Arrow RL17-SR-26D-CS Grade 2 Classroom Cylindrical Lock Sierra Lever Conventional Cylinder Schlage C Keyway Satin Chrome Finish Non-handed

Arrow

Write a Review
SKU:
RL17-SR-26D-CS
$0.00
Arrow RL17-SR-26D-CS Grade 2 Classroom Cylindrical Lock Sierra Lever Conventional Cylinder Schlage C Keyway Satin Chrome Finish Non-handed
$0.00

Descriptions

The RL Series has been enhanced to offer removable through bolts and a wide variety of designs, finishes and functions. The RL Series cylindrical locksets are an economical value for a variety of application. Perfect for multi-family housing markets, as well as light commercial applications.
TypeTitleURL
catalog2014 Arrow Full Line Cataloghttps://dvwi9lnoau63q.cloudfront.net/arrow/catalog/ARR_catalog_2014.pdf
cut-sheetRL Series Cut Sheethttps://dvwi9lnoau63q.cloudfront.net/arrow/cut-sheet/RLSeries.pdf
instructionsRL Series Instructionshttps://dvwi9lnoau63q.cloudfront.net/arrow/instructions/RL_Install_Inst.pdf
Video: How to Install a Commercial Leverhttps://youtu.be/mzirx11iQPM
templateRK & RL Series Templatehttps://dvwi9lnoau63q.cloudfront.net/arrow/template/RK_RL_Template.pdf

Specifications

Brand:
Arrow
Latch Bore Diameter (in):
1"
Door Handing:
Non-handed
Selling Quantity:
1
Finish Description:
Satin Chrome
Specifications Bullet 1:
Grade 2 Classroom Function Cylindrical Lockset
Grade:
Grade 2
Cylinder Type:
Conventional
Keyway:
C Keyway
Commercial Residential:
Commercial
Certification:
ANSI A156.2, Series 4000, Grade 2 UL Listed
Lever/Knob/Pull:
Lever
Function:
Classroom
Lever/Knob/Pull Design:
Sierra
Finish:
626/US26D
Bore Hole Diameter (in):
2-1/8"
Specifications Bullet 11:
ANSI A156.2, Series 4000, Grade 2 UL Listed
Includes Cylinder(s)?:
Yes
Specifications Bullet 9:
For Doors 1-3/8" - 1-3/4" Thick
Base Material:
Brass, Bronze
Specifications Bullet 7:
2-7/16" Projection
Fire Rated:
3 Hours {A}
Door Range (Thickness):
1-3/8" - 1-3/4"
Specifications Bullet 8:
3-5/16" Rose
Specifications Bullet 10:
2-1/8" Bore Hole Diameter
Specifications Bullet 2:
Sierra Lever
Electronic:
No
Country Of Origin:
Taiwan
Specifications Bullet 12:
5 Year Warranty
Latch Throw (in):
1/2"
Specifications Bullet 3:
Conventional C Keyway
Latch Description:
Dead Latch
Rose/Escutcheon Design:
Not Applicable
Manufacturer:
Arrow
Latch Dimensions:
1-1/8" x 2-1/4"
Rose/Escutcheon:
Rose
UOM:
1
Series:
RL Series Grade 2 Cylindrical Lever Locks
Specifications Bullet 5:
1-1/8" x 2-1/4" Dead Latch
Specifications Bullet 6:
1-1/4" x 4-7/8" ASA Strike
Specifications Bullet 4:
2-3/4" Backset
Minimum Door Thickness (in):
1-3/8"
Latch Number:
R71
Projection (in):
2-7/16"
Can Be Keyed:
Yes
Strike Dimensions:
1-1/4" x 4-7/8"
Rose/Escutcheon Dimensions (in):
3-5/16"
Backset (in):
2-3/4"
Maximum Door Thickness (in):
1-3/4"
Strike Number:
R62
Parent Manufacturer:
Assa Abloy
Product Warranty:
5 Year Warranty
ADA:
Yes
Strike Description:
ASA Strike
Uid:
ARR100RL17SR26DCS
Url Title:
rl17-sr-26d-cs
Title:
Arrow RL17-SR-26D-CS Cylindrical Lock
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Cylindrical Lock
Last Modified:
2021-06-16T09:13:28+00:00
Last Pricing:
2023-01-12T00:00:00+00:00
Msrp:
134
Avg Lead Time:
32
Finish Family:
Matte Silver
Popularity:
3
Pack Weight:
3.4
Pack Length:
7.25
Pack Width:
6.75
Pack Height:
3.75
Pack Volume:
183.515625
Ul Listing:
ANSI A156.2 Series 4000, Grade 2, UL Listed
Ansi Code:
F84
Limited Warranty:
5 Year Warranty
Unit Of Measure:
Each
Vendor:
Assa Abloy

Warranty Information

5 Year Warranty
