  • Hager 2550 SCC WTN US26D KD Grade 2 Office Cylindrical Lock Withnell Lever Not Handed Conventional Cylinder ASA Strike Satin Chrome

Hager 2550 SCC WTN US26D KD Grade 2 Office Cylindrical Lock Withnell Lever Not Handed Conventional Cylinder ASA Strike Satin Chrome

Hager

Write a Review
SKU:
2550 SCC WTN US26D KD
$93.67
Hager 2550 SCC WTN US26D KD Grade 2 Office Cylindrical Lock Withnell Lever Not Handed Conventional Cylinder ASA Strike Satin Chrome
UPC:
798550296423
$93.67

Descriptions

Hager 2500 Series Grade 2 lock is a perfect combination of value and performance and is the ideal choice of lock for typical commercial applications. The inherent value of this lock and the product offering make our 2500 Series lock a perfect choice for a stocking program. As an economical alternative to other Grade 2 cylindrical locks, it offers both dependability and affordability.
TypeTitleURL
catalogHager Locks Cataloghttps://dvwi9lnoau63q.cloudfront.net/hager/catalogs/HAGER_catalog_2016-rev5-v133.pdf
Understanding Interchangeable Coreshttps://dvwi9lnoau63q.cloudfront.net/hager/catalogs/understanding_interchangeable_cores.pdf
instruction-sheets2500 Series Grade 2 Lever Set Instruction Sheethttps://dvwi9lnoau63q.cloudfront.net/hager/installation/2500seriesleverinstallation.pdf
2517 Dummy Direct Door Mounting Instruction Sheethttps://dvwi9lnoau63q.cloudfront.net/hager/installation/2517_Mounting_Instructions.pdf
2550 & 2553 Lever Re-Key Supplemental Instruction Sheethttps://dvwi9lnoau63q.cloudfront.net/hager/installation/2055-rekeysuppliment-installation_instructions.pdf
2570 Grade 2 Leverset Timing Instruction Sheethttps://dvwi9lnoau63q.cloudfront.net/hager/installation/2570-installation_instructions.pdf
price-book2022 Hager Price Bookhttps://dvwi9lnoau63q.cloudfront.net/hager/pricebooks/HAGER_pricebook_16.12_12-2022.pdf
videoTiming a Hager Classroom Function Locksethttps://youtu.be/UiLmJceC4Qk

Specifications

Brand:
Hager
Door Handing:
Non-handed
Keyway:
C Keyway
Fire Rated:
3 Hours {A}
Series:
Hager Cylindrical Locks
Cylinder Type:
Conventional
Lever/Knob/Pull Design:
WTN
Projection (in):
2-21/32"
Includes Cylinder(s)?:
Yes
Specifications Bullet 5:
1-1/8" x 2-1/4" Dead Latch
Specifications Bullet 8:
3-11/32" Rose
Grade:
Grade 2
Rose/Escutcheon Design:
Not Applicable
Specifications Bullet 9:
For Doors 1-3/8" - 2" Thick
Specifications Bullet 2:
WTN Lever
Function:
Office
Specifications Bullet 1:
Grade 2 Office Function Cylindrical Lockset
Latch Throw (in):
1/2"
Lever/Knob/Pull:
Lever
Strike Description:
ASA Strike
Strike Number:
3935
Rose/Escutcheon Dimensions (in):
3-11/32"
ADA:
Yes
Specifications Bullet 7:
2-21/32" Projection
Country of Origin:
United States
Specifications Bullet 6:
1-1/4" x 4-7/8" ASA Strike
Finish Description:
Satin Chrome
UOM:
1
Specifications Bullet 3:
Conventional C Keyway
Base Material:
Brass Bronze
Bore Hole Diameter (in):
2-1/8"
Strike Dimensions:
1-1/4" x 4-7/8"
Door Range (Thickness):
1-3/8" - 2"
Latch Number:
3948
Latch Description:
Dead Latch
Specifications Bullet 4:
2-3/4" Backset
Specifications Bullet 12:
5 Year Warranty
Specifications Bullet 10:
2-1/8" Bore Hole Diameter
Maximum Door Thickness (in):
2"
Finish:
626/US26D
Minimum Door Thickness (in):
1-3/8"
UPC:
798550296423
Can Be Keyed:
Yes
Certification:
ANSI A156.2, Series 4000, Grade 2, ANSI A117.1 ADA, UL Listed
Specifications Bullet 11:
ANSI A156.2, Series 4000, Grade 2, ANSI A117.1 ADA, UL Listed
Backset (in):
2-3/4"
Product Warranty:
5 Year Warranty
Latch Dimensions:
1-1/8" x 2-1/4"
Rose/Escutcheon:
Rose
Manufacturer:
Hager
Uid:
HAG2550SCCWTNUS26DKD
Url Title:
2550-scc-wtn-us26d-kd
Title:
2550 SCC WTN US26D KD Hager Cylindrical Lock
Type:
Locks, Cylinders, Cores, Keyblanks
Sub Type:
Cylindrical Lock
Last Modified:
2023-02-13T07:58:21+00:00
Last Pricing:
2022-07-13T00:00:00+00:00
Msrp:
141.59
Popularity:
9
Limited Warranty:
5 Years

Warranty Information

5 Year Warranty
