HES 4500C-630 Grade 1 Electric Strike Fail Safe/Fail Secure 12/24 VDC Low Profile Fire Rated Satin Stainless Steel

HES

Write a Review
SKU:
4500C-630
$485.10
HES 4500C-630 Grade 1 Electric Strike Fail Safe/Fail Secure 12/24 VDC Low Profile Fire Rated Satin Stainless Steel
$485.10

Descriptions

The 4500C series electric strike is designed for installation in 2" UL 10C fire-rated frames with 1/2" drywall penetration. The 4500C features a low profile 1-3/8" depth, heavy-duty stainless steel construction. Its strength is derived from a unique keeper pin locking design, enabling the 4500C to exceed the ratings of the frame, door and locking hardware. Each Complete Pac conveniently paris the reliabilty of an HES electric strike with the flexibility of multiple faceplates in a single simple package. The 4500C includes a 4500 strike body and two interchangeable faceplates to accommodate most cylindrical and mortise latchbolts (without deadbolts).
TypeTitleURL
brochure/sales-materialAA ESH Electric Strike Overviewhttps://dvwi9lnoau63q.cloudfront.net/hes/literature/ESH_Electric_Strike_Overview_Brochure.pdf
catalog2021 HES/Securitron Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/hes/catalog/ASSA_ABLOY_ESH_Catalog.pdf
compatibility-chartHES Compatibility Charthttps://dvwi9lnoau63q.cloudfront.net/hes/compatibility-chart/HESCompatibilityChart2015.pdf
cross-reference-sheetHES Lock Cross Reference Charthttps://dvwi9lnoau63q.cloudfront.net/hes/cross-reference-sheet/HESLockCrossReference2015.pdf
dimensional-drawingHES 4500 Series Dimensional Drawingshttps://dvwi9lnoau63q.cloudfront.net/hes/dimensional-drawing/HES4500DimensionalDrawings.pdf
HES 4500C Series Dimensional Drawingshttps://dvwi9lnoau63q.cloudfront.net/hes/dimensional-drawing/HES4500DimensionalDrawings.pdf
installation-guideHES 4500 Series Installation Guidehttps://dvwi9lnoau63q.cloudfront.net/hes/installation-guide/4500SeriesInstallInstructions3053006.002RevC.pdf
HES 4500C Series Installation Guidehttps://dvwi9lnoau63q.cloudfront.net/hes/installation-guide/4500SeriesInstallInstructions3053006.002RevC.pdf
installation-instructionsVideo: 4500 Series Electric Strike Fail Secure to Fail Safehttps://youtu.be/FmyVdOUEVxQ
price-book2023 HES Price Book (effective 4.17.2023)https://dvwi9lnoau63q.cloudfront.net/hes/pricebooks/HES_pricebook_11-2023.pdf
product-guideElectric Strike Selector Guidehttps://dvwi9lnoau63q.cloudfront.net/hes/product-guide/Electric_Strike_Selector_Guide.pdf
sell-sheetHES 4500C Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/hes/sell-sheet/ESH_HES_4500C_Electric_Strike_CP_Sell_Sheet_WEB1.pdf

Specifications

Brand:
HES
Box Height (in):
4-7/8"
Specifications Bullet 3:
Includes Plug-In Connector
Door Range (Thickness):
-
Box Depth (in):
1-3/8"
Base Material:
Stainless Steel
FS/FSE Mode:
Fail Safe / Fail Secure
Specifications Bullet 2:
For Mortise or Cylindrical Locksets having 3/4" Throw
Current:
240mA @ 12 VDC, 120mA @ 24 VDC Current
Finish Description:
Satin Stainless Steel
Specifications Bullet 7:
1-1/4" x 4-7/8" Unit Dimension
Electronic:
No
Latch Throw (in):
3/4"
Fire Rated:
3 Hours {A}
Grade:
Grade 1
Specifications Bullet 8:
Accepts 3/4" Latch Throw
Certification:
ANSI A156.31, Grade 1, UL 1034, UL 10C
Specifications Bullet 9:
ANSI A156.31, Grade 1, UL 1034, UL 10C
Finish:
630/US32D
Specifications Bullet 4:
1500 lbs Static Holding Strength
Dynamic Impact Strength:
100 foot-pounds
Door Handing:
Non-handed
Dimensions:
1-1/4" x 4-7/8"
Application:
For Mortise or Cylindrical Locksets having 3/4" Throw
Specifications Bullet 10:
5 Year Warranty
Country Of Origin:
USA
Product Warranty:
5 Year Warranty
Specifications Bullet 5:
240mA @ 12 VDC, 120mA @ 24 VDC Current
Box Width (in):
1-1/4"
Specifications Bullet 1:
12/24 VDC Voltage Electric Strike
Selling Quantity:
1
Frame Material:
Metal/Wood
UOM:
1
Strike Dimensions:
1-1/4" x 4-7/8"
Interior/Exterior:
Interior/Exterior
Series:
4500C Series Electric Strikes
Parent Manufacturer:
Assa Abloy
Voltage:
12/24 VDC Voltage
Commercial Residential:
Commercial
Manufacturer:
HES
Specifications Bullet 6:
Fail Safe / Fail Secure
Static Holding Strength (lbs):
1500
Includes:
Plug-In Connector
Uid:
HAN1004500C630
Url Title:
4500c-630
Title:
4500C-630 HES Electric Strike
Type:
Electric Strikes, Bolts, Magnets
Sub Type:
Electric Strikes
Last Modified:
2024-02-03T05:13:06+00:00
Last Pricing:
2023-04-17T00:00:00+00:00
Msrp:
750
Avg Lead Time:
14
Finish Family:
Matte Silver
Popularity:
3
Pack Weight:
1.3
Pack Length:
10.5
Pack Width:
3.375
Pack Height:
2.25
Pack Volume:
79.734375
Baa Qualified:
Yes
Limited Warranty:
5 Years
Unit Of Measure:
Each
Vendor:
Assa Abloy

Warranty Information

5 Year Warranty
