2-2011, Series 4000, Grade 1, UL Listed
Door Range (Thickness):
1-5/8" - 2-1/8"
Grade:
Grade 1
Includes Cylinder(s)?:
No
Commercial Residential:
Commercial
Latch Description:
Dead Latch
Product Warranty:
10 Year Warranty
Specifications Bullet 5:
1-1/8" X 2-1/4" Dead Latch
Function:
Entrance
Lever/Knob/Pull:
Lever
Specifications Bullet 4:
2-3/4" Backset
Specifications Bullet 9:
For Doors 1-5/8" - 2-1/8" Thick
Specifications Bullet 12:
10 Year Warranty
Can Be Keyed:
Yes
Specifications Bullet 3:
LFIC Housing Less Core
Latch Dimensions:
1-1/8" X 2-1/4"
Specifications Bullet 6:
1-1/4" x 4-7/8" ASA Strike
Maximum Door Thickness (in):
2-1/8"
Keyway:
Less Core
Specifications Bullet 2:
Tubular Lever
Specifications Bullet 8:
3-7/16" Rose
Electronic:
No
Projection (in):
3"
Door Handing:
Non-handed
Lever/Knob/Pull Design:
Tubular
Box Weight (lbs):
5 lbs
Backset (in):
2-3/4"
Finish Description:
Satin Chrome
Finish:
626/US26D
Rose/Escutcheon Design:
Not Applicable
Latch Number:
13-247
Series:
ND Series Lever Locks
Strike Description:
ASA Strike
Specifications Bullet 1:
Grade 1 Entrance Function Cylindrical Lockset
Latch Throw (in):
1/2"
Rose/Escutcheon Dimensions (in):
3-7/16"
Strike Dimensions:
1-1/4" x 4-7/8"
Specifications Bullet 7:
3" Projection
Parent Manufacturer:
Allegion
Fire Rated:
3 Hours {A}
Specifications Bullet 10:
2-1/8" Bore Hole Diameter
Strike Number:
10-025
ADA:
Yes
Manufacturer:
Schlage
Bore Hole Diameter (in):
2-1/8"
Minimum Door Thickness (in):
1-5/8"
Box Depth (in):
9-1/2"
Rose/Escutcheon:
Rose
Box Width (in):
8-1/4"
Country of Origin:
Mexico
UOM:
1
Base Material:
Brass Bronze
Box Height (in):
4-3/4"

Warranty Information

10 Year Warranty
