Schlage ND12D ATH 626 Grade 1 Exit Lock Athens Lever Non-Keyed Satin Chrome Finish Non-Handed

Schlage

Write a Review
SKU:
ND12D ATH 626
$422.04
$422.04

Descriptions

Walter Schlage invented the cylindrical lock in 1920. Since then, the Schlage Lock Company has consistently delivered innovation and continuous improvement. In that tradition, The ND Series Cylindrical Lockset is a proven, easy to install product with extensive function, keying, trim and finish capabilities that work in nearly any application. The Schlage ND Series Locksets are commonly used in Healthcare, Education, Government, Office, Retail, and other commercial applications. The ND Series has been certified Grade 1; exceeding 3-million operating cycles without failure. This provides confidence that the lock will last within any type of facility. Finally, Schlage has incorporated wire-wireless capabilities that meet the access control and security needs of every facility owner.
TypeTitleURL
brochure/sales-materialSchlage Finishes Charthttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/ALLEGION_finish-chart.pdf
catalogND Series Locks & Latches Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/Allegion_2014_Commercial_Product_Catalogue_ND_Series_0114.pdf
ND Series Mechanical Grade 1 Cylindrical Locks Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/Schlage_ND_Series_Catalog_106501.pdf
ND Series Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/schlage/catalogs/106501.pdf
installation-guideSchlage ND-Series Standard Installation Instructions (locks manufactured after 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/NDSeriesStandInstallInstructionslocksmanafter8-15-2012.pdf
Schlage ND-Series Standard Installation Instructions (locks manufactured before 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/NDStandInstallInstructionslocksmanubefore8-15-2012.pdf
installation-instructionsND Series Electrified Functions Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/108353.PDF
ND Series Electrified Functions Installation Instructions (solenoid, mfg before 3-14-2016)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/111248.pdf
ND Series Hollow Metal Door Spacer Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/schlage/installation/107544.pdf
ND170 Installation Instructions (locks manufactured after 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/108996.pdf
ND170 Installation Instructions (locks manufactured before 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/106121.pdf
ND25 Installation Instructions (locks manufactured after 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/108995.pdf
ND25 Installation Instructions (locks manufactured before 8-15-2012)https://dvwi9lnoau63q.cloudfront.net/schlage/installation/106122.pdf
Video: ND Series Lock Installationhttps://youtu.be/U6fUoLLH7Kw
keyway-diagramEverest 29 S Keyway Family Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/keywaydiagram/S-Family_Open_Keyway_Diagram.pdf
Everest Keyways Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/keywaydiagram/Everest_Keyways.pdf
Observe Keyways for Classic Conventional Cylinders Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/keywaydiagram/Convetional_Observe_Keyways.pdf
Observe Keyways for Classic Primus XP Cylinders Diagramhttps://dvwi9lnoau63q.cloudfront.net/schlage/keywaydiagram/Primus_Observe_Keyways.pdf
miscellaneousND Series Locks & Latches Warrantyhttps://dvwi9lnoau63q.cloudfront.net/schlage/miscellaneous/Schlage_ND_Series_Commercial_Warranty_December_2013.pdf
price-book2024 Schlage Commercial Price Book (effective 3.2024)https://dvwi9lnoau63q.cloudfront.net/schlage/pricebooks/SCH_pricebook_3-2024.pdf
sell-sheetSchlage ND Series Electrified Cylindrical Locks Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/Schlage_ND_Series_Data_Sheet_110875.pdf
Schlage ND Series Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/106486NDsellsheet.pdf
service-manualSchlage ND Series Service Manualhttps://dvwi9lnoau63q.cloudfront.net/schlage/brochures_sales_material/2021_Schlage_ND_Series_Service_Manual.pdf
templateND Series Templatehttps://dvwi9lnoau63q.cloudfront.net/schlage/templates/Schlage_ND_Series_Template.pdf

Specifications

Brand:
Schlage
Specifications Bullet 1:
Grade 1 Exit Function Cylindrical Lockset
Door Range (Thickness):
1-5/8" - 2-1/8"
Country Of Origin:
Mexico
Lever/Knob/Pull Design:
Athens
Box Depth (in):
9-1/2"
Lever/Knob/Pull:
Lever
Specifications Bullet 2:
Athens Lever
Commercial Residential:
Commercial
Grade:
Grade 1
Fire Rated:
3 Hours {A}
Specifications Bullet 6:
3-5/16" Projection
Electronic:
No
Keyway:
Not Applicable
Specifications Bullet 4:
1-1/8" X 2-1/4" Dead Latch
Certification:
ANSI A156.2-2011, Series 4000, Grade 1, UL Listed
Includes Cylinder(s)?:
No
Door Handing:
Non-handed
Box Height (in):
4-3/4"
Specifications Bullet 3:
2-3/4" Backset
Backset (in):
2-3/4"
Specifications Bullet 11:
10 Year Warranty
Specifications Bullet 10:
ANSI A156.2-2011, Series 4000, Grade 1, UL Listed
Finish Description:
Satin Chrome
Latch Throw (in):
1/2"
Specifications Bullet 7:
3-7/16" Rose
Selling Quantity:
1
Box Weight (lbs):
5 lbs
Minimum Door Thickness (in):
1-5/8"
Function:
Exit
Box Width (in):
8-1/4"
Specifications Bullet 8:
For Doors 1-5/8" - 2-1/8" Thick
Interior/Exterior:
Interior/Exterior
Latch Number:
13-247
Strike Description:
ASA Strike
Finish:
626/US26D
Rose/Escutcheon Dimensions (in):
3-7/16"
Cylinder Type:
Keyless
Specifications Bullet 5:
1-1/4" x 4-7/8" ASA Strike
Latch Dimensions:
1-1/8" X 2-1/4"
Latch Description:
Dead Latch
Number of Pins:
6
Parent Manufacturer:
Allegion
Number of Keys:
2
Rose/Escutcheon:
Rose
Strike Dimensions:
1-1/4" x 4-7/8"
Projection (in):
3-5/16"
Maximum Door Thickness (in):
2-1/8"
Rose/Escutcheon Design:
Not Applicable
Product Warranty:
10 Year Warranty
Strike Number:
10-025
Specifications Bullet 9:
2-1/8" Bore Hole Diameter
Series:
ND Series
UOM:
1
Can Be Keyed:
No
ADA:
Yes
Base Material:
Brass Bronze
Manufacturer:
Schlage
Bore Hole Diameter (in):
2-1/8"

Warranty Information

10 Year Warranty
