Arrow MK33-TA-26D Grade 2 Asylum Cylindrical Lock Tudor Knob Conventional Cylinder Satin Chrome Finish Non-handed

Arrow

Write a Review
SKU:
MK33-TA-26D
$174.31
Arrow MK33-TA-26D Grade 2 Asylum Cylindrical Lock Tudor Knob Conventional Cylinder Satin Chrome Finish Non-handed
$174.31

Descriptions

Arrow MK Series offer the designer, architect and contractor simple solutions to accessibility requirements. Their clean designs, architectural finishes and available functions make them ideal for commercial applications where heavy duty grade one hardware may not be necessary.
TypeTitleURL
cut-sheetMK Series Cut Sheethttps://dvwi9lnoau63q.cloudfront.net/arrow/cut-sheet/MKSeries.pdf
templateMK Series Dummy Knob Templatehttps://dvwi9lnoau63q.cloudfront.net/arrow/template/MK_Template_Dummy_1.pdf
MK Series Templatehttps://dvwi9lnoau63q.cloudfront.net/arrow/template/MK_Series_Template_1.pdf

Specifications

Brand:
Arrow
Backset (in):
2-3/4"
Latch Dimensions:
1-1/8" x 2-1/4"
Fire Rated:
3 Hours {A}
Commercial Residential:
Commercial
Parent Manufacturer:
Assa Abloy
Latch Number:
114
Electronic:
No
Cylinder Type:
Conventional
Bore Hole Diameter (in):
2-1/8"
Function:
Asylum
Series:
MK Series Grade 2 Cylindrical Knob Locks
Certification:
ANSI A156.2, Series 4000, Grade 2, UL Listed
Finish:
626/US26D
Minimum Door Thickness (in):
1-3/8"
Keyway:
A Keyway
ADA:
No
Specifications Bullet 10:
2-1/8" Bore Hole Diameter
Specifications Bullet 8:
2-9/16" Rose
Specifications Bullet 6:
1-1/8" x 2-3/4" T-Strike
Country Of Origin:
Mexico
Can Be Keyed:
Yes
Latch Bore Diameter (in):
1"
Latch Description:
Dead Latch
Product Warranty:
1 Year Warranty
Finish Description:
Satin Chrome
Lever/Knob/Pull:
Knob
Specifications Bullet 3:
Conventional A Keyway
Selling Quantity:
1
Door Range (Thickness):
1-3/8" - 1-3/4"
Strike Dimensions:
1-1/8" x 2-3/4"
Rose/Escutcheon Design:
Not Applicable
Lever/Knob/Pull Design:
Tudor
Specifications Bullet 12:
1 Year Warranty
Door Handing:
Non-handed
Base Material:
Brass, Bronze
Latch Throw (in):
1/2"
Strike Number:
300
Specifications Bullet 1:
Grade 2 Asylum Function Cylindrical Lockset
Includes Cylinder(s)?:
Yes
Specifications Bullet 4:
2-3/4" Backset
Specifications Bullet 2:
Tudor Knob
Specifications Bullet 7:
2-7/16" Projection
Specifications Bullet 11:
ANSI A156.2, Series 4000, Grade 2, UL Listed
Projection (in):
2-7/16"
Grade:
Grade 2
Specifications Bullet 5:
1-1/8" x 2-1/4" Dead Latch
Strike Description:
T-Strike
Manufacturer:
Arrow
Maximum Door Thickness (in):
1-3/4"
Specifications Bullet 9:
For Doors 1-3/8" - 1-3/4" Thick
UOM:
1
Rose/Escutcheon Dimensions (in):
2-9/16"
Rose/Escutcheon:
Rose
Uid:
ARR100MK33TA26D
Url Title:
mk33ta-26d
Title:
Arrow MK33-TA-26D Cylindrical Lock
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Cylindrical Lock
Last Modified:
2023-02-26T06:48:16+00:00
Last Pricing:
2022-09-16T00:00:00+00:00
Msrp:
250
Avg Lead Time:
41
Finish Family:
Matte Silver
Popularity:
3
Pack Weight:
1.5
Pack Length:
7.5
Pack Width:
3.5
Pack Height:
2.625
Pack Volume:
68.90625
Ul Listing:
BHMA A156.2, Series 4000, Grade 2, UL Listed
Ansi Code:
F87
Limited Warranty:
1 Year Warranty
Unit Of Measure:
Each
Vendor:
Assa Abloy

Warranty Information

1 Year Warranty
