Arrow RL02-SR-04 Grade 2 Privacy Cylindrical Lock Sierra Lever Non-Keyed Satin Brass Finish Non-handed

Arrow

Write a Review
SKU:
RL02-SR-04
$69.97
Arrow RL02-SR-04 Grade 2 Privacy Cylindrical Lock Sierra Lever Non-Keyed Satin Brass Finish Non-handed
$69.97

Descriptions

The RL Series has been enhanced to offer removable through bolts and a wide variety of designs, finishes and functions. The RL Series cylindrical locksets are an economical value for a variety of application. Perfect for multi-family housing markets, as well as light commercial applications.
TypeTitleURL
catalog2014 Arrow Full Line Cataloghttps://dvwi9lnoau63q.cloudfront.net/arrow/catalog/ARR_catalog_2014.pdf
cut-sheetRL Series Cut Sheethttps://dvwi9lnoau63q.cloudfront.net/arrow/cut-sheet/RLSeries.pdf
instructionsRL Series Instructionshttps://dvwi9lnoau63q.cloudfront.net/arrow/instructions/RL_Install_Inst.pdf
Video: How to Install a Commercial Leverhttps://youtu.be/mzirx11iQPM
templateRK & RL Series Templatehttps://dvwi9lnoau63q.cloudfront.net/arrow/template/RK_RL_Template.pdf

Specifications

Brand:
Arrow
Manufacturer:
Arrow
ADA:
Yes
Series:
RL Series Grade 2 Cylindrical Lever Locks
Parent Manufacturer:
Assa Abloy
Backset (in):
2-3/4"
Base Material:
Brass
Certification:
ANSI A156.2, Series 4000, Grade 2 UL Listed
Commercial Residential:
Commercial
Can Be Keyed:
No
Bore Hole Diameter (in):
2-1/8"
Cylinder Type:
Keyless
Door Handing:
Non-handed
Electronic:
No
Door Range (Thickness):
1-3/8" - 1-3/4"
Country Of Origin:
Taiwan
Finish Description:
Satin Brass
Grade:
Grade 2
Finish:
606/US4
Function:
Privacy
Fire Rated:
3 Hours {A}
Includes Cylinder(s)?:
No
Latch Description:
Spring Latch
Keyway:
Not Applicable
Latch Bore Diameter (in):
1"
Latch Dimensions:
1-1/8" x 2-1/4"
Lever/Knob/Pull:
Lever
Specifications Bullet 1:
Grade 2 Privacy Function Cylindrical Lockset
Latch Number:
R73
Lever/Knob/Pull Design:
Sierra
Latch Throw (in):
1/2"
Specifications Bullet 2:
Sierra Lever
Specifications Bullet 3:
2-3/4" Backset
Specifications Bullet 4:
1-1/8" x 2-1/4" Spring Latch
Specifications Bullet 6:
2-7/16" Projection
Specifications Bullet 5:
1-1/4" x 4-7/8" ASA Strike
Specifications Bullet 10:
ANSI A156.2, Series 4000, Grade 2 UL Listed
Specifications Bullet 11:
5 Year Warranty
Specifications Bullet 9:
2-1/8" Bore Hole Diameter
Specifications Bullet 7:
3-5/16" Rose
Specifications Bullet 8:
For Doors 1-3/8" - 1-3/4" Thick
Maximum Door Thickness (in):
1-3/4"
Product Warranty:
5 Year Warranty
Minimum Door Thickness (in):
1-3/8"
Projection (in):
2-7/16"
Rose/Escutcheon:
Rose
Rose/Escutcheon Design:
Not Applicable
Strike Description:
ASA Strike
Strike Dimensions:
1-1/4" x 4-7/8"
Rose/Escutcheon Dimensions (in):
3-5/16"
Selling Quantity:
1
UOM:
1
Strike Number:
R62
Uid:
ARR100RL02SR4
Url Title:
rl02-sr-04
Title:
Arrow RL02-SR-04 Cylindrical Lock
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Cylindrical Lock
Last Modified:
2021-05-18T08:31:59+00:00
Last Pricing:
2023-01-12T00:00:00+00:00
Msrp:
124
Avg Lead Time:
85
Finish Family:
Matte Brass
Popularity:
9
Pack Weight:
3.4
Pack Length:
7.25
Pack Width:
6.75
Pack Height:
3.75
Pack Volume:
183.515625
Ul Listing:
ANSI A156.2 Series 4000, Grade 2, UL Listed
Ansi Code:
F76A
Limited Warranty:
5 Year Warranty
Unit Of Measure:
Each
Vendor:
Assa Abloy

Warranty Information

5 Year Warranty
