Hager 5200-PAR HD ALM Grade 1 Surface Closer Push or Pull Side Parallel Arm Mounting Extra Heavy Duty Arm Size 1 to 6 Adjustable Aluminum Finish Non-Handed

Hager

Write a Review
SKU:
5200-PAR HD ALM
$242.87
Hager 5200-PAR HD ALM Grade 1 Surface Closer Push or Pull Side Parallel Arm Mounting Extra Heavy Duty Arm Size 1 to 6 Adjustable Aluminum Finish Non-Handed
UPC:
840067658000
$242.87

Descriptions

5200 Series Closers are engineered and designed to offer the ideal combination of appearance and reliability. The 5200 Series Closers are constructed of aluminum alloy to be installed on exterior and interior doors. They are designed and engineered for reliability and superior performance. The commercial applications ideal for these closers include schools, medical facilities, institutions and hospitals as well as office buildings and any entrance door with high foot traffic.
TypeTitleURL
dimensional-drawings5200 Series Door Sizinghttps://dvwi9lnoau63q.cloudfront.net/hager/installation/5200_doorsizingchart_relatedfiles.pdf
instruction-sheets5100 Series Door Closer - Delayed Action Instruction Sheethttps://dvwi9lnoau63q.cloudfront.net/hager/installation/5100SeriesDelayedActionInstallationInstructions.pdf
5100 Series Instruction Sheethttps://dvwi9lnoau63q.cloudfront.net/hager/installation/5100_series-installation-instructions.pdf
5125, 5106, 5108, 5961 Heavy Duty Parallel Arm Instruction Sheethttps://dvwi9lnoau63q.cloudfront.net/hager/installation/hager-5961-armi-cl00238.pdf
5200 Series Door Closer Instruction Sheetshttps://dvwi9lnoau63q.cloudfront.net/hager/installation/Hager-5200-installationi-cl00187.pdf
5300 Series Door Closer Instruction Sheethttps://dvwi9lnoau63q.cloudfront.net/hager/installation/5300_pg1-6_8_14_06-1.pdf
5400 Series Non-Hold Open Door Closer Instruction Sheetshttps://dvwi9lnoau63q.cloudfront.net/hager/installation/5400_install_pgs_11-3-05.pdf
literatureHager - Door Closer ANSI Reference Sheethttps://dvwi9lnoau63q.cloudfront.net/hager/literature/5200-door-closer-ansi-reference-sheet.pdf
Hager Door Closers - How to Order Guidehttps://dvwi9lnoau63q.cloudfront.net/hager/literature/hager-5100series-door-closers-how-to-order.pdf
Hager Test Report for 5400 Series Door Closerhttps://dvwi9lnoau63q.cloudfront.net/hager/installation/5400_series-test_report-diagram.pdf
price-book2022 Hager Price Bookhttps://dvwi9lnoau63q.cloudfront.net/hager/pricebooks/HAGER_pricebook_16.12_12-2022.pdf
videoAdjusting the 5100 Door Closerhttps://youtu.be/F08DtZpJr6E
Hager 8400 Series Low Energy Door Power Operator Installationhttps://youtu.be/wA1pk6xkzzE

Specifications

Brand:
Hager
Specifications Bullet 10:
Includes Sex Nuts, Bolts and Screws
Body Base Material:
Aluminum
All Weather Fluid:
Yes
Door Range (Thickness):
-
Specifications Bullet 3:
Size 1-6
Closing Speed Adjustment:
Yes
Country of Origin:
United States
Advanced Backcheck:
No
Commercial Residential:
Commercial
Piston Diameter (in):
1-1/4"
Cover Type:
Slim Profile Cover
Arm Type:
Heavy Duty Arm
Specifications Bullet 5:
Non-handed
Door Handing:
Non-handed
Hold Open Type:
Not Applicable
ADA:
Yes
Latch Speed Adjustment:
Yes
Series:
Hager Door Coordinators and Closers
Specifications Bullet 11:
ANSI A156.4 Grade 1, A117.1 ADA, UL Listed
Fire Rated:
3 Hours {A}
Certification:
ANSI A156.4 Grade 1, A117.1 ADA, UL Listed
Grade:
Grade 1
Type:
Door Closers and Operators
Specifications Bullet 8:
Aluminum Body
Product Warranty:
Lifetime Warranty
Degree Swing:
180 Degree Swing
UOM:
1
Specifications Bullet 1:
Grade 1 Surface Door Closer
Finish Description:
Aluminum
Specifications Bullet 4:
Parallel Arm Mount
Hold Open:
No
Finish:
689/US28
Maximum Door Weight (lbs):
225 lbs Maximum Door Weight
Cover Material:
Plastic
Specifications Bullet 12:
Lifetime Warranty
Backcheck:
Yes
Specifications Bullet 7:
Plastic Slim Profile Cover
UPC:
840067658000
Interior/Exterior:
Interior/Exterior
Specifications Bullet 6:
180 Degree Swing
Manufacturer:
Hager
Selling Quantity:
1
Specifications Bullet 9:
1-1/4" Piston Diameter
Screw Pack:
Sex Nuts, Bolts and Screws
Size:
Size 1-6
Specifications Bullet 2:
Heavy Duty Arm
Mount:
Parallel Arm Mount
Uid:
HAG5200PARHDALM
Url Title:
5200-par-hd-alm
Title:
5200-PAR HD ALM Hager Surface Closers
Sub Type:
Surface Closers
Last Modified:
2023-02-13T08:43:23+00:00
Last Pricing:
2022-07-13T00:00:00+00:00
Msrp:
367.15
Avg Lead Time:
6
Finish Family:
Matte Silver
Finish B:
ALM
Finish B Description:
Sprayed Aluminum
Popularity:
9
Limited Warranty:
Lifetime
Vendor:
Hager

Warranty Information

Lifetime Warranty
