  • Falcon T301S A 626 Grade 1 Privacy Cylindrical Lock Non-keyed Avalon Lever Standard Rose Satin Chrome Finish Non-Handed

Falcon T301S A 626 Grade 1 Privacy Cylindrical Lock Non-keyed Avalon Lever Standard Rose Satin Chrome Finish Non-Handed

Falcon

Write a Review
SKU:
T301S A 626
$235.05
Falcon T301S A 626 Grade 1 Privacy Cylindrical Lock Non-keyed Avalon Lever Standard Rose Satin Chrome Finish Non-Handed
$235.05

Descriptions

The T Series extra heavy-duty Grade 1 cylindrical lock is designed to stand up to high-traffic and heavy-abuse applications. The lock can accept any manufacturer’s cylinder, and the cylinder can easily be removed for quick, easy re-keying, so retrofitting a current building is simple. The T Series is constructed with a compression spring that allows the lock to exceed ANSI/BHMA Grade 1 testing requirements. Perfect for high-use institutional applications, the T Series lock delivers by providing a solid product at a solid price.
TypeTitleURL
brochure/sales-materialFalcon Finishes Charthttps://dvwi9lnoau63q.cloudfront.net/falcon/miscellaneous/ALLEGION_finish-chart.pdf
catalogFalcon Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/falcon/catalog/Falcon_Locks_Catalog_110449.pdf
data-sheetT Series Data sheethttps://dvwi9lnoau63q.cloudfront.net/falcon/miscellaneous/Falcon_T_Series_Data_Sheet_106191.pdf
T/W Series Data Sheethttps://dvwi9lnoau63q.cloudfront.net/falcon/miscellaneous/Falcon_T_Series_and_W_Series_Data_Sheet_110522.pdf
installation-instructionsT-Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/falcon/installation_instructions/106829.pdf
T-Series Installation Instructions - Electricalhttps://dvwi9lnoau63q.cloudfront.net/falcon/installation_instructions/110164.pdf
price-book2024 Falcon Price Book (effective 3.2024)https://dvwi9lnoau63q.cloudfront.net/falcon/pricebooks/FAL_pricebook_3-2024.pdf
product-guideFalcon Cylindrical Lock Guidehttps://dvwi9lnoau63q.cloudfront.net/falcon/miscellaneous/Falcon_Cylindrical_Lock_Guide_110894.pdf
sell-sheetT and W Series Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/falcon/sell-sheets/Falcon_T_Series_and_W_Series_Data_Sheet_110522.pdf
T-Series Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/falcon/literature/106191.pdf
service-manualT-Series Service Manualhttps://dvwi9lnoau63q.cloudfront.net/falcon/manuals/108002.pdf

Specifications

Brand:
Falcon
Commercial Residential:
Commercial
Base Material:
Brass Bronze
ADA:
Yes
Series:
T Series Grade 1 Cylindrical Lever Locks
Manufacturer:
Falcon
Bore Hole Diameter (in):
2-1/8"
Parent Manufacturer:
Allegion
Backset (in):
2-3/4"
Certification:
ANSI A156.2, Series 4000, Grade 1, UL Listed
Can Be Keyed:
No
Door Range (Thickness):
1-3/8" - 2-1/8"
Grade:
Grade 1
Finish Description:
Satin Chrome
Function:
Privacy
Includes Cylinder(s)?:
No
Fire Rated:
3 Hours {A}
Cylinder Type:
Keyless
Door Handing:
Non-handed
Finish:
626/US26D
Electronic:
No
Lever/Knob/Pull Design:
Avalon
Specifications Bullet 2:
Avalon Lever
Keyway:
Not Applicable
Latch Bore Diameter (in):
1"
Latch Number:
23981137
Latch Throw (in):
1/2"
Specifications Bullet 1:
Grade 1 Privacy Function Cylindrical Lockset
Lever/Knob/Pull:
Lever
Latch Dimensions:
1-1/8" x 2-1/4"
Latch Description:
Spring Latch
Specifications Bullet 4:
1-1/8" x 2-1/4" Spring Latch
Specifications Bullet 5:
1-1/4" x 4-7/8" ASA Strike
Specifications Bullet 3:
2-3/4" Backset
Specifications Bullet 10:
ANSI A156.2, Series 4000, Grade 1, UL Listed
Specifications Bullet 6:
3-1/4" Projection
Specifications Bullet 9:
2-1/8" Bore Hole Diameter
Specifications Bullet 11:
10 Year Warranty
Specifications Bullet 7:
3-1/2" Rose
Specifications Bullet 8:
For Doors 1-3/8" - 2-1/8" Thick
Maximum Door Thickness (in):
2-1/8"
Minimum Door Thickness (in):
1-3/8"
Product Warranty:
10 Year Warranty
Projection (in):
3-1/4"
Rose/Escutcheon Design:
Not Applicable
Strike Description:
ASA Strike
Strike Number:
5164
Rose/Escutcheon:
Rose
Strike Dimensions:
1-1/4" x 4-7/8"
Rose/Escutcheon Dimensions (in):
3-1/2"
Selling Quantity:
1
UOM:
1
Uid:
FAL100T301SA626
Url Title:
t301s-a-626
Title:
T301S A 626 Falcon Cylindrical Lock
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Cylindrical Lock
Last Modified:
2023-02-26T07:12:35+00:00
Last Pricing:
2023-02-24T00:00:00+00:00
Msrp:
517
Avg Lead Time:
40
Popularity:
3
Pack Weight:
5.5
Pack Length:
9.25
Pack Width:
7
Pack Height:
3.75
Pack Volume:
242.8125
Ul Listing:
A Label
Ansi Code:
ANSI/BHMA A156.2, Series 4000, Grade 1
Restrictions:
None
Country Of Origin:
Mexico
Baa Qualified:
Yes
Limited Warranty:
10 Years
Accessible:
Yes
Unit Of Measure:
Each
Vendor:
Allegion

Warranty Information

10 Year Warranty
