Von Duprin 99EO 4 US28 Grade 1 Rim Exit Bar Wide Stile Pushpad 48 Device Exit Only Less Trim Hex Key Dogging Satin Aluminum Clear Anodized Finish Non-handed

Von Duprin

Write a Review
SKU:
99EO 4 US28
$1,307.34
Von Duprin 99EO 4 US28 Grade 1 Rim Exit Bar Wide Stile Pushpad 48 Device Exit Only Less Trim Hex Key Dogging Satin Aluminum Clear Anodized Finish Non-handed
UPC:
043156978144
$1,307.34

Descriptions

98 and 99 Rim exit devices for all types of single and double doors with mullion, UL listed for panic exit hardware. Devices are ANSI A156.3 - 2008 Grade 1
TypeTitleURL
brochure/sales-materialVon Duprin Finishes Charthttps://dvwi9lnoau63q.cloudfront.net/vonduprin/miscellaneous/ALLEGION_finish-chart.pdf
catalogVon Duprin 98/99 Series Cataloghttps://dvwi9lnoau63q.cloudfront.net/vonduprin/catalogs/Von_Duprin_98.99_Series_Catalog_106590.pdf
data-sheetChexit (CX) Data Sheethttps://dvwi9lnoau63q.cloudfront.net/vonduprin/literature/Von_Duprin_Chexit_Data_Sheet_110102.pdf
QEL Data Sheethttps://dvwi9lnoau63q.cloudfront.net/vonduprin/literature/106586.pdf
installation-instructionsQEL 98/99 Baseplate Conversion Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/vonduprin/installation-instructions/110746.pdf
QEL Conversion Kit for 98/99 Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/vonduprin/installation-instructions/110745.pdf
Video: 98/99 EL - How to Convert to QELhttps://youtu.be/WKm8fBsjROw
Video: 98/99 Rim Exit Device Installationhttps://youtu.be/j5Wug77AVbM
Von Duprin 22/98/99 Series Device with Active Trim Cylinder Tailpiece Guide Retrofit Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/vonduprin/installation-instructions/Von_Duprin_22_98_99_Series_Device_with_Active_Trim_Cylinder_Tailpiece_Guide_Retrofit_Installation_Instructions_109268.pdf
Von Duprin 33/35 and 98/99 ALK Alarm Kit Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/vonduprin/installation-instructions/107710.pdf
Von Duprin 33/35 and 98/99 End Cap Retrofit Kit Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/vonduprin/installation-instructions/109265.pdf
Von Duprin 33/99 LD Kit Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/vonduprin/installation-instructions/109278.PDF
Von Duprin 98/99 Center Case Kit Less Cover Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/vonduprin/installation-instructions/107720.pdf
Von Duprin 98/99 Rim Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/vonduprin/installation-instructions/107600.pdf
Von Duprin Pneumatic Exit Device Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/vonduprin/installation-instructions/107614.pdf
miscellaneous98/99 Series Bronze Finish Comparisonhttps://dvwi9lnoau63q.cloudfront.net/vonduprin/literature/VD_98_99_DarkBrownReferenceChart_rev2_11_2014.pdf
Exit Device Fire Label Specificationshttps://dvwi9lnoau63q.cloudfront.net/vonduprin/literature/FireRatingChart-VD.pdf
Quiet Electric Latch FAQhttps://dvwi9lnoau63q.cloudfront.net/vonduprin/literature/110624.pdf
price-book2024 Von Duprin Price Book (effective 3.2024)https://dvwi9lnoau63q.cloudfront.net/vonduprin/pricebooks/VON_pricebook_3-2024.pdf
sell-sheetQEL Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/vonduprin/literature/103226.pdf
Von Duprin Exit Alarm Kit Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/vonduprin/literature/105255.pdf
service-manual98/99 Rim Exit Device Service Manualhttps://dvwi9lnoau63q.cloudfront.net/vonduprin/common-part-manuals/98-99_Rim_Exit_Device_Service_Manual.pdf
templateCX98/99 & 98-F/99-F TP, K, & L Series Wood Door Templatehttps://dvwi9lnoau63q.cloudfront.net/vonduprin/wood-templates/108768.pdf
CX98/99 NL Series Wood Door Templatehttps://dvwi9lnoau63q.cloudfront.net/vonduprin/wood-templates/108766.pdf
EL, SS, CX99 Series Rim Devices on Pair of Doors with Mullion Hinge Stile Preparation Wood Door Templatehttps://dvwi9lnoau63q.cloudfront.net/vonduprin/wood-templates/108934.pdf
video10 Things You Need to Know About the Von Duprin Chexithttps://youtu.be/JAhF99eIAMg
Intro to Door Hardware: Types of Panic Hardwarehttps://youtu.be/t96GpTVqesw
Introduction to Von Duprin Exit Deviceshttps://youtu.be/t-9QD-Oh3Qc
wiring-diagramChexit Wiring Instructions - 2016https://dvwi9lnoau63q.cloudfront.net/vonduprin/literature/NewChexitwiringinstructions2016.pdf
Chexit Wiring Instructions - 2021https://dvwi9lnoau63q.cloudfront.net/vonduprin/wiring/Chexit_Wiring_Instructions_2021.pdf

