HES 9600-630-LBM Grade 1 Electric Strike Fail Safe/Fail Secure 12/24 VDC Surface Mounted 3/4 Thickness Latchbolt Monitor Satin Stainless Steel Finish

HES

Write a Review
SKU:
9600-630-LBM
$449.53
HES 9600-630-LBM Grade 1 Electric Strike Fail Safe/Fail Secure 12/24 VDC Surface Mounted 3/4 Thickness Latchbolt Monitor Satin Stainless Steel Finish
$449.53

Descriptions

The 9600 Series is a windstorm rated, surface mounted electric strike designed to accommodate rim exit devices with a 3/4" throw latch. All components are completely encased within its 3/4" thick stainless steel housing, so no cutting on the frame is required for installation. Simply place the electric strike on the surface of the frame, align it with the exit latchbolt and install. It is field selectable for fail secure and fail safe operation, and for 12 or 24VDC.
TypeTitleURL
brochure/sales-materialAA ESH Electric Strike Overviewhttps://dvwi9lnoau63q.cloudfront.net/hes/literature/ESH_Electric_Strike_Overview_Brochure.pdf
catalog2021 HES/Securitron Product Cataloghttps://dvwi9lnoau63q.cloudfront.net/hes/catalog/ASSA_ABLOY_ESH_Catalog.pdf
compatibility-chartHES Compatibility Charthttps://dvwi9lnoau63q.cloudfront.net/hes/compatibility-chart/HESCompatibilityChart2015.pdf
cross-reference-sheetHES Lock Cross Reference Charthttps://dvwi9lnoau63q.cloudfront.net/hes/cross-reference-sheet/HESLockCrossReference2015.pdf
dimensional-drawingHES 9600 Series Dimensional Drawingshttps://dvwi9lnoau63q.cloudfront.net/hes/dimensional-drawing/HES9600DimensionalDrawings.pdf
installation-guideHES 9400/9500/9600 Electric Strike Installation Guidehttps://dvwi9lnoau63q.cloudfront.net/hes/installation-guide/AADSS1053638_1.pdf
HES 9600 Series Installation Guidehttps://dvwi9lnoau63q.cloudfront.net/hes/installation-guide/9400_9500_9600InstallationInstructions.pdf
HES 9600 Series Installation Templatehttps://dvwi9lnoau63q.cloudfront.net/hes/installation-guide/940095009600InstallationTemplate.pdf
literatureHES 9600 Series Electric Strike - Environmental Product Declaration (EPD)https://dvwi9lnoau63q.cloudfront.net/hes/product-guide/128.1_ASSA_ABLOY_mrEPD_HES9600SeriesElectric_Strike.pdf
product-guideElectric Strike Selector Guidehttps://dvwi9lnoau63q.cloudfront.net/hes/product-guide/Electric_Strike_Selector_Guide.pdf
HES 9400, 9500, 9600 Surface Mounted Electric Strikes Videohttps://youtu.be/8VjpbNdYvUE
HES 9600 Series Overviewhttps://dvwi9lnoau63q.cloudfront.net/hes/product-guide/HES9600SeriesOverview2015.pdf
HES Electric Strikes for Every Lockset Applicationhttps://dvwi9lnoau63q.cloudfront.net/hes/product-guide/HES_guide_slectric-strikes.pdf
HES Electric Strikes How to Order Guidehttps://dvwi9lnoau63q.cloudfront.net/hes/product-guide/HESESHowtoOrder2015.pdf
sell-sheetHES 9600 Series Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/hes/sell-sheet/HES_9600_Sell-Sheet.pdf

Specifications

Brand:
HES
Specifications Bullet 3:
(DMS) Dual Monitor Switch
Door Handing:
Non-handed
Armor Front Dimensions:
1-3/4" x 9"
Current:
240mA @ 12 VDC, 120mA @ 24 VDC Current
Fire Rated:
No
Box Height (in):
9"
Finish:
630/US32D
Base Material:
Stainless Steel
Specifications Bullet 10:
5 Year Warranty
Commercial Residential:
Commercial
Specifications Bullet 2:
For RIM Exit Devices having 3/4" Throw, Windstorm-Rated
Dimensions:
1-3/4" x 9"
Certification:
ANSI A156.31, Grade 1, SDIA 250.13
Box Width (in):
1-3/4"
Box Depth (in):
3/4"
Door Range (Thickness):
-
Dynamic Impact Strength:
120 foot-pounds
Interior/Exterior:
Interior/Exterior
Electronic:
No
Frame Material:
Metal/Wood
Manufacturer:
HES
Application:
For RIM Exit Devices having 3/4" Throw, Windstorm-Rated
Country Of Origin:
USA
Specifications Bullet 4:
2000 lbs Static Holding Strength
Product Warranty:
5 Year Warranty
Latch Throw (in):
3/4"
Specifications Bullet 1:
12/24 VDC Voltage Electric Strike
Selling Quantity:
1
Grade:
Grade 1
FS/FSE Mode:
Fail Safe / Fail Secure
Finish Description:
Satin Stainless Steel
Specifications Bullet 9:
ANSI A156.31, Grade 1, SDIA 250.13
Series:
9600 Series Electric Strikes
Specifications Bullet 6:
Fail Safe / Fail Secure
Specifications Bullet 5:
240mA @ 12 VDC, 120mA @ 24 VDC Current
Option 1:
(DMS) Dual Monitor Switch
Specifications Bullet 8:
Accepts 3/4" Latch Throw
UOM:
1
Specifications Bullet 7:
1-3/4" x 9" Unit Dimension
Parent Manufacturer:
Assa Abloy
Static Holding Strength (lbs):
2000
Voltage:
12/24 VDC Voltage
Uid:
HAN1009600630LBM
Url Title:
9600-630-lbm
Title:
9600-630-LBM Electric Strike
Type:
Electric Strikes, Bolts, Magnets
Sub Type:
Electric Strikes
Last Modified:
2024-02-03T05:28:41+00:00
Last Pricing:
2023-04-17T00:00:00+00:00
Msrp:
695
Avg Lead Time:
11
Finish Family:
Matte Silver
Popularity:
3
Pack Weight:
1.7
Pack Length:
10.5
Pack Width:
3.375
Pack Height:
2.25
Pack Volume:
79.734375
Baa Qualified:
Yes
Limited Warranty:
5 Years
Unit Of Measure:
Each
Vendor:
Assa Abloy

Warranty Information

5 Year Warranty
