  • Norton 8301 689 Grade 1 Surface Closer Hydraulic Tri Mount Push or Pull Side Mounting Regular Arm Adjustable Backcheck Plastic Cover Size 1 to 6 Aluminum Painted Finish Non-Handed

Norton 8301 689 Grade 1 Surface Closer Hydraulic Tri Mount Push or Pull Side Mounting Regular Arm Adjustable Backcheck Plastic Cover Size 1 to 6 Aluminum Painted Finish Non-Handed

Norton

Write a Review
SKU:
8301 689
$192.98
Norton 8301 689 Grade 1 Surface Closer Hydraulic Tri Mount Push or Pull Side Mounting Regular Arm Adjustable Backcheck Plastic Cover Size 1 to 6 Aluminum Painted Finish Non-Handed
$192.98

Descriptions

The 8000 Series Door Closers offer the ideal combination of appearance, reliability and durability in today's market. With features such as staked valves, precise valve adjustment and a complete range of arm and cover options, this closer can meet virtually any application challenge. The 8000 Series Door Closers exceed 10 million cycles, have a rack and pinion design with a cast aluminum body and are non-handed. A slim-line plastic cover is standard with the 8301 closer and a full plastic cover is standard with the 8501 closer.
TypeTitleURL
catalog8000 Surface Closerhttps://dvwi9lnoau63q.cloudfront.net/norton/catalogs/43085_Norton_8000.pdf
installation8000 Tri-Stylehttps://dvwi9lnoau63q.cloudfront.net/norton/installation/80-9380-2206-020.pdf
8000H Tri-Stylehttps://dvwi9lnoau63q.cloudfront.net/norton/installation/80-9380-2207-020.pdf
8000ST, PS8000ST, Slide Track, Push or Pull, Non-Hold Open or Hold Openhttps://dvwi9lnoau63q.cloudfront.net/norton/installation/80-9380-2213-020.pdf
8040ST, PS8040ST, Low Profile Slide Track, Push or Pull, Non-Hold Open or Hold Openhttps://dvwi9lnoau63q.cloudfront.net/norton/installation/80-9380-2212-020.PDF
8080, Low Profile Arm, Non-Hold Open Onlyhttps://dvwi9lnoau63q.cloudfront.net/norton/installation/80-9380-2210-020.pdf
CLP8000, CloserPlushttps://dvwi9lnoau63q.cloudfront.net/norton/installation/80-9380-2209-020.pdf
CLP8000R; CloserPlus Ramp Hold Open Armhttps://dvwi9lnoau63q.cloudfront.net/norton/installation/80-9380-2216-020.pdf
JS8301, JS8501 - Top Jamb Only; Non-Hold Openhttps://dvwi9lnoau63q.cloudfront.net/norton/installation/80-9380-2218-020.pdf
P8301, P8501 - Parallel Arm Only; Non-Hold Openhttps://dvwi9lnoau63q.cloudfront.net/norton/installation/80-9380-2219-020.pdf
PR8000, Parallel Rigid Arm, Non-Hold Open or Hold Openhttps://dvwi9lnoau63q.cloudfront.net/norton/installation/80-9380-2209-020.pdf
R8000, Regular Rigid Armhttps://dvwi9lnoau63q.cloudfront.net/norton/installation/80-9380-2215-020.pdf
S8301, S8501 - Regular Arm Only; Non-Hold Openhttps://dvwi9lnoau63q.cloudfront.net/norton/installation/80-9380-2217-020.pdf
UNI8000, Unitrolhttps://dvwi9lnoau63q.cloudfront.net/norton/installation/80-9380-2208-020.pdf
price-books2023 Norton Price Book (effective 4.17.2023)https://dvwi9lnoau63q.cloudfront.net/norton/pricebooks/NOR_RIX_pricebook_4-2023.pdf
product-bulletins8000 Closer Exceeds 15 Million Cycleshttps://dvwi9lnoau63q.cloudfront.net/norton/product-bulletins/43320_Norton_8000_Exceeds_15_Mil_Cycles.pdf

Specifications

Brand:
Norton
Electronic:
No
Hold Open:
No
Finish Description:
Aluminum Painted
Cover Type:
Slim Profile Cover
Selling Quantity:
1
Specifications Bullet 11:
ANSI A156.4, Grade 1, ANSI A117.1, UL Listed
Finish:
689/US28
Specifications Bullet 8:
Aluminum Body
Cover Material:
Plastic
Specifications Bullet 2:
Regular Arm
Specifications Bullet 10:
Includes Self Drilling Screws
Door Range (Thickness):
-
ADA:
Yes
Fire Rated:
3 Hours {A}
Specifications Bullet 9:
1-1/4" Piston Diameter
Latch Speed Adjustment:
Yes
Maximum Door Weight (lbs):
225 lbs Maximum Door Weight
Grade:
Grade 1
Specifications Bullet 4:
Tri Mount
Piston Diameter (in):
1-1/4"
Specifications Bullet 1:
Grade 1 Surface Door Closer
Degree Swing:
180 Degree Swing
Specifications Bullet 3:
Size 1-6
Interior/Exterior:
Interior/Exterior
Specifications Bullet 6:
180 Degree Swing
Manufacturer:
Norton
Door Handing:
Non-handed
Specifications Bullet 12:
25 Year Warranty
Hold Open Type:
Not Applicable
Size:
Size 1-6
Series:
8301 Series Closers
UOM:
1
Specifications Bullet 7:
Plastic Slim Profile Cover
Mount:
Tri Mount
Body Base Material:
Aluminum
Product Warranty:
25 Year Warranty
Backcheck:
Yes
Screw Pack:
Self Drilling Screws
Type:
Door Closers and Operators
Specifications Bullet 5:
Non-handed
Advanced Backcheck:
No
Parent Manufacturer:
Assa Abloy
All Weather Fluid:
Yes
Certification:
ANSI A156.4, Grade 1, ANSI A117.1, UL Listed
Arm Type:
Regular Arm
Base Material:
Varies
Closing Speed Adjustment:
Yes
Commercial Residential:
Commercial
Uid:
NOR3008301689
Url Title:
8301-689
Title:
8301 689 Norton Surface Closers
Sub Type:
Surface Closers
Last Modified:
2023-02-28T05:12:31+00:00
Last Pricing:
2022-09-16T00:00:00+00:00
Msrp:
518
Avg Lead Time:
70
Finish Family:
Matte Silver
Popularity:
3
Pack Weight:
8
Pack Length:
15.25
Pack Width:
6.25
Pack Height:
3.5
Pack Volume:
333.59375
Ul Listing:
UL10C
Ansi Code:
ANSI A156.4
Country Of Origin:
USA
Baa Qualified:
Yes
Limited Warranty:
25 Years
Accessible:
Yes
Unit Of Measure:
Each
Unit Of Measure 2:
Case
Unit Of Measure 2 Qty:
4
Vendor:
Assa Abloy

Warranty Information

25 Year Warranty