Specifications

Brand:
Von Duprin
Box Weight (lbs):
17 lbs
Dogging Option:
Yes
Base Material:
Aluminum
Grade:
Grade 1
Minimum Door Thickness (in):
1-3/4"
Cylinder Type:
Keyless
Finish:
628/US28
Box Height (in):
10-1/2"
Electronic:
No
Box Depth (in):
49-1/4"
Certification:
ANSI A156.3-2014, Grade 1
Specifications Bullet 2:
4" Minimum Stile
Specifications Bullet 8:
3-13/16" Full Extension
Specifications Bullet 3:
2-3/4" Backset
Door Material:
Metal/Wood
Commercial Residential:
Commercial
Finish Description:
Satin Aluminum Clear Anodized
Backset (in):
2-3/4"
Includes Cylinder(s)?:
No
Product Width (in):
48"
Box Width (in):
5"
Manufacturer:
Von Duprin
Specifications Bullet 9:
3/4" Dead Latch
Keyway:
Not Applicable
Specifications Bullet 14:
3 Year Warranty
Fire Rated:
No
Maximum Door Thickness (in):
2-1/8"
Door Width Minimum (in):
34"
Parent Manufacturer:
Allegion
Specifications Bullet 1:
Surface Exit Device, Exit Only
End Cap Material:
Cast Zinc
Center Case Dimensions:
8" x 2-3/4" x 2-3/8"
Latch Description:
Dead Latch
Specifications Bullet 11:
Cast Zinc End Cap
Dogging Type:
Hex Key Dogging
Strike Number:
299
Door Width Maximum (in):
48"
Specifications Bullet 4:
8" x 2-3/4" x 2-3/8" Center Case Dimension
Screw Pack:
Machine Screws
Door Range (Thickness):
1-3/4" - 2-1/8"
Door Height (in):
Not Applicable
Type:
Exit Devices
Strike Description:
Roller Strike
Projection (in):
3-13/16"
Specifications Bullet 6:
For Doors 1-3/4" - 2-1/8" Thick
Latch Throw (in):
3/4"
Selling Quantity:
1
Series:
99 Series Rim Exit Device
Specifications Bullet 5:
For Doors 34" - 48" Wide
Specifications Bullet 12:
Includes Machine Screws
UOM:
1
Specifications Bullet 13:
ANSI A156.3-2014, Grade 1
Door Handing:
Non-handed
Specifications Bullet 10:
Hex Key Dogging
Country of Origin:
United States
Minimum Stile (in):
4"
Product Warranty:
3 Year Warranty
Specifications Bullet 7:
For Metal/Wood Doors
Function:
Exit Only
Uid:
VON10099EO4US28
Url Title:
99eo-4-us28
Title:
99EO 4 US28 Von Duprin Rim Exit Devices
Sub Type:
Rim Exit Devices
Last Modified:
2023-02-28T05:12:38+00:00
Last Pricing:
2023-02-24T00:00:00+00:00
Msrp:
1746
Avg Lead Time:
84
Finish Family:
Matte Silver
Popularity:
3
Pack Weight:
17
Pack Length:
49
Pack Width:
5
Pack Height:
10.5
Pack Volume:
2572.5
Ul Listing:
UL 305
Ansi Code:
A156.3
Restrictions:
None
Baa Qualified:
Yes
Limited Warranty:
3 Years
Accessible:
No
Unit Of Measure:
Each
Unit Of Measure 2:
Case
Unit Of Measure 2 Qty:
3
Vendor:
Allegion
Assembly Item:
1

Warranty Information

3 Year Warranty
