Schlage ND10S SPA 622 Grade 1 Passage Latch Sparta Lever Non-Keyed Matte Black Finish Non-Handed

Schlage

Write a Review
SKU:
ND10S SPA 622
$422.04
$422.04

Descriptions

Walter Schlage invented the cylindrical lock in 1920. Since then, the Schlage Lock Company has consistently delivered innovation and continuous improvement. In that tradition, The ND Series Cylindrical Lockset is a proven, easy to install product with extensive function, keying, trim and finish capabilities that work in nearly any application. The Schlage ND Series Locksets are commonly used in Healthcare, Education, Government, Office, Retail, and other commercial applications. The ND Series has been certified Grade 1; exceeding 3-million operating cycles without failure. This provides confidence that the lock will last within any type of facility. Finally, Schlage has incorporated wire-wireless capabilities that meet the access control and security needs of every facility owner.
TypeTitleURL
brochure/sales-materialSchlage Finishes Charthttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/ALLEGION_finish-chart.pdf
catalogND Series Locks & Latches Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/Allegion_2014_Commercial_Product_Catalogue_ND_Series_0114.pdf
ND Series Mechanical Grade 1 Cylindrical Locks Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/Schlage_ND_Series_Catalog_106501.pdf
ND Series Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/106501.pdf
installation-guideSchlage ND-Series Standard Installation Instructions (locks manufactured after 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/NDSeriesStandInstallInstructionslocksmanafter8-15-2012.pdf
Schlage ND-Series Standard Installation Instructions (locks manufactured before 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/NDStandInstallInstructionslocksmanubefore8-15-2012.pdf
installation-instructionsND Series Electrified Functions Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108353.PDF
ND Series Electrified Functions Installation Instructions (solenoid, mfg before 3-14-2016)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/111248.pdf
ND Series Hollow Metal Door Spacer Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/107544.pdf
ND170 Installation Instructions (locks manufactured after 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/108996.pdf
ND170 Installation Instructions (locks manufactured before 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/106121.pdf
ND25 Installation Instructions (locks manufactured after 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/108995.pdf
ND25 Installation Instructions (locks manufactured before 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/106122.pdf
Video: ND Series Lock Installationhttps://youtu.be/U6fUoLLH7Kw
keyway-diagramEverest 29 S Keyway Family Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/keywaydiagram/S-Family_Open_Keyway_Diagram.pdf
Everest Keyways Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/keywaydiagram/Everest_Keyways.pdf
Observe Keyways for Classic Conventional Cylinders Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/keywaydiagram/Convetional_Observe_Keyways.pdf
Observe Keyways for Classic Primus XP Cylinders Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/keywaydiagram/Primus_Observe_Keyways.pdf
miscellaneousND Series Locks & Latches Warrantyhttps://dvwi9lnoau63q.cloudfront.net/schlage/miscellaneous/Schlage_ND_Series_Commercial_Warranty_December_2013.pdf
price-book2024 Schlage Commercial Price Book (effective 3.2024)https://dvwi9lnoau63q.cloudfront.net/schlage/pricebooks/SCH_pricebook_3-2024.pdf
sell-sheetSchlage ND Series Electrified Cylindrical Locks Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/Schlage_ND_Series_Data_Sheet_110875.pdf
Schlage ND Series Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/106486NDsellsheet.pdf
service-manualSchlage ND Series Service Manualhttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/2021_Schlage_ND_Series_Service_Manual.pdf
templateND Series Templatehttps://dvwi9lnoau63q.cloudfront.net/schlage/templates/Schlage_ND_Series_Template.pdf

Specifications

Brand:
Schlage
Latch Number:
13-248
Backset (in):
2-3/4"
Latch Dimensions:
1-1/8" X 2-1/4"
Rose/Escutcheon:
Rose
Product Warranty:
10 Year Warranty
Commercial Residential:
Commercial
Door Handing:
Non-handed
Finish Description:
Matte Black
Latch Description:
Spring Latch
Specifications Bullet 1:
Grade 1 Passage Function Cylindrical Lockset
Parent Manufacturer:
Allegion
Can Be Keyed:
No
Lever/Knob/Pull Design:
Sparta
Function:
Passage
Bore Hole Diameter (in):
2-1/8"
Keyway:
Not Applicable
Minimum Door Thickness (in):
1-5/8"
Specifications Bullet 6:
3-1/2" Projection
Specifications Bullet 8:
For Doors 1-5/8" - 2-1/8" Thick
Box Weight (lbs):
5 lbs
Cylinder Type:
Keyless
Lever/Knob/Pull:
Lever
Box Width (in):
8-1/4"
Specifications Bullet 11:
10 Year Warranty
Strike Description:
ASA Strike
Finish:
622/US19
Door Range (Thickness):
1-5/8" - 2-1/8"
Includes Cylinder(s)?:
No
Country Of Origin:
Mexico
Specifications Bullet 5:
1-1/4" x 4-7/8" ASA Strike
Specifications Bullet 4:
1-1/8" X 2-1/4" Spring Latch
Specifications Bullet 7:
3-7/16" Rose
Specifications Bullet 2:
Sparta Lever
Base Material:
Brass Bronze
Fire Rated:
3 Hours {A}
Latch Throw (in):
1/2"
Specifications Bullet 3:
2-3/4" Backset
Series:
ND Series Lever Locks
Box Height (in):
4-3/4"
Certification:
ANSI A156.2-2011, Series 4000, Grade 1, UL Listed
Specifications Bullet 9:
2-1/8" Bore Hole Diameter
Specifications Bullet 10:
ANSI A156.2-2011, Series 4000, Grade 1, UL Listed
Projection (in):
3-1/2"
Box Depth (in):
9-1/2"
Electronic:
No
Grade:
Grade 1
Strike Number:
10-025
ADA:
Yes
Rose/Escutcheon Design:
Not Applicable
Maximum Door Thickness (in):
2-1/8"
Rose/Escutcheon Dimensions (in):
3-7/16"
UOM:
1
Strike Dimensions:
1-1/4" x 4-7/8"
Manufacturer:
Schlage

Warranty Information

10 Year Warranty
