Norton 5730 689 Low Energy Surface Mounted Electrohydraulic Door Operator Double Lever Arm Regular Push Side Mounted Top Jamb 29 - 36 Door 170 Deg Swing Aluminum Painted Finish

Norton

Write a Review
SKU:
5730 689
$3,034.79
Norton 5730 689 Low Energy Surface Mounted Electrohydraulic Door Operator Double Lever Arm Regular Push Side Mounted Top Jamb 29 - 36 Door 170 Deg Swing Aluminum Painted Finish
$3,034.79

Descriptions

A reliable ADA solution comprising Norton's heavy-duty 1601 door closer. The use of a hydraulic closer ensures quiet and consistently smooth operation, ideal in applications where doors are typically operated manually but can also be activated via wall switches for automatic operation. The 5700 offers basic automated door functions and is designed for quick set-up, making it easy to specify and install.
TypeTitleURL
brochure/sales-materialNorton Rixson Low Energy Operator Brochurehttps://dvwi9lnoau63q.cloudfront.net/norton/brochures/NOR_brochure_low-energy-ops_11-23.pdf
catalog2021 Norton Operators Cataloghttps://dvwi9lnoau63q.cloudfront.net/norton/catalogs/Norton_Operators_Catalog.pdf
5700 Low Energy Operatorhttps://dvwi9lnoau63q.cloudfront.net/norton/catalogs/43100_NOR_5700.pdf
5700 Series Operator Cataloghttps://dvwi9lnoau63q.cloudfront.net/norton/catalogs/Norton_5700_Series_Operator_Catalog.pdf
installation5700 Series Operator, Pull Side Mountedhttps://dvwi9lnoau63q.cloudfront.net/norton/installation/80-9357-0004-020.pdf
5700 Series Operator, Push Side Mountedhttps://dvwi9lnoau63q.cloudfront.net/norton/installation/80-9357-0005-020.pdf
5700P Series Operator with Optional Plug-In Power Input, Pull Side Mountedhttps://dvwi9lnoau63q.cloudfront.net/norton/installation/80-9357-0006-020.pdf
5700P Series Operator with Optional Plug-In Power Input, Push Side Mountedhttps://dvwi9lnoau63q.cloudfront.net/norton/installation/80-9357-0007-020.pdf
literature5700 Series Swinging Door Operator - Environmental Product Declaration (EPD)https://dvwi9lnoau63q.cloudfront.net/norton/literature/156.1_ASSA_ABLOY_mrEPD_Swinging_door_operator_Norton_5700_Series.pdf
price-books2023 Norton Price Book (effective 4.17.2023)https://dvwi9lnoau63q.cloudfront.net/norton/pricebooks/NOR_RIX_pricebook_4-2023.pdf
sell-sheetNorton Touchless Environments Sell Sheethttps://dvwi9lnoau63q.cloudfront.net/norton/sell-sheet/Norton_Touchless_Environments_Sell_Sheet.pdf
touchless-electrical-solutionsNorton Low Energy Operators Brochurehttps://dvwi9lnoau63q.cloudfront.net/norton/brochures/Norton_Low_Energy_Door_Operators_Brochure.pdf
wiring-diagrams5700 Series Operator 5700 x 2 Actuatorshttps://dvwi9lnoau63q.cloudfront.net/norton/wiring-diagram/120909_5700_x_2_Actuators.pdf
5700 Series Operator 5700 x RFhttps://dvwi9lnoau63q.cloudfront.net/norton/wiring-diagram/120908_5700_x_RF.pdf
wiring-instructions5710, 5730, 5740, Push or Pull Side Mounting (5700 Series)https://dvwi9lnoau63q.cloudfront.net/norton/wiring-instructions/80-9357-0001-020.pdf

Specifications

Brand:
Norton
Specifications Bullet 4:
120 VAC 60Hz Input
Finish Description:
Aluminum Painted
LED Indicators:
No
Specifications Bullet 7:
2-5/8" to 6-3/4" Reveal
Arm Type:
Double Lever Arm
Grade:
Grade 1
Finish:
689/US28
Series:
5700 Series Operators
Application:
For use with Interior Doors up to 48"
Door Range (Thickness):
-
Specifications Bullet 1:
Push Side Mount Power Operator
Door Handing:
Non-handed
Electronic:
No
Specifications Bullet 6:
SPDT Switch
Degree Swing:
110 to 170 Degree
Specifications Bullet 2:
Double Lever Arm
Commercial Residential:
Commercial
Specifications Bullet 12:
2 Year Warranty
Specifications Bullet 3:
For use with Interior Doors up to 48"
Manufacturer:
Norton
Specifications Bullet 9:
200 lbs Maximum Door Weight
Dimensions:
29" x 5-1/4"
Body Base Material:
Cast Aluminum
Onboard Diagnostics:
No
Hold Open:
Yes
Specifications Bullet 5:
24 VDC Output @ 1.1A
ADA:
Yes
Base Material:
Varies
Interior/Exterior:
Interior/Exterior
Input Power:
120 VAC 60Hz Input
Certification:
ANSI A156.4, A156.19, Grade 1, UL Listed, ADA
Mount:
Push Side Mount
UOM:
1
Specifications Bullet 8:
29" x 5-1/4" Unit Dimension
Onboard Power Supply:
Yes
Product Warranty:
2 Year Warranty
Maximum Door Weight (lbs):
200
Specifications Bullet 10:
Includes Machine Screws
Cover Material:
Metal
Includes:
Inverter
Parent Manufacturer:
Assa Abloy
Mounting Detail:
2-5/8" to 6-3/4" Reveal
Size:
Size 3-6
Output:
24 VDC Output @ 1.1A
Specifications Bullet 11:
ANSI A156.4, A156.19, Grade 1, UL Listed, ADA
Switch Type:
SPDT Switch
Screw Pack:
Machine Screws
Selling Quantity:
1
Type:
Door Closers and Operators
Uid:
NOR5730689
Url Title:
5730-689
Title:
5730 689 Norton Door Operators
Sub Type:
Door Operators
Last Modified:
2023-02-28T05:09:58+00:00
Last Pricing:
2022-09-16T00:00:00+00:00
Msrp:
4100
Avg Lead Time:
48
Finish Family:
Matte Silver
Popularity:
3
Pack Weight:
20
Pack Length:
35
Pack Width:
9
Pack Height:
7
Pack Volume:
2205
Country Of Origin:
USA
Baa Qualified:
Yes
Limited Warranty:
2 Years
Accessible:
Yes
Unit Of Measure:
Each
Vendor:
Assa Abloy

Warranty Information

2 Year Warranty
