HES 8500-630-LBSM Fail Safe/Fail Secure Body Only 12/24VDC Electric Strike Latchbolt Strike Monitor Satin Stainless Steel

HES

Write a Review
SKU:
8500-630-LBSM
$483.81
HES 8500-630-LBSM Fail Safe/Fail Secure Body Only 12/24VDC Electric Strike Latchbolt Strike Monitor Satin Stainless Steel
$483.81

Descriptions

The 8500 series is a fire rated, compact, high performance electric strike featuring a unique concealed design for use with mortise locksets without a deadbolt. Designed for fast, convenient installation, the 8500 installs with little or no modification to the frame. Simply remove the existing strike plate, remove the dust box and install. Its strength is derived from a unique keeper pin locking design, enabling the 8500 to exceed Grade-1 ratings. This unique electric strike complies with NFPA 80-07 guidelines for retrofit into fire-rated frames. The 8500 accommodates mortise latchbolts up to 3/4" throw.
TypeTitleURL
brochure/sales-materialAA ESH Electric Strike Overviewhttps://dvwi9lnoau63q.cloudfront.net/hes/literature/ESH_Electric_Strike_Overview_Brochure.pdf
catalog2021 HES/Securitron Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/hes/catalog/ASSA_ABLOY_ESH_Catalog.pdf
compatibility-chartHES Compatibility Charthttps://dvwi9lnoau63q.cloudfront.net/hes/compatibility-chart/HESCompatibilityChart2015.pdf
cross-reference-sheetHES Lock Cross Reference Charthttps://dvwi9lnoau63q.cloudfront.net/hes/cross-reference-sheet/HESLockCrossReference2015.pdf
installation-guideHES 8500 Series Installation Guidehttps://dvwi9lnoau63q.cloudfront.net/hes/installation-guide/HES8500InstallInstructions.pdf
price-book2023 HES Price Book (effective 4.17.2023)https://dvwi9lnoau63q.cloudfront.net/hes/pricebooks/HES_pricebook_11-2023.pdf
product-guideElectric Strike Selector Guidehttps://dvwi9lnoau63q.cloudfront.net/hes/product-guide/Electric_Strike_Selector_Guide.pdf
HES 8500 Electric Strike Promo Videohttps://youtu.be/kiEo9DgRAts
HES 8500 Series Compliance Sustainabilityhttps://dvwi9lnoau63q.cloudfront.net/hes/product-guide/HES_8500_NFPA-80_Compliance.pdf
HES 8500 Series Overviewhttps://dvwi9lnoau63q.cloudfront.net/hes/product-guide/HES8500SeriesOverview2015.pdf
sell-sheetHES 8500 Series Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/hes/sell-sheet/HES_8500_Sell_Sheet.pdf

Specifications

Brand:
HES
Box Width (in):
1-1/4"
Electronic:
No
Specifications Bullet 11:
5 Year Warranty
Static Holding Strength (lbs):
1500
Box Depth (in):
1-5/16"
Parent Manufacturer:
Assa Abloy
Selling Quantity:
1
Latch Throw (in):
3/4"
Dimensions:
1-1/4" x 4-7/8"
Includes:
Plug-In Connector
Manufacturer:
HES
Fire Rated:
3 Hours {A}
Specifications Bullet 10:
ANSI A156.31, Grade 1, UL 1034, UL 10C
Specifications Bullet 9:
Accepts 3/4" Latch Throw
Specifications Bullet 8:
1-1/4" x 4-7/8" Unit Dimension
Current:
240mA @ 12 VDC, 120mA @ 24 VDC Current
Specifications Bullet 4:
Includes Plug-In Connector
FS/FSE Mode:
Fail Safe / Fail Secure
Certification:
ANSI A156.31, Grade 1, UL 1034, UL 10C
Frame Material:
Metal/Wood
Finish Description:
Satin Stainless Steel
Dynamic Impact Strength:
70 foot-pounds
Finish:
630/US32D
Series:
8500 Series Electric Strikes
Base Material:
Stainless Steel
Specifications Bullet 5:
1500 lbs Static Holding Strength
Specifications Bullet 1:
12/24 VDC Voltage Electric Strike
Application:
For Mortise or Cylinderical Locksets having 3/4" Throw
Specifications Bullet 2:
For Mortise or Cylinderical Locksets having 3/4" Throw
Door Range (Thickness):
-
Commercial Residential:
Commercial
Specifications Bullet 3:
(LBSM) Latchbolt Strike Monitor
Country Of Origin:
USA
Box Height (in):
4-7/8"
Door Handing:
Non-handed
Strike Dimensions:
1-1/4" x 4-7/8"
Interior/Exterior:
Interior/Exterior
Option 1:
(LBSM) Latchbolt Strike Monitor
Specifications Bullet 7:
Fail Safe / Fail Secure
UOM:
1
Voltage:
12/24 VDC Voltage
Product Warranty:
5 Year Warranty
Specifications Bullet 6:
240mA @ 12 VDC, 120mA @ 24 VDC Current
Grade:
Grade 1
Uid:
HAN1008500LBSM630
Url Title:
8500-lbsm-630
Title:
8500-630-LBSM HES Electric Strike
Type:
Electric Strikes, Bolts, Magnets
Sub Type:
Electric Strikes
Last Modified:
2024-02-03T05:26:48+00:00
Last Pricing:
2022-07-28T00:00:00+00:00
Msrp:
707
Avg Lead Time:
18
Finish Family:
Matte Silver
Popularity:
3
Pack Weight:
1
Pack Length:
10.5
Pack Width:
3.375
Pack Height:
2.25
Pack Volume:
79.734375
Baa Qualified:
Yes
Limited Warranty:
5 Years
Unit Of Measure:
Each
Vendor:
Assa Abloy

Warranty Information

5 Year Warranty
