  • Corbin Russwin DC3220 689 M54 Grade 1 Surface Door Closer Double Lever Arm Regular Push Side Mount Size 1-6 Full Cover Aluminum Painted Finish Non-Handed

Corbin Russwin DC3220 689 M54 Grade 1 Surface Door Closer Double Lever Arm Regular Push Side Mount Size 1-6 Full Cover Aluminum Painted Finish Non-Handed

Corbin Russwin

Write a Review
SKU:
DC3220 689 M54
$371.04
Corbin Russwin DC3220 689 M54 Grade 1 Surface Door Closer Double Lever Arm Regular Push Side Mount Size 1-6 Full Cover Aluminum Painted Finish Non-Handed
UPC:
840067639016
$371.04

Descriptions

The mid-priced, cost-effective choice for high-traffic situations. The DC3000 Series Door Closers fulfill security and life safety requirements by ensuring reliable latching for access control and fire code compliance, along with ease of operation and precise adjustability for barrier-free code compliance. Ideal for virtually all door openings and draft conditions in both new construction and renovation
TypeTitleURL
catalogDC3000 Series Cataloghttps://dvwi9lnoau63q.cloudfront.net/corbin/catalogs/aadss1004466.pdf
price-book2023 Corbin Price Book (updated 10.2023)https://dvwi9lnoau63q.cloudfront.net/corbin/pricebooks/COR_pricebook_10-2023.pdf
wiring-diagrams-and-instructionsDC3200 Non-Hold Open, Regular Arm Application with A10 Heavy Duty Armhttps://dvwi9lnoau63q.cloudfront.net/corbin/wiring-diagrams-instructions/80-9330-3004-152.pdf
DC3200 Regular, Parallel or Top Jamb Mounthttps://dvwi9lnoau63q.cloudfront.net/corbin/wiring-diagrams-instructions/80-9330-3000-152.pdf
DC3210 x HD Parallel Arm (A2, A4 or A5)https://dvwi9lnoau63q.cloudfront.net/corbin/wiring-diagrams-instructions/80-9330-3005-152.pdf
DC3210 x HD Parallel Arm (A3)https://dvwi9lnoau63q.cloudfront.net/corbin/wiring-diagrams-instructions/80-9330-3006-152.pdf
DC3210 x HD Spring Stop Parallel Arm (A11 or A12)https://dvwi9lnoau63q.cloudfront.net/corbin/wiring-diagrams-instructions/80-9330-3003-152.pdf
ED3000 Series Lever Handle Controlhttps://dvwi9lnoau63q.cloudfront.net/corbin/wiring-diagrams-instructions/FM36905-14.pdf
ED3200/ED3200A Series Rim Type Exit Devicehttps://dvwi9lnoau63q.cloudfront.net/corbin/wiring-diagrams-instructions/FM36205-15.pdf
ED3400/ED3400A Series SVR Exit Deviceshttps://dvwi9lnoau63q.cloudfront.net/corbin/wiring-diagrams-instructions/FM36105-15.pdf
ED3600 & ED3600A Series Mortise Exit Devicehttps://dvwi9lnoau63q.cloudfront.net/corbin/wiring-diagrams-instructions/FM36305-15.pdf

Specifications

Brand:
Corbin Russwin
Parent Manufacturer:
Assa Abloy
Series:
DC3000 Series Door Closers
ADA:
Yes
Advanced Backcheck:
No
Manufacturer:
Corbin Russwin
Arm Type:
Regular Arm
Body Base Material:
Cast Iron
Backcheck:
Yes
All Weather Fluid:
Yes
Base Material:
VARIES
Closing Speed Adjustment:
Yes
Certification:
ANSI/BMHA A 156.4, Grade 1 Certified
Commercial Residential:
Commercial
Country of Origin:
United States
Cover Material:
Plastic
Door Range (Thickness):
-
Door Handing:
Non-handed
Cover Type:
Full Body Cover
Electronic:
No
Degree Swing:
180 Degree Swing
Finish:
689/US28
Grade:
Grade 1
Finish Description:
Aluminum Painted
Fire Rated:
3 Hours {A}
Hold Open:
No
Hold Open Type:
Not Applicable
Specifications Bullet 1:
Grade 1 Surface Door Closer
Latch Speed Adjustment:
Yes
Specifications Bullet 2:
Regular Arm
Interior/Exterior:
Interior/Exterior
Specifications Bullet 3:
Size 1-6
Specifications Bullet 4:
Push Side Mount
Specifications Bullet 6:
180 Degree Swing
Specifications Bullet 5:
Non-handed
Specifications Bullet 7:
Plastic Full Body Cover
Specifications Bullet 12:
15 Year Warranty
Specifications Bullet 11:
ANSI/BMHA A 156.4, Grade 1 Certified
Specifications Bullet 8:
Cast Iron Body
Specifications Bullet 10:
Includes Self Drilling Screws
Specifications Bullet 9:
1-3/8" Piston Diameter
Mount:
Push Side Mount
Maximum Door Weight (lbs):
225 lbs Maximum Door Weight
Screw Pack:
Self Drilling Screws
Product Warranty:
15 Year Warranty
Piston Diameter (in):
1-3/8"
Selling Quantity:
1
Screw Pack Designation:
M54
Size:
Size 1-6
UOM:
1
Type:
Door Closers and Operators
UPC:
840067639016
Uid:
COR300DC3220689M54
Url Title:
dc3220-689-m54
Title:
DC3220 689 M54 Corbin Russwin Surface Closers
Sub Type:
Surface Closers
Last Modified:
2022-09-19T09:27:59+00:00
Last Pricing:
2022-09-16T00:00:00+00:00
Msrp:
530
Avg Lead Time:
43
Finish Family:
Matte Silver
Popularity:
9
Pack Weight:
11.4
Pack Length:
13.75
Pack Width:
7.375
Pack Height:
3.875
Pack Volume:
392.9492188
Limited Warranty:
15 Years
Unit Of Measure:
Each
Unit Of Measure 2:
Case
Unit Of Measure 2 Qty:
4
Vendor:
Assa Abloy

Warranty Information

15 Year Warranty
