LCN SEM7840 695 Magnetic Door Holder Recessed Wall Mount Low Profile Armature 12V 24V 120V Tri Voltage Dark Bronze Painted Finish

LCN

Write a Review
SKU:
SEM7840 695
$413.81
LCN SEM7840 695 Magnetic Door Holder Recessed Wall Mount Low Profile Armature 12V 24V 120V Tri Voltage Dark Bronze Painted Finish
UPC:
840067611746
$413.81

Descriptions

The Sentronic SEM7800 Series are heavy duty, electrically controlled door holding magnets. Magnets are fail safe and hold until the current is interrupted. A manual door closer is used to control and close the doors. A choice of floor, recessed wall or surface wall mounted magnets are available.
TypeTitleURL
installation-guideLCN Closers & Auto Operators Installation Guidehttps://dvwi9lnoau63q.cloudfront.net/lcn/installation-guide/LCN_Closers_and_Auto_Operators_Templates_and_Instructions_Index_111819.pdf
LCN SEM7810 Extension Installation Guidehttps://dvwi9lnoau63q.cloudfront.net/lcn/installation-guide/LCNSEM7810Extinstallationinstructions.pdf
LCN SEM7820 Extension Installation Guidehttps://dvwi9lnoau63q.cloudfront.net/lcn/installation-guide/LCNSEM7820Extinstallationinstructions.pdf
LCN SEM7830 Extension Installation Guidehttps://dvwi9lnoau63q.cloudfront.net/lcn/installation-guide/LCNSEM7830Extinstallationinstructions.pdf
LCN SEM7840/7850 Installation Guidehttps://dvwi9lnoau63q.cloudfront.net/lcn/installation-guide/LCNSEM7840.7850installationinstructions.pdf
LCN SEM7870 Installation Guidehttps://dvwi9lnoau63q.cloudfront.net/lcn/installation-guide/LCNSEM7870installationinstructions.pdf

Specifications

Brand:
LCN
Parent Manufacturer:
Allegion
Country of Origin:
United States
FS/FSE Mode:
Fail Safe
Finish Description:
Dark Bronze Painted
Door Range (Thickness):
-
Includes:
Housing, Cover and Armature
Screw Pack:
Machine Screws
Specifications Bullet 3:
Housing, Cover and Armature
Specifications Bullet 8:
35 lbs Holding Force
Holding Force (lbs):
35
Specifications Bullet 5:
12 VDC, 24 VAC/VDC, 120 VAC Voltage
Finish:
695
Specifications Bullet 4:
2-5/8" Projection
Specifications Bullet 9:
Includes Machine Screws
Certification:
ANSI A156.15, UL 10C Listed, Grade 1
Specifications Bullet 7:
Fail Safe
Current:
30mA @ 12 VDC, 20mA @ 24 VAC/VDC, 20mA @ 120 VAC Current
Specifications Bullet 6:
30mA @ 12 VDC, 20mA @ 24 VAC/VDC, 20mA @ 120 VAC Current
Specifications Bullet 1:
Recessed Wall Mount Magnetic Door Holders
Trademark Term:
Not Applicable
Grade:
Grade 1
Specifications Bullet 2:
2-5/8" Projection, 2-13/16" x 4-5/8" Unit Dimension
Projection (in):
2-5/8"
Dimensions:
2-13/16" x 4-5/8"
UPC:
840067611746
Mount:
Recessed Wall Mount
Product Warranty:
1 Year Warranty
Manufacturer:
LCN
Specifications Bullet 11:
1 Year Warranty
Specifications Bullet 10:
ANSI A156.15, UL 10C Listed, Grade 1
Series:
SEM Series Fire/Life Safety Closers/Holders
Voltage:
12 VDC, 24 VAC/VDC, 120 VAC Voltage
Base Material:
Varies
Uid:
LCN100SEM7840DKBRZ
Url Title:
sem7840-dkbrz
Title:
SEM7840 DKBRZ LCN Electromagnetic Door Holders
Type:
Electric Strikes, Bolts, Magnets
Sub Type:
Electromagnetic Door Holders
Last Modified:
2024-02-03T06:12:00+00:00
Last Pricing:
2024-02-29T00:00:00+00:00
Commercial Residential:
Commercial
Msrp:
563
Avg Lead Time:
15
Finish Family:
Dark Bronze
Popularity:
3
Pack Weight:
4
Baa Qualified:
Yes
Limited Warranty:
2 Years
Unit Of Measure:
Each
Vendor:
Allegion

Warranty Information

1 Year Warranty
