Securitron RB-4-24 Relay Board 4 DPDT Relays 24V 2 AMP Contacts

Securitron

Write a Review
SKU:
RB-4-24
$100.90
Securitron RB-4-24 Relay Board 4 DPDT Relays 24V 2 AMP Contacts
$100.90

Descriptions

The relay board provides Normally - Open or Normally - Closed relays that can be interconnected. Ideal for interlock installations or wherever a basic relay board is used to trigger action, shunt alarms or report status from an access control system. DPDT relays with 2A contacts. Individual coil connections common, negative or positive. Replaces socket mount relays. Dry contact connections via screw terminals. Relays have low current coils (13 mA at 12 VDC; 8 mA at 24 VDC) Allows operation from most LED drive outputs.
TypeTitleURL
catalog2021 Securitron Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/securitron/catalog/ASSA_ABLOY_ESH_Catalog.pdf
installation-instructionsDPA-12, DPA-24 Installation and Operating Instructionshttps://dvwi9lnoau63q.cloudfront.net/securitron/installation-instructions/DPA-12_DPA-24_IO_500-15700_20C.pdf
price-book2023 Securitron Price Book (effective 4.17.2023)https://dvwi9lnoau63q.cloudfront.net/securitron/pricebooks/SEC_pricebook_4-2023.pdf

Specifications

Brand:
Securitron
Contact Rating:
2A Rating
Current:
8mA Low Current Coils, 32mA Current Draw
Product Warranty:
Limited Warranty
Specifications Bullet 8:
UL Listed
Door Range (Thickness):
-
Specifications Bullet 2:
For use for interLock Installations and where a Basic Relay Board is Needed
Specifications Bullet 4:
(4) DPDT Contacts
Specifications Bullet 6:
8mA Low Current Coils, 32mA Current Draw
Manufacturer:
Securitron
Dimensions:
4" x 3-1/2"
Parent Manufacturer:
Assa Abloy
Application:
For use for interLock Installations and where a Basic Relay Board is Needed
Contacts:
(4) DPDT Contacts
Specifications Bullet 1:
Relay Board
Specifications Bullet 3:
4" x 3-1/2" Unit Dimension
Specifications Bullet 5:
2A Rating
Country Of Origin:
USA
Specifications Bullet 9:
Limited Warranty
Type:
Power Supplies and Transformers
Specifications Bullet 7:
24 VDC Voltage
Voltage:
24 VDC Voltage
Certification:
UL Listed
Uid:
SEC100RB424
Url Title:
rb-4-24
Title:
RB-4-24 Securitron Power Supply
Sub Type:
Power Supplies
Series:
Securitron Switches, Relays, Timers and Pushbuttons
Last Modified:
2024-08-11T04:47:44+00:00
Last Pricing:
2024-05-17T00:00:00+00:00
Commercial Residential:
Commercial
Msrp:
143
Avg Lead Time:
17
Popularity:
3
Pack Weight:
0.3
Restrictions:
None
Baa Qualified:
Yes
Limited Warranty:
Lifetime
Fire Rated:
No
Unit Of Measure:
Each
Vendor:
Assa Abloy

Warranty Information

Limited Warranty
