  • Falcon T411CP6D D 626 Grade 1 Asylum Cylindrical Lock Key in Lever Cylinder Dane Lever Standard Rose Satin Chrome Finish Non-Handed

Falcon T411CP6D D 626 Grade 1 Asylum Cylindrical Lock Key in Lever Cylinder Dane Lever Standard Rose Satin Chrome Finish Non-Handed

Falcon

Write a Review
SKU:
T411CP6D D 626
$306.05
Falcon T411CP6D D 626 Grade 1 Asylum Cylindrical Lock Key in Lever Cylinder Dane Lever Standard Rose Satin Chrome Finish Non-Handed
$306.05

Descriptions

The T Series extra heavy-duty Grade 1 cylindrical lock is designed to stand up to high-traffic and heavy-abuse applications. The lock can accept any manufacturer’s cylinder, and the cylinder can easily be removed for quick, easy re-keying, so retrofitting a current building is simple. The T Series is constructed with a compression spring that allows the lock to exceed ANSI/BHMA Grade 1 testing requirements. Perfect for high-use institutional applications, the T Series lock delivers by providing a solid product at a solid price.
TypeTitleURL
brochure/sales-materialFalcon Finishes Charthttps://dvwi9lnoau63q.cloudfront.net/falcon/miscellaneous/ALLEGION_finish-chart.pdf
catalogFalcon Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/falcon/catalog/Falcon_Locks_Catalog_110449.pdf
data-sheetT Series Data sheethttps://dvwi9lnoau63q.cloudfront.net/falcon/miscellaneous/Falcon_T_Series_Data_Sheet_106191.pdf
T/W Series Data Sheethttps://dvwi9lnoau63q.cloudfront.net/falcon/miscellaneous/Falcon_T_Series_and_W_Series_Data_Sheet_110522.pdf
installation-instructionsT-Series Installation Instructionshttps://dvwi9lnoau63q.cloudfront.net/falcon/installation_instructions/106829.pdf
T-Series Installation Instructions - Electricalhttps://dvwi9lnoau63q.cloudfront.net/falcon/installation_instructions/110164.pdf
price-book2024 Falcon Price Book (effective 3.2024)https://dvwi9lnoau63q.cloudfront.net/falcon/pricebooks/FAL_pricebook_3-2024.pdf
product-guideFalcon Cylindrical Lock Guidehttps://dvwi9lnoau63q.cloudfront.net/falcon/miscellaneous/Falcon_Cylindrical_Lock_Guide_110894.pdf
sell-sheetT and W Series Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/falcon/sell-sheets/Falcon_T_Series_and_W_Series_Data_Sheet_110522.pdf
T-Series Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/falcon/literature/106191.pdf
service-manualT-Series Service Manualhttps://dvwi9lnoau63q.cloudfront.net/falcon/manuals/108002.pdf

Specifications

Brand:
Falcon
Latch Dimensions:
1-1/8" x 2-1/4"
Function:
Asylum
Can Be Keyed:
Yes
Specifications Bullet 4:
2-3/4" Backset
Specifications Bullet 1:
Grade 1 Asylum Function Cylindrical Lockset
Latch Bore Diameter (in):
1"
Finish Description:
Satin Chrome
Latch Number:
23981145
Electronic:
No
Fire Rated:
3 Hours {A}
Lever/Knob/Pull Design:
Dane
Specifications Bullet 3:
Conventional C Keyway
Commercial Residential:
Commercial
Specifications Bullet 6:
1-1/4" x 4-7/8" ASA Strike
Series:
T Series Grade 1 Cylindrical Lever Locks
Door Handing:
Non-handed
Specifications Bullet 8:
3-1/2" Rose
Specifications Bullet 10:
2-1/8" Bore Hole Diameter
Specifications Bullet 7:
3-1/4" Projection
Latch Description:
Dead Latch
Keyway:
C Keyway
Rose/Escutcheon:
Rose
Includes Cylinder(s)?:
Yes
Latch Throw (in):
1/2"
Maximum Door Thickness (in):
2-1/8"
Specifications Bullet 5:
1-1/8" x 2-1/4" Dead Latch
Specifications Bullet 2:
Dane Lever
Grade:
Grade 1
Lever/Knob/Pull:
Lever
ADA:
Yes
Product Warranty:
10 Year Warranty
Door Range (Thickness):
1-3/8" - 2-1/8"
Certification:
ANSI A156.2, Series 4000, Grade 1, UL Listed
Minimum Door Thickness (in):
1-3/8"
Selling Quantity:
1
Finish:
626/US26D
Bore Hole Diameter (in):
2-1/8"
Cylinder Type:
Conventional
Rose/Escutcheon Dimensions (in):
3-1/2"
Projection (in):
3-1/4"
Specifications Bullet 12:
10 Year Warranty
UOM:
1
Rose/Escutcheon Design:
Not Applicable
Strike Dimensions:
1-1/4" x 4-7/8"
Strike Number:
5164
Specifications Bullet 9:
For Doors 1-3/8" - 2-1/8" Thick
Parent Manufacturer:
Allegion
Strike Description:
ASA Strike
Backset (in):
2-3/4"
Base Material:
Brass Bronze
Specifications Bullet 11:
ANSI A156.2, Series 4000, Grade 1, UL Listed
Manufacturer:
Falcon

Warranty Information

10 Year Warranty
