  • Schlage ND80BDEL RHO 626 Grade 1 Electrified Cylindrical Lock Storeroom Function 12-24V DC Fail Safe 2-3/4 Backset Rhodes Lever SFIC Prep Satin Chrome

Schlage ND80BDEL RHO 626 Grade 1 Electrified Cylindrical Lock Storeroom Function 12-24V DC Fail Safe 2-3/4 Backset Rhodes Lever SFIC Prep Satin Chrome

Schlage

Write a Review
SKU:
ND80BDEL RHO 626
$738.90
Schlage ND80BDEL RHO 626 Grade 1 Electrified Cylindrical Lock Storeroom Function 12-24V DC Fail Safe 2-3/4 Backset Rhodes Lever SFIC Prep Satin Chrome
UPC:
840067605196
$738.90

Descriptions

ND Series locks are available for electrically locking and unlocking controls for high security and fire safety applications.They are UL Listed and rated for both fire and electrical single-point locking on labeled doors. RX feature is available on ND10, ND12, ND80 and ND96 families. Switch is ready to be used in a normally open or normally closed application.
TypeTitleURL
brochure/sales-materialSchlage Finishes Charthttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/ALLEGION_finish-chart.pdf
catalogND Series Mechanical Grade 1 Cylindrical Locks Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/Schlage_ND_Series_Catalog_106501.pdf
ND Series Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/106501.pdf
price-book2024 Schlage Commercial Price Book (effective 3.2024)https://dvwi9lnoau63q.cloudfront.net/schlage/pricebooks/SCH_pricebook_3-2024.pdf

Specifications

Brand:
Schlage
Backset (in):
2-3/4"
Parent Manufacturer:
Allegion
Finish:
626/US26D
Electronic:
Yes
Specifications Bullet 10:
1-1/8" x 2-1/4" Dead Latch
Specifications Bullet 4:
2-3/4" Backset
Product Warranty:
1 Year Warranty
Box Weight (lbs):
5 lbs
Bore Hole Diameter (in):
2-1/8"
Door Handing:
Non-handed
Specifications Bullet 9:
1/2" Latch Throw
Latch Throw (in):
1/2"
Commercial Residential:
Commercial
Voltage:
12/24 VDC Voltage
Cylinder Type:
SFIC Housing
Box Depth (in):
9-1/2"
Specifications Bullet 13:
Includes Wood/Metal Screws
Specifications Bullet 12:
2-1/8" Bore Hole Diameter
FS/FSE Mode:
Fail Safe
Finish Description:
Satin Chrome
Grade:
Grade 1
Includes Cylinder(s)?:
No
Keyway:
Less Core
Latch Dimensions:
1-1/8" x 2-1/4"
Specifications Bullet 2:
Rhodes Lever
Specifications Bullet 6:
12/24 VDC Voltage Fail Safe
Specifications Bullet 3:
SFIC Housing Less Core
Lever/Knob/Pull:
Lever
Rose/Escutcheon:
Rose
Fire Rated:
Yes
Specifications Bullet 5:
1-1/4" x 4-7/8" ASA Strike
Door Range (Thickness):
1-5/8" - 2-1/8"
Function:
Electronically Locked Storeroom
Latch Description:
Dead Latch
Certification:
ANSI A156.2-2011, Series 4000, Grade 1, UL Listed
Box Width (in):
8-1/4"
Strike Description:
ASA Strike
Specifications Bullet 1:
Grade 1 Electrified Electronically Locked Storeroom Function Cylindrical Lockset
Specifications Bullet 8:
3-7/16" Rose Dimension
Base Material:
Brass or Bronze
Minimum Door Thickness (in):
1-5/8"
Specifications Bullet 7:
2-15/16" Projection
Latch Number:
13-247
Maximum Door Thickness (in):
2-1/8"
Latch Bore Diameter (in):
1"
Specifications Bullet 11:
For Doors 1-5/8" - 2-1/8" Thick
Can Be Keyed:
Yes
Specifications Bullet 14:
ANSI A156.2-2011, Series 4000, Grade 1, UL Listed
Country Of Origin:
Mexico
Box Height (in):
4-3/4"
Rose/Escutcheon Dimensions (in):
3-7/16"
Projection (in):
2-15/16"
Lever/Knob/Pull Design:
Rhodes
Strike Dimensions:
1-1/4" x 4-7/8"
Screw Pack:
Wood/Metal Screws
Specifications Bullet 15:
1 Year Warranty
UPC:
840067605196
Strike Number:
10-025
UOM:
1
Series:
ND Series
ADA:
Yes
Manufacturer:
Schlage

Warranty Information

1 Year Warranty
